Installation Instructions
Model:
NJ24-HW-WH
NJ30-HW-WH
NJ36-HW-WH
NJ48-HW-WH
NJ60-HW-WH
NJ30-GO-WH
NJ60-GO-WH
READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Standard Time)
Vanity With Top
NJ24-NO-WH
NJ30-NO-WH
NJ36-NO-WH
NJ48-NO-WH
NJ60-NO-WH
NJ36-HW-WH-LED
NJ48-HW-WH-LED
Or Email: help@woodbridgebath.com
www.woodbridgebath.com
CA24-CG-MB
CA30-CG-MB
CA36-CG-MB
CA48-CG-MB
CA60-CG-MB
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Woodbridge NJ24-HW-WH
Summary of Contents for Woodbridge NJ24-HW-WH
- Page 1 Installation Instructions Vanity With Top Model: NJ24-HW-WH NJ24-NO-WH CA24-CG-MB NJ30-HW-WH NJ30-NO-WH CA30-CG-MB NJ36-HW-WH NJ36-NO-WH CA36-CG-MB NJ48-HW-WH NJ48-NO-WH CA48-CG-MB NJ60-HW-WH NJ60-NO-WH CA60-CG-MB NJ30-GO-WH NJ36-HW-WH-LED NJ60-GO-WH NJ48-HW-WH-LED READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Standard Time) Or Email: help@woodbridgebath.com...
- Page 2 19 5/8″ 2″ 2″ 2″ 8 7/8″ 8 7/8″ 20 1/2″ 20 1/2″ 20 1/2″ 8 7/8″ 8 7/8″ 8 7/8″ 8 7/8″ NJ24-HW-WH NJ30-HW-WH NJ36-HW-WH NJ24-NO-WH NJ30-NO-WH NJ36-NO-WH NJ30-GO-WH NJ36-HW-WH-LED 19 5/8″ 19 5/8″ 2″ 2″ 8 7/8″ 8 7/8″...
- Page 3 WOODBRIDGE REMOVE THE DRAWER metalbox wooden drawer metalbox wooden drawer 1. Position the cabinet securely on the stable platform and then pull out the drawer. 2. Use a cross screwdriver to loosen the reinforcement screw located at the bottom. 3. Loosen the screw and lift the drawer to get the drawer off the guide track.
- Page 4 WOODBRIDGE INSTALLING THE SHOWER WALL 8 1/2″ 8 1/2″ 33 1/2″ 25″ wall wall 1. It is recommended to position the cabinet at a counter height of 850mm above the ground. Position the hanging board at 45 degrees angle to the rear plate, then measure distance from the top end of the cabinet to the bottom of the hanging plate.
- Page 5 WOODBRIDGE INSTALLING THE SHOWER WALL +/- 1/8″ 1. Install the faucet on the basin. 2. Attach the drainpipe to the basin. 3. Apply silicone caulking to the top of the cabinet. 4. Use textured paper to fill the 3mm gap between the cabinet and the wall.
- Page 6 WOODBRIDGE INSTALLATION & ADJUSTMENT OF DRAWER CLICK CLICK metalbox wooden drawer 1. Place the drawer onto the track, push it inside until hearing the “click” sound, indicating it is properly installed. 2. To adjust the drawer, twist the edge of this screw, Turn it counterclockwise to the left or adjustable and clockwise to the right.
-
Page 7: Warranty
WARRANTY Woodbridge warrants its products as listed in below to be free of material and workmanship defect, subjected to the limitations set forth in this limited warranty. RESPONSIBILITIES OF OTHERS DISCLAIMER www.woodbridgebath.com... - Page 8 IMPORTANT! DO NOT USE: Abrasive cleaners such as: acid, ammonia, bleach, and similar solutions. Use of such solutions may cause corrosion, finish peeling, and/or dull the surface. DO NOT USE: Abrasive sponges or cloth. Never use steel, wool, or wired brushes that will permanently scratch the Please don't hesitate to contact us if you have any questions or concerns.
