D6061/D6071 Series
Unitrol Double Unit Push Side Power Operator
Installation Instructions
WARNING
This product can expose you to lead which is known to
the state of California to cause cancer and birth defects or
other reproductive harm. For more information go to
www.P65warnings.ca.gov.
6061/6071
Door Swing 85°
Minimum 36"
Door Width
Backplate - LH
(D6001BP-36-LH
D6001BP-38-LH
D6001BP-40-LH
D6001BP-42-LH
D6001BP-44-LH
D6001BP-46-LH
D6001BP-48-LH)
Closer Assembly
(7500LAP)
End Cap - LH
(6001ENLH)
Operator LAP
(6021LAP)
(D6001COV-36
D6001COV-38
D6001COV-40
D6001COV-42
Tools Needed
#7
1/4-20 3/8
Ratchet
with
10" or 12"
#2 and #3
11/16" socket
Copyright © 2023, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or in part
without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9360-1046-020 Rev 1 01/23
90° 95° 100° 105° 110°
35" 34" 34" 33" 33"
Conduit Assembly
Power Module
(D6001CON)
Sub-assembly
(6001PM)
Inverter
Power Supply
(6000IN)
(6000SUP)
Cover
D6001COV-44
D6001COV-46
D6001COV-48)
Supplied Fasteners per Operator
Safety Glasses
Set (Inch) Punch
Power Module Sub-assembly
Approved 2023-11-10
Power Module
Sub-assembly
(6001PM)
Power Supply
(6000SUP)
Inverter
(6000IN)
Union Spacer
(6001US)
Union Assembly
(D6001U)
NOTE: Fasteners shown are for
this specific installation.
(Fasteners for other installations
are included in the package)
13x
Conduit Assembly
End Caps Adjusting Tube
Union Assembly & Shoe
#8-32 x 5/16" 1/4-20 x 2"
Pour la version francaise voir NortonRixson.com.
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Backplate - RH
(D6001BP-36-RH
D6001BP-38-RH
D6001BP-40-RH
D6001BP-42-RH
D6001BP-44-RH
Operator LAP
D6001BP-46-RH (6021LAP)
D6001BP-48-RH)
Cover
(D6001COV-36
D6001COV-38
Union Spacer
D6001COV-40
(6001US)
D6001COV-42
Unitrol Arm
Standard Reveal
(6660-1) x2
Deep Reveal
(6670-1) x2
2x 2x
Union Spacer Union Door
#6-32 x 1/4" #4-40 x 3/8"
2x
1x 8x
Arm Operator LAP
1/4-20 x 1/2" 1/4-20 x 1/2"
Closer Assembly
(7500LAP)
End Cap - RH
(6001ENRH)
D6001COV-44
D6001COV-46
D6001COV-48)
2x
Backplate
1/4-20 x 1"
OR
7x
Backplate
#14 x 1-1/2"
5x
Backplate
1/4-20 x 5/8"
