- Page 1 ABLOY DA300 SWING DOOR OPERATOR ® – Installation and commissioning manual Abloy Oy An ASSA ABLOY Group company...
-
Page 2: Approvals / Standards
APPROVALS / STANDARDS Electrical safety tested and approved FI, N, D Low Voltage directive 72/23/EEC as amended by the directive 93/68/EEC EMC directive 89/336/EEC prEN 12650... -
Page 3: Table Of Contents
Contents Revision..................3 General information..................4 Installation ................6 C o m m i s s i o n i n g ..............9 Operation.....................10 Internal monitoring................10 Self diagnostics...................11... -
Page 4: General Information
General information Warning Important safety instructions. It is important for the safety of persons to follow these instructions. Save these instructions. Not for fire door use. Features • Swing door operator for indoor use only. • Adjustable hold open time 0...60 s or sequential use. •... - Page 5 General information Technical data Measures Temperature range - (L) 453 x (H) 68 x (W) 82 mm - storage -20...70 °C - weight 3,1 kg - operation 0...40 °C Supply voltage Interfaces - 110 - 230 VAC (±15%) - power output 24 VDC max 500 mA 50...60 Hz - potential free relay output - back-up inlet 24 VDC (±15%) 2A...
-
Page 6: Installation
Standard Arm ABLOY 7190 ) Note the maximum - door weight 60 kg hinge line - door width 1000 mm - opening angle - on the closing side 100° The maximum frame depth is 100 mm. DA300 For closing side only. - Page 7 Installation Sliding Arm ABLOY DC194 hinge line Frame Minimum depth distance door width 0-50 50-100 100-150 For opening and closing side Note the maximum - door weight 40 kg - door width 1000 mm - opening angle - on the closing side 90° - on the opening side 110°...
- Page 8 Loose wires may cause unwanted contacts. - Always use safety sensors when needed. - Maximum length of the impulse device cables is 30 metres. - No battery charging is provided by DA300. +24 VDC 0.5 A output For e.g. a electric or safety sensor...
-
Page 9: Commissioning
Commissioning Check the free movement of the door. Turn mode switch to MAN. The mode switch is located in the head panel. Plug in the mains. The jumpers are located on the control board. Choose the type of the arm Jumper is connected Jumper is disconnected Choose the size of the door... -
Page 10: Operation
Operation MODE SWITCH The door opens by an impulse and closes AUTO after the adjusted hold open time. Manual use. OPEN The door opens and stays open. NOTE! There is 3 seconds constant delay when mode switch is changed from position open to auto or manual. -
Page 11: Self Diagnostics
Self diagnostics The means of diagnostic features is to - detect malfunctions - try to take care of safety during malfunction - get the operator to recover from the defected state. In case the result of the diagnostics shows unrecoverable malfunctions, the door operator is considered as unsafe, and the door is set free for manual use. -
Page 12: Connection Examples
Connection examples Safety sensors DA001 and DA002 On the opening side 1000 ohm Connect the 1000 ohm resistor from connectors 1 and 4 to safety sensor connectors 4 and 6 if dip-switch is on position “dark on” or 4 and 5 if dip-switch is on position “light on”. - Page 13 Connection examples DA063 Microwave radar white pink 1000 ohm yellow blue brown green DA061 and DA062 Microwave radar 1000 ohm...
- Page 14 Connection examples Electric locks EL412, EL414, EL512 black 1000 ohm blue green 8400 Microswitch keep black blue 1000 ohm Motorlocks 8904, 8910, 8329 green white...
- Page 15 Connection examples Motorlocks EL420, EL520 12-24VDC 12-18VAC S/N: AC /DC AC /DC BACKUP+ OPEN BACKUP - +12V DOOR WHITE CLOSED BLACK+VIOL. USED GREEN 1000 ohm HANDLE YELLOW Extension cable NOT USED ABLOY EA218, EL219 USED BROWN EA218 CYLINDER BLUE NOT USED RED/GREEN Length 6m/10m ORANGE...
- Page 16 ABLOY Oy is one of the leading manufacturers of locks, locking systems and architectural hardware and the world’s leading developer of products in the field of electromechanical locking technology. The ASSA ABLOY Group is the world’s leading manufacturer and supplier of locking solutions, dedicated to satisfying end-user needs for security, safety and convenience.
