- Page 1 KIDS ELECTRIC DIRT BIKE OWNER'S MANUAL...
-
Page 2: User Manual
User Manual If the bike has power but cannot move, turn off the power immediately User Manual to avoid damaging the electronics. Notice: The illustrations are for demonstration purposes only. They When you get off the bike or push it, turn off the bike to prevent it from may not reflect the exact appearance of the actual product. -
Page 3: Table Of Contents
Table of Contents Table of Contents User Manual ....................................................1 1. Packaging Details ................................................3 1.1 Packing Lis ...................................................3 1.2 Description of Each Part .............................................. 3 2. Complete Vehicle Assembly ............................................4 2.2 Handlebar Tube Installation Diagram .......................................... 4 2.3 Front Mudguard Installation Diagram ......................................... 5 2.4 Front Wheel Installation Diagram ..........................................6 3. -
Page 4: Packaging Details
1. Packaging Details 1. Packaging Details 1.2 Description of Each Part 1.1 Packing Lis Serial No. Name Quantity Illustration ltem Quantity Tool Kit Complete Vehicle Front Mudguard Tool Kit Front Wheel Front Mudguard Front Wheel Accessory Pack Accessory Pack (Front Wheel Axle, Front Mudguard Installation Screws, Rear Shock Absorber Installation Instruction Screws) -
Page 5: Complete Vehicle Assembly
2. Complete Vehicle Assembly 2. Complete Vehicle Assembly 2.2 Handlebar Tube Installation Diagram 2.1 Rear Shock Absorber Installation Diagram Top booth Mounting screw handlebar Lower booth Rear shock absorber Rotating handle installation diagram Fastening screw Rear shock-absorbing mounting screws Upon receiving the complete vehicle, the rear shock absorber will be in a disassembled state. -
Page 6: Front Mudguard Installation Diagram
2. Complete Vehicle Assembly 2.3 Front Mudguard Installation Diagram Finish the horizontal installation Front fender Clearance between upper and lower booths When you receive the product, the handlebars will be disassembled. You must install the handlebars onto the vehicle before riding. Start by using an M8 Allen Mounting screw wrench to remove the four screws from the stem. -
Page 7: Front Wheel Installation Diagram
2. Complete Vehicle Assembly Remove the front mudguard from the packaging. Attach the rear-facing limit catch of the front mudguard to the lower connecting plate of the front fork, ensuring that the limit post of the mudguard goes through the limit hole on the inner side of the number plate. -
Page 8: Operating Instructions
3. Operating Instructions 3. Operating Instructions 3.1 Riding Instructions 3.1.2 Handle Operation 3.1.1 Fastener Inspection 3.1.2.1 Power On/Off Switch The diagram shows the vehicle's power button. To operate the vehicle, use this button to turn the power on or off. The "I" position indicates that the vehicle is on, and the "O"... -
Page 9: Charging Instructions
3. Operating Instructions 3.1.2.3 Battery Display 3.1.2.2 Speed Adjustment Power indicator light Gear adjustment switch The diagram shows the battery display function. The meter has three lights; when all three are lit, the battery is over 75% charged. When only one light remains and it changes from green to red, it indicates that the vehicle needs to be charged to continue riding. - Page 10 3. Operating Instructions To charge this product, connect the charger to the input end, then plug the input end into a household socket, and insert the output end into the charging port shown in Charging port position the diagram to start charging the vehicle. The charging mode is indicated by the color of the light at the depicted location.
-
Page 11: Usage Scenarios
4. Usage Scenarios 4. Usage Scenarios 4.1 Usage Scenario Illustrations Remember: Check with your local authority first as to where you can ride this bike safely and legally. -
Page 12: Routine Maintenance
5. Routine Maintenance 5. Routine Maintenance 5.2.2 Hydraulic Brake Maintenance Instructions 5.1 Electrical Component Maintenance Instructions ① When maintaining the brake, use a special tool to unscrew the disc brake Lithium-ion batteries should be stored in a cool, dry, and ventilated environment, lever oil filling port screw, and then inject oil into the oil pipe with a syringe to adjust away from sources of fire and heat. -
Page 13: Tire Maintenance Instructions
5. Routine Maintenance 5.5 Tire Maintenance Instructions If the battery is normal and the display screen lights up, then there is no fault with Measure whether the tire pressure meets the tire label pressure; if not, adjust the the display; if the display does not light up, there may be a fault with the display or pressure by inflating or deflating. -
Page 14: Service Manual
6. Service Manual 6. Service Manual 6.1 List of wearing parts Serial number name tyre Brake pad Chain Plastic covering 6.2 List of three guarantees name Warranty period Supplementary statement frame 3 years battery 15 months The warranty period is calculated on the date of the code controller 1 year... -
Page 15: Warranty Record
6. Service Manual 6.3 Warranty record When the vehicle is handed over, the customer and the vehicle data must be completed. Maintenance No.1 Maintenance No.2 Maintenance No.3 Current mileage: Current mileage: Current mileage: Date: Date: Date: Dealer stamp/signature Dealer stamp/signature Dealer stamp/signature Maintenance No.1 Maintenance No.5...
