R
WOODBRIDGE
INSTALLATION INSTRUCTIONS
SHOWER DOORS • TUB DOORS
MODELS:
SHOWER DOORS:
MSDF4876
MSDF6076
TUB DOORS:
MSDF6062
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Paci c Time)
Or Email: help@woodbridgebath.com
0119328 REV. 2
1
www.woodbridgebath.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Woodbridge MSDF4876
Summary of Contents for Woodbridge MSDF4876
- Page 1 WOODBRIDGE INSTALLATION INSTRUCTIONS SHOWER DOORS • TUB DOORS MODELS: SHOWER DOORS: MSDF4876 MSDF6076 TUB DOORS: MSDF6062 Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Paci c Time) Or Email: help@woodbridgebath.com 0119328 REV. 2 www.woodbridgebath.com...
-
Page 2: Tools Required
Please note that Woodbridge will not replace any damaged products or missing parts free of charge after 5 business days or if the product has been installed. Feel free to contact Woodbridge if you have any questions. - Page 3 WOODBRIDGE Threshold Requirement (Size): 2 1/4" www.woodbridgebath.com...
- Page 4 WOODBRIDGE Fixed Glass Glass Door 2.5mm Description Description 1 pcs Bumper Strip 1 pc Side PVC Strip 1 pc Screw M5X60 2 pcs Fixed Glass Handle 1 pc 2 pcs Glass Bracket 1 pc Glass Door 1 pc Upper Guide Rail...
- Page 5 WOODBRIDGE 1. Your Upper Guide Rail (15) and Anti-Splash Aluminum Threshold (9) have been precut for your shower model opening width: 48" or 60". If W-width of your wall to wall opening is equal to the size of your shower model, it is not necessary to cut the guide rail and threshold and you can continue to step 2.
- Page 6 WOODBRIDGE Figure 2 www.woodbridgebath.com...
- Page 7 WOODBRIDGE 2. Place the Anti-Splash Aluminum Threshold (9) to the shower tray or shower base. Using a level to adjust the threshold horizontal, make sure the threshold level. Figure 3 for details. Figure 3 Wall www.woodbridgebath.com...
- Page 8 WOODBRIDGE 3. Make the marks through the Anti-Splash Aluminum Threshold (9) for drilling. Now drill the holes with drill bit Φ8mm(Ø5/16"), and Apply silicone into the holes on the wall. Insert the Wall Anchor (7). Figure 4 for details. Figure 4...
- Page 9 WOODBRIDGE 4. Apply silicone from top to bottom along the back edge (edge facing the shower base) of Anti-splash Aluminum Threshold (9).Fasten the threshold to the shower base or shower tray with Round Head Screw M4X30 (6). Put the Screw Cover (5) to cover the screw in the threshold.
- Page 10 WOODBRIDGE 5. Use the allen key (21) to loose the screw on the guide rail bracket (20) and glass door stopper (19). Slide the stopper and then the bracket to the guide rail (15). Figure 6 for details. Figure 6...
- Page 11 WOODBRIDGE 6. Loose the screw of the Glass Bracket (14) and then align the screw hole of the glass bracket with the hole of the Fixed Glass (13), fasten the fixed glass with to Guide Rail (15). Figure 7 for details.
- Page 12 WOODBRIDGE 7. Put the Fixed Glass Assembly with the Guide Rail (15) into the slot of the Anti-Splash Aluminum Threshold (9). Figure 8 for details. Figure 8 Inside Wall Outside Outside Inside shower tray or shower base www.woodbridgebath.com...
- Page 13 WOODBRIDGE 8. Now, level your Upper Guide Rail(15) and tighten up the Glass Bracket (14) and Fixed Glass (13) with Alleny Key(21). Figure 9 for details. Figure 9 www.woodbridgebath.com...
- Page 14 WOODBRIDGE Outside Inside 9. Align the Upper Guide Rail (15) and make it horizontal, and then slide the Guide Rail Bracket (20) to attach to the wall. Outline the position of the guide rail bracket on the wall. Put the fixed...
- Page 15 WOODBRIDGE 10. Put the Fixed Glass Assembly into the Anti-Splash Aluminum Threhold (9) again, now slide the guide rail brackets toward the wall and push it against the wall. Use Allen Key (21) to tighten up the screws of the brackets.
- Page 16 WOODBRIDGE Outside shower tray shower base www.woodbridgebath.com...
- Page 17 WOODBRIDGE 1 3/16" Figure 12 11. Place the Guide Block (10) on the shower base or shower tray and parallel it to the Fixed Glass (13). It should not pass beyond the vertical edge of the glass. Take a measurement to ensure the distance between the front line of the glass and the center line of the Guide block is 1 3/16".
- Page 18 WOODBRIDGE 12. Slide the Side Anti-water Strip (16) to the Fixed Glass (13), remove the flapper that interferes with the Guide Rail (15). Outside Figure 13 for details. Inside Outside Inside Figure 13 13. Install the Handle (3) and Rollers (18) to the Glass Door (4), place Anti-Water Strip (16) and Bumper Strip (1) to the glass door as well.
- Page 19 WOODBRIDGE 14. Hang the Glass Door Assembly to the Guide Rail (15), make sure that the Rollers (18) are against the guide rail, now adjust the Glass Door (4) and slide the bottom edge of the glass door into the groove of the Guide Block (10).
- Page 20 MUST ALLOW SILICONE TO DRY FOR 24 HOURS BEFORE STARTING USING THE SHOWER Thank you for using WoodBridge products! Please don't hesitate to contact us if you have any questions or concerns. Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Paci c Time) Or Email: help@woodbridgebath.com...
-
Page 21: Installer Information
WOODBRIDGE NOTES NOTES INSTALLER INFORMATION INSTALLER INFORMATION DATE OF INSTALL: DATE OF INSTALL: INSTALLER’S NAME: INSTALLER’S NAME: PLUMBER: PLUMBER: CONTRACTOR: CONTRACTOR: LICENSE #: LICENSE #: www.woodbridgebath.com...
