MARINA DESK
© design by metrica
READ INSIDE
ASSEMBLY INSTRUCTIONS,
HOW TO USE, USEFUL TIPS
FOR KEEPING YOUR TOOL
FOR TOGETHERNESS IN
SHAPE
PRODUCT
MARINA DESK – MAINTENANCE
LANGUAGES
EN - NL - DE - FR - IT - ES
MORE
WWW.EXTREMIS.BE

Advertisement

Chapters

loading
Need help?

Need help?

Do you have a question about the MARINA DESK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Extremis MARINA DESK

  • Page 1 © design by metrica READ INSIDE LANGUAGES ASSEMBLY INSTRUCTIONS, EN - NL - DE - FR - IT - ES HOW TO USE, USEFUL TIPS MORE FOR KEEPING YOUR TOOL FOR TOGETHERNESS IN WWW.EXTREMIS.BE SHAPE PRODUCT MARINA DESK – MAINTENANCE...
  • Page 2: Table Of Contents

    LANGUAGES ENGLISH P. 3 contents p. 3 assembly marina desk p. 4 maintenance p. 7 NEDERLANDS P. 9 inhoud p. 9 montage marina desk p. 10 onderhoud p. 13 DEUTSCH P. 15 inhalt p. 15 montage marina desk p. 16 pflege p.
  • Page 3 N = number of legs INHOUD - length between 1,95m - 4,05m = 2 legs - length between 4,75m - 7,55m = 3 legs - length between 8,25m - 11,05m = 4 legs - length 11,75m = 5 legs 10/12 x profiles 4 x tabletop end piece 2 x N x tabletop connection 2 x N x table leg...
  • Page 4: Assembly Marina Desk

    3. Put the 5/6 tabletop profiles on the floor, with the slots facing through 2 for each table leg assembly and put them aside. upwards, and make sure that the crosses are facing the same way. Insert a spacer between each profile at +/- 40 cm from the end. assembly marina desk...
  • Page 5 4. Insert the tabletop end piece with the lips into the slots from 5. Put the 2 tabletops nex to each other, with the slots facing left to right. Fasten them using 5/6 M5 x 12 countersunk bolts. upwards. Now fasten the table leg assembly with the tabletop Repeat this operation on the other side, this time from right connection to the profiles, each time at the intended place, to left.
  • Page 6: Maintenance

    The magic sponge can be used on tarpaulin fabric, plastic profiles, glass, steel, chrome, aluminium, porcelain, artificial leather and many types of floor. ° For more information, contact Extremis: info@extremis.be maintenance...
  • Page 7 english...
  • Page 8: Nederlands

    LANGUAGES ENGLISH P. 3 contents p. 3 assembly marina desk p. 4 maintenance p. 7 NEDERLANDS P. 9 inhoud p. 9 montage marina desk p. 10 onderhoud p. 13 DEUTSCH P. 15 inhalt p. 15 montage marina desk p. 16 pflege p.
  • Page 9: Inhoud

    N = aantal poten INHOUD - lengte tussen 1,95m - 4,05m = 2 poten - lengte tussen 4,75m - 7,55m = 3 poten - lengte tussen 8,25m - 11,05m = 4 poten - lengte 11,75m = 5 poten 10/12 x profielen 4 x eindstuk tafelblad 2 x N x tafelblad connectie 2 x N x tafelpoot...
  • Page 10: Montage Marina Desk

    Tussen elk profiel op +/- 40 cm van het uiteinde een dikte plaatje steken. montage marina desk...
  • Page 11 4. Schuif het tafelblad eindstuk met de lipjes in de sleufopeningen 5. Leg de 2 tafelbladen nu naast elkaar met de sleufopeningen van links naar rechts. Schroef deze vast met 5/6 M5 x 12 naar boven gericht. Monteer nu het tafelpootstel met de verzonken boutjes.
  • Page 12: Onderhoud

    De MiraClean kan gebruikt worden op zeil, pvc, glas, staal, chroom, aluminium, porselein, kunststofleer, en diverse vloeren, artificial leather and many types of floor. Voor meer informatie, contacteer Extremis via info@extremis.be onderhoud...
  • Page 13 nederlands...
  • Page 14: Montage Marina Desk

    LANGUAGES ENGLISH P. 3 contents p. 3 assembly marina desk p. 4 maintenance p. 7 NEDERLANDS P. 9 inhoud p. 9 montage marina desk p. 10 onderhoud p. 13 DEUTSCH P. 15 inhalt p. 15 montage marina desk p. 16 pflege p.
  • Page 15: Inhalt

    N = Anzahlt Beine INHALT - Länge zwischen 1,95m - 4,05m = 2 Beine - Länge zwischen 4,75m - 7,55m = 3 Beine - Länge zwischen 8,25m - 11,05m = 4 Beine - Länge 11,75m = 5 Beine 10/12 x Profile 4 x Endstück Tischplatte 2 x N x Tischplatteverbindung 2 x N x Tischbein...
  • Page 16: Montage Marina Desk

    Schritt 1 bis 2 für jedes Tischbeinpaar und stellen Sie diese Schlitzöffnung weist nach oben. Sorgen Sie dafür, dass die dann zur Seite. Kreuzchen nach derselben Seite zeigen. Stecken Sie ca. 40 cm vom Ende entfernt einen Abstandhalter zwischen jedes Profil. montage marina desk...
  • Page 17 4. Schieben Sie das Tischplattenendstück mit den Laschen in die 5. Legen Sie 2 Tischplatten nebeneinander, die Schlitzöffnung Schlitzöffnungen von links nach rechts. Schrauben Sie es mit weist nach oben. Montieren Sie jetzt jedes Tischbeinpaar mit 5/6 Senkkopfschrauben M5 x 12 fest. Wiederholen Sie das auf der Tischplattenverbindung mit 10/12 der anderen Seite, von rechts nach links.
  • Page 18: Pflege

    Flecken wie Filzstifte, Fett, Abriebspuren, Kalkflecken oder Kaffee und Tee Flecken. Den Schwamm kann benutzt werden auf Plane, Kunststoffprofile, Glass, Stahl, Chrom, Aluminium, Porzellan, Kunstleder und viele Arten von Boden. Für weitere Informationen, wenden Sie sich Extremis: info@extremis.be pflege...
  • Page 19 deutsch...
  • Page 20: Français

    LANGUAGES ENGLISH P. 3 contents p. 3 assembly marina desk p. 4 maintenance p. 7 NEDERLANDS P. 9 inhoud p. 9 montage marina desk p. 10 onderhoud p. 13 DEUTSCH P. 15 inhalt p. 15 montage marina desk p. 16 pflege p.
  • Page 21: Contenu

    N = nombre de pieds CONTENU - longeur entre 1,95m - 4,05m = 2 pieds - longeur entre 4,75m - 7,55m = 3 pieds - longeur entre 8,25m - 11,05m = 4 pieds - longeur 11,75m = 5 pieds 10/12 x profilés 4 x latte de finition pour plateau de table 2 x N x latte de finition pour banc 2 x N x pied de table...
  • Page 22 Déposez ensuite ces assemblages de pieds un moment sur le toutes orientées dans le même sens. Insérez une plaquette côté. d’épaisseur entre chaque profilé, à environ 40 cm de l’extrémité. montage marina desk...
  • Page 23 4. Glissez une latte de finition pour plateau à une extrémité des 5. Déposez les deux plateaux à côté de l’autre avec les gorges vers profilés du plateau en insérant bien les languettes dans les le haut. Prenez à présent les assemblages de pieds et déposéz- gorges de gauche à...
  • Page 24 Le MiraClean peut être utilisé sur bâche, PVC, verre, acier, chrome, aluminium, porcelaine, cuir synthétique et des sols divers. Pour plus d’informations, contactez Extremis: info@extremis.be entretien...
  • Page 25 français...
  • Page 26: Montage Marina Desk

    LANGUAGES ENGLISH P. 3 contents p. 3 assembly marina desk p. 4 maintenance p. 7 NEDERLANDS P. 9 inhoud p. 9 montage marina desk p. 10 onderhoud p. 13 DEUTSCH P. 15 inhalt p. 15 montage marina desk p. 16 pflege p.
  • Page 27 N = numero di gambe INHOUD - lunghezza tra 1,95m - 4,05m = 2 gambe - lunghezza tra 4,75m - 7,55m = 3 gambe - lunghezza tra 8,25m - 11,05m = 4 gambe - lunghezza 11,75m = 5 gambe 10/12 x profili 4 x terminale piano del tavolo 2 x N x giunzione gamba-piano del tavolo...
  • Page 28 Inserire uno spessore tra un profilo e l’altro a +/- 40 cm dall’estremità. montaggio marina desk...
  • Page 29 4. Spingere le linguette del terminale del piano del tavolo nelle 5. Posizionare i 2 piano del tavolo fianco a fianco con le scanalature de sinestra a destra. scanalature rivolte verso l’alto. Montare sui profili le coppie di Avvitare il tutto con 5/6 viti con testa svasata M5 x 12. gambe con la giunzione gamba-piano del tavolo nei punti Ripetere l’operazione per l’altro lato, de destra a sinestra.
  • Page 30: Manutenzione

    La spugna MiraClean può essere utilizzata sulla tela cerata, sui profilati in PVC, vetro, acciaio, cromo, alluminio, porcellana, pelle sintetica e diversi tipi di pavimenti. Per ulteriori informazioni, contattare Extremis: info@extremis.be manutenzione...
  • Page 31 italiano...
  • Page 32: Montaggio Marina Desk

    LANGUAGES ENGLISH P. 3 contents p. 3 assembly marina desk p. 4 maintenance p. 7 NEDERLANDS P. 9 inhoud p. 9 montage marina desk p. 10 onderhoud p. 13 DEUTSCH P. 15 inhalt p. 15 montage marina desk p. 16 pflege p.
  • Page 33: Contenido

    N = cantidad de patas CONTENIDO - longitud entre 1,95m - 4,05m = 2 patas - longitud entre 4,75m - 7,55m = 3 patas - longitud entre 8,25m - 11,05m = 4 patas - longitud 11,75m = 5 patas 10/12 x perfiles 4 x extremo de tablero de mesa 2 x N x conexión de tablero 2 x N x pata de mesa...
  • Page 34: Montaje Marina Desk

    1 a 2 para cada ensamblaje de las patas y guarde todo boca arriba y procure que las cruces estén orientadas hacia la aparte. misma dirección. Ponga un tirante entre cada perfil a +/- 40 cm del extremo. montaje marina desk...
  • Page 35 4. Introduzca el extremo de tablero con las lengüetas en las 5. Ponga los 2 tableros laterales con las ranuras boca arriba. ranuras da sinistra a destra. Fíjelo bien con 5/6 pernos Monte ahora el ensamblaje de las patas con la conexión de empotrados M5 x 12.
  • Page 36: Mantenimiento

    Se puede utilizar la esponja MiraClean en toldos, PVC, vidrio, acero, cromo, aluminio, porcelana, cuero sintético y diversos suelos. Para obtener más información, póngase en contacto con Extremis: info@extremis.be mantenimiento...
  • Page 37 español...
  • Page 38 tools for togetherness...
  • Page 40 All images, ideas, designs and design content are the intellectual property of Extremis and may not be copied, imitated or used, in whole or in part, without the prior written permission of Extremis.
