5.2 Disassembly Sequence Chart

Use the following chart to determine the section number to be
referenced when removing computer components.
Section
5.3
5.4
5.5
5.6
5.7
5.8
5.9
5.10
5.11
5.12
Maintenance and Service Guide
Disassembly Sequence Chart
Description
Preparing the computer for
disassembly
Battery pack
Optical drive
Hard drive
Computer feet
Memory expansion board
Mini PCI communications board
Disk cell RTC battery
Connector cover
LED cover
Keyboard
Heat spreader
Processor
Removal and Replacement Procedures
# of Screws Removed
0
2
1 to remove the hard
4 to remove the hard
0
1
1
0
2
2
0
7
0
drive
drive from hard drive
bracket
5–3
