5.2 Disassembly Sequence Chart

Use the chart below to determine the section number to be
referenced when removing computer components.
Section Description
5.3 Preparing the computer for disassembly
5.4 Computer feet
5.5 Mini PCI Communications Board
5.6 LED cover
5.7 Keyboard
5.8 Optical drive
5.9 Display
5.10 Heat sink
5.11 Processor
5.12 Top cover
5.13 Diskette drive
5.14 TouchPad
5.15 Hard drive
Hard drive bracket
5.16 Disk cell Real Time Clock (RTC) battery
5.17 Fan
Fan bracket
5.18 System board
Optical drive alignment rail
Maintenance and Service Guide
Table 5-1
Disassembly Sequence Chart
Removal and Replacement Procedures
# of Screws
Removed
0
0
1
0
2
1
7
5
0
15
2
1
3
0
2
7
5-3
