Ryobi RLT26CDSN Original Instructions Manual

Ryobi RLT26CDSN Original Instructions Manual

Two stroke petrol line trimmer

Advertisement

RLT26CDSN
TWO STROKE PETROL LINE TRIMMER
ORIGINAL INSTRUCTIONS
Important!
It is essential you read the instructions in this manual before starting and
operating this machine.
Subject to technical modifications.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RLT26CDSN and is the answer not in the manual?

Questions and answers

Romeu Baptista
June 2, 2025

I need to replace the trimmer head on the machine. How to remove it?

1 comments:
Mr. Anderson
June 2, 2025

To remove the trimmer head on a Ryobi RLT26CDSN:

1. Stop the engine.
2. Disconnect the spark plug wire.
3. Remove the currently installed line trimmer head.

This ensures safety and allows for replacing or servicing the trimmer head.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for Ryobi RLT26CDSN

  • Page 1 RLT26CDSN TWO STROKE PETROL LINE TRIMMER ORIGINAL INSTRUCTIONS Important! It is essential you read the instructions in this manual before starting and operating this machine. Subject to technical modifications.
  • Page 2: General Safety Warnings

    English (Original Instructions) GENERAL SAFETY WARNINGS „ Dangerous Environments. To avoid falling, do not use the product in damp or wet locations. WARNING „ Controlling Product. During carburetor adjustments, the cutting attachment may spin. Read and understand all instructions. Failure to Therefore, you should wear protective equipment follow all instructions may result in serious personal and observe all safety instructions when adjusting...
  • Page 3 English (Original Instructions) SYMBOLS Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME EXPLANATION Indicates danger, warning or caution.
  • Page 4 English (Original Instructions) Rotational direction and maximum speed of the shaft for the RPM Decal cutting attachment. Run position. Set the choke lever to "Full" position. Place the engine switch to the "I" position. PRIME - press the primer bulb 10 times slowly. Pull the starter rope to start.
  • Page 5: Specifications

    English (Original Instructions) SPECIFICATIONS DESCRIPTION FIGURE 1 Weight without fuel 4.38 Kg 1. Upper shaft and trimmer head 2. Knob Weight without fuel 3. Button 4.60 Kg with trimmer head 4. Guide recess 5. Front handle Fuel tank volume 250 ml 6.
  • Page 6 English (Original Instructions) list are included. „ Push the button while pulling out the attachment. „ Inspect the tool carefully to make sure no breakage or ATTACHING THE FRONT HANDLE (FIG. 2) damage occurred during shipping. „ Loosen and remove the bolt (item 9), wing nut (item „...
  • Page 7: Operation

    WARNING And watch the video; Always shut off engine before fueling. Never add fuel to RYOBI: How to install trimming line on a Reel Easy™ a machine with a running or hot engine. Move at least head 9m from refueling site before starting engine. Do not...
  • Page 8: Maintenance

    English (Original Instructions) STARTING THE PRODUCT (FIG. 4-5) OPERATING THE TRIMMER (FIG. 6) Starting the product differs depending on whether the engine is cold or warm. Refer to the label on the air filter WARNING cover. Injuries may be caused, or aggravated, by prolonged TO START A COLD ENGINE use of a tool.
  • Page 9: General Maintenance

    English (Original Instructions) bottom of the air box cover into the latch at the bottom WARNING of the air box base; push the air box cover up until it Before inspecting, cleaning, or servicing the machine, latches securely in place. shut off engine, wait for all moving parts to stop, and disconnect spark plug lead and move it away from WARNING...
  • Page 10 English (Original Instructions) „ Clean all foreign material from the product. „ Store the product in a well-ventilated place that is inaccessible to children. Note: Keep the product away from corrosive agents such as garden chemicals. Important: Abide by all local and government regulations for the safe storage and handling of petrol.
  • Page 11: Troubleshooting

    English (Original Instructions) TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION 1. Switch set to the O (OFF) position. 1. Set switch to the I (ON) position. 2. No spark. 2. Remove the spark plug. Reattach the spark plug cap and lay the spark plug on the metal cylinder. Pull the starter cord and watch for a spark at the spark plug tip.
  • Page 12 Techtronic Industries (Australia) Pty. Ltd. Level 1, 660 Doncaster Road Doncaster, VIC 3108, Australia Techtronic Industries New Zealand Ltd. 18-26 Amelia Earhart Avenue Mangere, Auckland 2022, New Zealand 961473001-03...
