  • Page 1 HBN30 / HBN50 OWNER’S MANUAL...
  • Page 2 ENGLISH...
  • Page 3 ENGLISH IMPORTANT SAFETY INSTRUCTIONS • It is essential that your equipment is used only WARNING indoors, in a climate controlled room. SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE DEATH OR SERIOUS INJURY CAN OCCUR ON THIS • Do not Drop dumbbells and kettlebell to the floor. EQUIPMENT.
  • Page 4 ENGLISH LOCATION OF THE HOW TO MOVE THE WEIGHT BENCH WEIGHT BENCH Raise the product by holding the handle and push FRONT backwards or forwards. Carefully move the bench to the Place the Bench on a level and desired location and then lower it. stable base.
  • Page 5 ENGLISH HOW TO ADJUST THE INCLINE / HOW TO FOLD THE HBN30 • DECLINE • Pull the pin and fold / unfold the front base. • There are a total 7 backrest positions. • Make sure hear the click sound and the pin is locked in the place.
  • Page 7 ENGLISH ENGLISH ASSEMBLY WARNING During the assembly process there are several areas that special attention must be paid. It is very important to follow the assembly instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed correctly, the weight bench could have frame parts that are not tightened and will seem loose and may cause irritating noises.
  • Page 8 ENGLISH HBN30 FOLDABLE BENCH LOCK PIN BACKREST CUSHION ADJUSTABLE ARM WHEEL SEAT CUSHION MAIN FRAME LOCK PIN LEG HOLDER...

  • Page 9: Pre-Assembly

    ENGLISH PRE ASSEMBLY PARTS INCLUDED: 1 Main Frame UNPACKING Unpack the product where you will be using it. Place the bench on a level flat surface. It is recommended that you place a protective covering on your floor. Never open box when it is on its side. NOTE: During each assembly step, ensure that ALL nuts and bolts are in place and partially threaded in before completely tightening any ONE bolt.
  • Page 10 ENGLISH HBN50 ADJUSTABLE BENCH BACKREST CUSHION WHEEL SEAT CUSHION BAND PEGS REAR BASE ADJUSTABLE ARM ADJUSTABLE ARM MAIN FRAME HANDLE...
  • Page 11 ENGLISH UNPACKING HARDWARE KIT INCLUDED: 2 Bolt (M8x45 mm) 8 Bolt (M8x25 mm) UNPACKING 2 Bolt (M10x125 mm) Unpack the product where you will be using it. Place the bench on a level flat 8 Flat Washer (M10) surface. It is recommended that you place a protective covering on your floor. 4 Curved Washer (M10) Never open box when it is on its side.

  • Page 12: Assembly Step

    ENGLISH ASSEMBLY STEP 1 Hardware For Step 1 Description BOLT (M10X25) CURVED WASHER (M10) LOCK NUT (M10) 1. Attach REAR BASE (AB1) and REAR BASE COVER (D05A), with 2 LOCK NUT (Z41), 2 BOLT (Z07) and 4 CURVED WASHER (Z22) to the MAIN FRAME (AD1). D05A...
  • Page 13 ENGLISH ASSEMBLY STEP 2 Hardware For Step 2 Description FLAT WASHER (M8) BOLT (M8X25) 1. Attach SEAT CUSHION (J02A), with 2 FLAT WASHER (Z21), J01A 2 BOLT (Z06) to the MAIN FRAME (AD1). 2. Attach BACKREST CUSHION (J01A), with 2 FLAT WASHER J02A (Z21), 2 BOLT (Z06) to the MAIN FRAME (AD1).
  • Page 14 ENGLISH ASSEMBLY STEP 3 ASSEMBLY COMPLETE! HBN50 HBN30 TECH SPECS Assembled Dimensions 145 x 41 x 127 cm / (L x W x H) 57” x 16” x 50” Product Weight 24 kg / 53 lbs. Max User Weight 120 kg / 264 lbs.
  • Page 15 ENGLISH GET START atZone Exercise with atZone via Bluetooth, scan QR code on the cover to download and for more information.

  • Page 16: Conditioning Guidelines

    ENGLISH CONDITIONING GUIDELINES STRETCH FIRST Before using your product, it is best to take a few minutes doing a few gentle stretching exercises. Stretching prior to exercise will improve flexibility and reduce chances of exercise related injury. Ease into each of these stretches with a slow gentle motion. Do not stretch to the point of pain.

  • Page 17: Troubleshooting

    ENGLISH TROUBLESHOOTING MAINTENANCE The safety considerations designed into the Bench Set Problem Solution can only be maintained when the equipment is regularly examined for damage and wear. Inoperable components Verify the following: should be replaced or the equipment should be put out of 1) The Bench is on a level surface.
  • Page 18 | ADJUSTABLE BENCH Horizon FOLDABLE BENCH | HBN30 | HBN50 Rev. 1.0 E | 1000522992 ©2024 Horizon Fitness...
