Connector Pin Assignments
Pin
Signal
1
Keyboard/mouse data1
2
Keyboard/mouse data2
3
Ground
Pin
Signal
1
Unused
2
Tip
3
Ring
A–2
Table A-3
Keyboard/Mouse
1
2
KEY
3
4
5
6
Pin
4
5
6
Table A-4
RJ-11 Modem
Pin
4
5
6
Signal
+5 VDC
Keyboard/mouse clock1
Keyboard/mouse clock2
Signal
Unused
Unused
Unused
Maintenance and Service Guide
