Schwinn AirDyne AD Pro: Why is my machine making a weird noise?
Follow this troubleshooting guide to help resolve noise issues on the Schwinn AirDyne AD Pro.
Some common complaints may include:
Rubbing noises
Squeaking or creaking noises
Squealing noises
Clicking or clunking noises
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
6mm hex/Allen wrench
13mm, 15mm open-ended wrenches
1.
Make sure that your bike is placed on a solid and level surface. If needed, adjust the leveler feet to offset an uneven
surface. The leveler feet should be adjusted to be as low to the ground as possible while keeping your bike
level [13142.A].
2.
Check all hardware installed during the assembly process. Using your assembly tools included with your machine
(6mm Allen wrench and multi-sized wrench and screwdriver tool), tighten all hardware according to the assembly
instructions in the
3.
If the issue persists, refer to the "Replace the Shrouds and Footpad" section of
removing the shrouds. One by one, remove the shrouds with a Phillips head screwdriver and carefully realign them.
Make sure that they are not rubbing on any other parts after installing and that the hardware is securely
installed [13142.C]. If a shroud is damaged, please contact Customer Care for assistance identifying and replacing
your damaged part. Our contact information is located at the bottom of this page [13142.D].
4.
If the issue persists, cycle your machine for several revolutions while trying to determine the source of the noise. Pay
close attention to the connections of the components. See reference 1 for assistance with identifying possible source
of the noise. Once the source of the noise is determined, choose a noise troubleshooting topic below.
about:blank
Schwinn AirDyne AD Pro:  Why is my machine making a weird noise?
assembly manual [13142.B].
(Reference 1)
ID: 13142.1
the service manual for instructions on
