Network Video Recorder
Quick Installation Guide
DS-2200 UHD+ Series
2.2.0.10
Information in this document is subject to change without notice.
© Copyright 2024, DIGIEVER Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2200 UHD+ Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Digiever DS-2200 UHD+ Series

  • Page 1 Network Video Recorder Quick Installation Guide DS-2200 UHD+ Series 2.2.0.10 Information in this document is subject to change without notice. © Copyright 2024, DIGIEVER Corporation. All rights reserved.
  • Page 2: Table Of Contents

     Power on and Connecting ................9  Securing the Power Cord ................10  Connection to DIGIEVER NVR ..............12  Quick Configuration ..................16 Appendix......................17 LED Indicators at Front Panel ................17 LED Indicators at Rear Panel ................18...
  • Page 3: Safety Notice

    Quick Installation Guide Thank you for choosing DIGIEVER Network Video Recorder (NVR). The following quick guide will lead you to complete the installation and configuration of the NVR. Please read the following description carefully. Safety Notice The following safety precautions will increase the life of the NVR. Follow all precautions and instructions.
  • Page 4: Pre-Installation Notice

     Compatibility of hard disk with the NVR  1 slotted screwdriver and 1 Philips screwdriver *For camera compatibility, please check our website http://www.digiever.com/support/compatibility.php  Remote PC System Requirements The following are minimum system requirements for a personal computer to operate the NVR in better performance: ...
  • Page 5  Graphics Adapter AGP or PCI-Express, minimum 1024× 768, 16bit colors, 1G memory or above Note: It is highly recommended to use a graphics adaptor which provides higher than resolutions 1024x768 in order to experience the full benefits of the software. Make sure the display DPI setting is set to default at 96DPI ...
  • Page 6: Package Contents

     Package Contents   NVR (Network Video Recorder) Power Cord   Power Adapter RJ45 Network Cable   Screws for 2.5” HDD Screws for 3.5” HDD  Power Code Bracket...
  • Page 7: Hardware Description

     Hardware Description Front View Rear View Power LED Indicator System LED Indicator HDD LED Indicator Network LED Indicator USB backup button with LED Indicator 1 x USB 3.2 Gen 2x1 (for auto video backup) HDD 1 HDD 2 2 x 2.5 Gigabit LAN ports 10.
  • Page 8: Hard Disk Installation

     Hard Disk Installation Please follow the steps as illustrated below to install the hard disk: ① Press the button on the lower portion of the hard disk tray to release the latch. ② Using the latch, gently pull the disk tray out of the disk bay. ③...
  • Page 9 (2) 2.5-inch hard disks and SSD hard disks: Place the hard disk into the area of the disk tray outlined in red (see picture below). Make sure that the mounting holes on the bottom of the hard disk and disk tray are lined up. Secure the drive with four screws. ④...
  • Page 10: Power On And Connecting

    ⑥ Once the latch is secure, you can lock it by using the disk tray lock. Using a flathead screwdriver, turn the lock counterclockwise to lock the latch mechanism. Turning the lock clockwise will unlock it. Un-lock: Lock:  Power on and Connecting ①...
  • Page 11: Securing The Power Cord

    Turn on the server and there is a beep to indicate the NVR is in booting process. ③ Please wait for minutes until NVR beeps another time. The installation of NVR is complete right now.  Securing the Power Cord You can use the provided cord bracket to secure the power cord in place, if you are concerned about the power cord becoming detached when the NVR is moved.
  • Page 12 ② Attach the bracket to the power cord as shown in the graphic below ③ Remove the fan screw by unscrewing it counter-clockwise ④ Position the bracket over the hole for the removed fan screw. Secure the bracket in place by replacing the fan screw.
  • Page 13: Connection To Digiever Nvr

     Connection to DIGIEVER NVR There are 3 methods to connect to the NVR: Local display via HDMI connection Connect to the NVR through computer in local network environment Web browser Install NVR Search to quickly find NVR in the local network...
  • Page 14 Connect to the NVR through computer in local network environment Web Browser (Microsoft Edge, Chrome, Firefox, Opera) Step 1. Connect the NVR to the local network (router or switch) Step 2. Enter the NVR’s IP address in the web browser. Note: There are 2 methods to set network: Obtain an IP address automatically (NVR Default) ...
  • Page 15 Step 4. Download and install NVR-Client.exe, a software application, to execute liveview monitoring and video playback. Note: All browsers will be closed when installing the software application. Install NVR Search to quickly find NVR in the local network Step 1. Please download NVR Search from official website (or request from our sales team) and install it to client’s computer.
  • Page 16 Connect the computer to the NVR directly If you need to use a computer to set up the NVR in a non-networked environment, you can use the docking method. Step 1. Please connect NVR and computer via LAN cable. Step 2. Please set the computer IP segment to be the same as the NVR’s default network segment.
  • Page 17: Quick Configuration

     Quick Configuration After users log in NVR, the system will direct you to set Quick Configuration in 5 steps. Follow the instructions of the Overview of wizard to complete the system setup. Once 5-step Quick Configuration are completed, you can click “Start Live View”...
  • Page 18: Appendix

    Appendix LED Indicators at Front Panel LED Color & Status Indicate Power Off Blue Power On Power UPS power is from AC power mode to battery mode System is off or in sleep mode when UPS battery is too low Green blinking System goes on or goes off System...
  • Page 19: Led Indicators At Rear Panel

    LED Indicators at Rear Panel LED Position LED/State Indicate No connection/10Mbps connection LAN1 Speed LAN2 (Top LED) Orange 1G/100Mbps connection Green 2.5G connection LAN Link is not established LAN1 Link/Activity Green LAN Link is established LAN2 (Bottom LED) Green blinking LAN activity is occurring...
