- Page 1 ASSEMBLY MANUAL / OWNER’S MANUAL...
-
Page 2: Table Of Contents
Nautilus, Inc. | ® indicates trademarks registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Schwinn, the Schwinn Quality logo, Schwinn AD2, Bowflex, Nautilus, and Universal are trademarks owned by or licensed to Nautilus, Inc. -
Page 3: Important Safety Instructions - Assembly
IMPORTANT SAFETY INSTRUCTIONS This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Obey the following warnings: Read and understand all warnings on this machine. Carefully read and understand the Assembly instructions. •... - Page 4 • Make the Pedals stable before you step on them. Use caution when you step on and off the machine. • Keep the Pedals clean and dry. • Disconnect all power before servicing this machine. • Do not operate this machine outdoors or in moist or wet locations. Keep the foot pedals clean and dry. •...
-
Page 5: Safety Warning Labels / Serial Number
SAFETY WARNING LABELS AND SERIAL NUMBER / SPECIFICATIONS Serial number Product specifications Maximum User Weight: 113 kg (250 lbs.) Total Surface Area (footprint) of equipment: 7430 cm (1150 in Machine Weight: 37 kg (81.6 lbs.) 127 cm Power Requirements: 2 LR6 batteries (AA) (50”) Operational Voltage: 1.0 - 3.3VDC DO NOT dispose of this product as refuse. - Page 6 PARTS / HARDWARE / TOOLS Item Description Item Description Main Frame Handlebar, Right Front Stabilizer Handlebar, Left Rear Stabilizer Console Pedal, Right Seat Pedal, Left Seat Post Foot Peg, Right Transport Strap Foot Peg, Left Item Description Button Head Hex Screw M8 x 20 Curved Washer M8 Lock Washer M8 Tools...
-
Page 7: Assembly
ASSEMBLY 1. Attach Stabilizers to Frame Assembly 6 mm 2. Attach Pedals Note: The Left Pedal is reverse-threaded. Be sure to attach Pedals on the proper side of the Bike. Orientation is based from a seated position on the bike. The Left Pedal has an “L”, the Right Pedal an “R”. Pedal straps not shown for clarity. - Page 8 3. Attach Foot Pegs and Handlebar Arms 6 mm 4. Install batteries in Console Note: The console uses LR6 size batteries (AA). Make sure that the batteries point in the direction of the +/– indica- tors in the battery bay.
- Page 9 5. Attach the Console and Connect the Console Cable NOTICE: Do not crimp Console Cable.
-
Page 10: Final Inspection
6. Attach Seat to Seat Post and Install on Frame Assembly Note: Hardware is pre-installed on the seat and not on the hardware card. NOTICE: Be sure the Seat is straight and tighten the hardware. Make sure the adjustment knob (12a) engages the holes in the Seat Post. 7. -
Page 11: Leveling Your Machine
Leveling Your Machine If your workout area is uneven, you must level your machine. To adjust: Loosen the upper locking nut. Turn the leveler to adjust the height. Tighten the upper locking nut to lock the leveler. Do not adjust the levelers to such a height that they detach or unscrew from the machine. -
Page 12: Features
FEATURES Console Pedals Handlebars Adjustable Seat Assembly Fan Assembly Air Vents Stabilizers Foot Rests Transport Roller Magazine Holder Levelers Battery Bay... -
Page 13: Console Features
Console Features The Console provides information about your workout on the display screen. You can also use the button to get access to information about console settings. Front Back Battery bay Cable connector START/RESET Start Reset WARNING: If you feel any unusual pain, shortness of breath or dizziness, consult your physician. -
Page 14: Operations
What to Wear Wear rubber-soled athletic shoes. You will need the appropriate clothes for exercise that allow you to move freely. How Often Should You Exercise Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. -
Page 15: Workout Mode
Workout Mode The Console starts Workout Mode if the button is pushed, or if it receives a signal from the RPM sensor as a result of ped- aling the machine. The Time starts to count up from 0:00. Note: If the battery level is low, the Console display shows “Batt” for 10 seconds or until the button is pushed. The Console calculates the workout data as you exercise. -
Page 16: Service Mode
SERVICE MODE Service Mode lets you set the units of measure to either English Imperial or Metric, and see machine statistics and firmware version (for technician use only). When the Console is in Workout Mode or Pause Mode, push and hold down the button for 5 seconds to go into Ser- vice Mode. -
Page 17: Maintenance
MAINTENANCE Read all maintenance instructions fully before you start any repair work. In some conditions, an assistant is necessary to do the necessary tasks. Equipment must be regularly examined for damage and repairs. The owner is responsible to make sure that regular maintenance is done. -
Page 18: Maintenance Parts
Maintenance Parts Console Crank Covers Q RPM Sensor Handlebars Pedals Levelers Fan Assembly Shroud, Right Seat Fan Assembly Covers Shroud, Left Seat Post Footpegs M Drive Pulley Adjustment Knob Arm Pivots Drive Belt Transport Strap G Connector Arms O Speed Sensor Magnet Crank Arms Data Cable... -
Page 19: Troubleshooting
TROUBLESHOOTING Condition/Problem Things to Check Solution Console will not power Batteries Make sure batteries are installed correctly. If batteries are up/turn on/start correctly installed, replace with a set of new batteries. Check data cable integrity All wires in cable should be intact. If any are visibly crimped or cut, replace cable. - Page 20 Nautilus Bowflex Schwinn Universal ® ® ® ® 8016146.071517.A...
