- Page 1 OPERATION AND INSTALLATION Sensor tap for pressurised (sealed unvented) DHW appliances » WSH 20 AU...
-
Page 2: Table Of Contents
CONTENTS | SpECiAl iNfOrmATiON SpECiAl iNfOrmATiON SPECIAL INFORMATION OPERATION General information �����������������������������������������3 Safety instructions ����������������������������������������������� 3 - The appliance may be used by children aged 8 Other symbols in this documentation ����������������������� 3 and older and persons with reduced physical, Units of measurement ������������������������������������������ 3 sensory or mental capabilities or a lack of ex- Safety ����������������������������������������������������������3 perience and know-how, provided that they... -
Page 3: General Information
OpErATiON General information OpErATiON Other symbols in this documentation Note General information is identified by the adjacent symbol. f Read these texts carefully. General information The chapters "Special information" and "Operation" are intended Symbol meaning for both users and qualified contractors. Material losses The chapter "Installation"... -
Page 4: Product Description
OpErATiON product description Product description Settings Operation of the sensor tap is contactless. The water is turned on Setting the temperature and off via a PCB with a proximity sensor. The PCB is powered by a battery. 1 Sensor and LED 2 Touch area Your qualified contractor can set a fixed temperature or limit the 3 Lever for temperature setting... -
Page 5: Standard Settings
OpErATiON Settings Symbols 4.3.2 Adjusting the sensor range The sensor range can be adjusted to suit the washbasin. This Symbol Description prevents the sensor tap from running independently. Touch the touch area Factory setting: distance 6 f Touch the touch area for 2 sec- Move your finger away from the touch area onds. - Page 6 OpErATiON Settings Deactivating the draw-off pause Setting continuous draw-off in minutes The pause is ended automatically after 2 minutes or by touching Set continuous draw-off from 0.5 to 20 minutes (in increments of the touch area for 2 seconds. 0.5 minutes). Factory setting: approx. 2 minutes f Touch the touch area for 2 sec- onds.
-
Page 7: Troubleshooting
OpErATiON Troubleshooting Troubleshooting 4.4.3 Hygiene flush 12/24/48 hours You can set a hygiene flush to take place 12, 24 or 48 hours after Observe chapter "Recalibrating the sensor" to restore the factory last use. settings. The hygiene flush time corresponds to the setting for continuous problem Cause remedy... -
Page 8: Changing The Battery
OpErATiON Cleaning, care and maintenance Changing the battery Supplement "Touch settings and programming" on the internet Note You can also find separate instructions for "Touch settings and programming" for the sensor tap on the internet. To view this, scan the QR code or paste this link into your browser: https://www.stiebel.com. -
Page 9: Installation
iNSTAllATiON Safety iNSTAllATiON Preparation Installation site Installation example: Safety Only qualified contractors should carry out installation, commis- sioning, maintenance and repair of the product. General safety instructions We guarantee trouble-free function and operational reliability only if original accessories and spare parts intended for the product are used. -
Page 10: Commissioning
iNSTAllATiON Commissioning 12. Settings If required, you can set a fixed temperature and a hot water stop at the sensor tap. 12.1 Setting a fixed temperature You can set a fixed temperature at the sensor tap. f Mount the strainer and make the cold water connection. 11. -
Page 11: Troubleshooting
iNSTAllATiON | ENVirONmENT AND rECYCliNG Troubleshooting 13. Troubleshooting 15.2 Data table WSH 20 AU problem Cause remedy 200215 Water does not run. The "draw-off pause" is Deactivate the "draw-off Application Washbasin activated. pause". Sealed unvented type The shut-off valve is Open the shut-off valve. closed. Type of installation Monobloc mixer tap Water is running contin- The solenoid valve is... -
Page 12: Warranty
Contact person: Customer Service Representative The Stiebel Eltron warranty for the unit is in addition to any rights E-mail: service@stiebel.com.au and remedies you may have under the Australian Consumer Law. - Page 13 NOTES www.stiebel-eltron.com WSH AU | ...
