bq25898, bq25898D, and bq25898C PWR730 Evaluation
This user's guide provides detailed testing instructions for the bq25898, bq25898D, and bq25898C
evaluation modules. Also included are descriptions of the necessary equipment, equipment setup, and
procedures.
Section 4
(BOM).
Throughout this user's guide, the abbreviations EVM, bq25898xEVM, and the term evaluation module are
synonymous with the bq25898, bq25898D, and bq25898C evaluation modules, unless otherwise noted.
Also, the abbreviation bq25898x refers to any of the three devices - bq25898, bq25898D, and bq25898C,
unless otherwise noted.
...................................................................................................................
