Terminal Connections - M-system R7F4DC-DC16B-H Instruction Manual

TERMINAL CONNECTIONS

Connect the unit as in the diagram below.
■ EXTERNAL DIMENSIONS unit: mm [inch]
■ CONNECTION DIAGRAM
Note: In order to improve EMC performance, bond the FE1 terminal to ground.
Caution: FE1 terminal is NOT a protective conductor terminal.
DA
DG
To other
DB
CC-Link
device
SLD
FE
138 [5.43]
123 [4.84]
115 [4.53]
1
NC
2
NC
3
GND
Output Y0
4
Y0
・
・
・
1
NC
・
・
2
NC
3
GND
Output YF
4
YF
1
PWR+
Power supply (IN)
2
PWR–
3
FE1
4
SNSR.EXC+
Exc. supply (IN)
5
SNSR.EXC–
1
PWR＋
Power supply (OUT)
2
PWR–
3
FE1
4
SNSR.EXC+
Exc. supply (OUT)
5
SNSR.EXC–
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
R7F4DC-DC16B-H
41 [1.61]
2-4.3 [.17] dia. 4 [.16] deep
DIN rail
(35mm wide)
(4 [.16])
EM-7767-P P. 6 / 7
