On/Off Flow Control Software - Matrix Process Control Manual

Software
On Off control
1
2
3
4
The file name for this program is 'Open OnOff-
Control.bat'.
The controls and displays are:
1) Program control - hit 'PLAY' to start
2) Flags for App running, communications work-
ing and App running.
3) RUN button
4) DRIVE output
5) LOAD output
6) System measured value
7) Graph area
8) Zero button (not all applications)
9) Properties
Before RUNning please select the Process Con-
trol application you are using in the properties
section.
5
8
6
