Summary of Contents for Extremis Manille
- Page 1 Manille Assembly instructions, how to use, useful tips for keeping MANUAL your tool for togetherness in shape. LAB192...
- Page 2 Tools for togetherness © All our designs are original creations and protected by intellectual property rights.
- Page 3 IMPORTANT! RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. BELANGRIJK! LEES DIT DOCUMENT AANDACHTIG EN BEWAAR HET VOOR TOEKOMSTIGE RAADPLEGING! WICHTIG! AUFHEBEN, UM SPÄTER ETWAS NACHSEHEN ZU KÖNNEN: SORGFÄLTIG DURCHLESEN! IMPORTANT! LISEZ ATTENTIVEMENT CE MANUEL ET CONSERVEZ-LE POUR RÉFÉRENCE ULTÉRIEURE!
- Page 4 Do not use power tools!
- Page 7 Table of contents Mounting kit Exploded view Assembly Manille Assembly floor fastening Assembly shade Assembly coupling...
-
Page 8: Mounting Kit
Mounting kit 16 x M8x25 6 x M8 Mounting kit to fix the Manille table MNL233 8 x M8x25 Mounting kit to fix the coupling MNL229... -
Page 9: Exploded View
Exploded view... - Page 10 Assembly Manille N° 13 30’ Put the tabletop on two trestless Make sure only the wood rests on the trestless, not the frame! Place the protective foil of the packaging on top of the tabletop...
- Page 11 Put one backrest on the protective foil with the leg connection facing upwards...
- Page 12 4. a MNL233 Repeat step 2 - 4 for the other leg 2 x M8x25 4. b (with floor fastening) MNL233 Repeat steps 2 - 4 for the other leg 2 x M8x25...
- Page 13 MNL233 Do this for both sides & remove the trestless 4 x M8x25...
- Page 14 MNL233 Screw the bolts about 5 mm into the tube 2 x M8x25...
- Page 15 MNL233 Screw the nuts about 5 mm onto the threads 3 x M8...
- Page 16 Slide the bench over the nuts and bolts of steps 6 & 7 Tighten the bolts and nuts Repeat steps 6 - 8 for the other bench...
- Page 17 9a. (without shade) 9b. (with shade)
- Page 18 Assembly shade 2’ Insert the four stainless steel tubes in the backrest...
- Page 19 Hook the shade onto the top of the stainless steel tubes...
- Page 20 Assembly Coupling N° 13 15’ MNL229 Attach the two coupling profiles into the tabletop frame 2 x M8x25 Use the first holes in the coupling profiles!
- Page 21 MNL229 2 x M8x25...
- Page 22 MNL229 Do this on both sides 4 x M8x25...
- Page 23 Repeat step 1 - 3 if you want the connect another Manille...
- Page 24 3. Slide the leg into the backrest as shown in the • Thorough cleaning with Extremis Wood Cleaner. diagram. • We strongly recommend that you treat your wood 4. a. Attach the leg to the backrest by inserting two with wood oil to protect it from stains - Small M8x25 bolts.
- Page 25 After a few years, there will be little cracks and ma- 2. Position the second Manille table to the coupling ybe some warping in your wood. This is completely profiles and attach them by inserting one M8x25 normal, because wood is a natural, living material.
- Page 26 Powder coating CLEANING Regularly Use Extremis Multicleaner, a 100% biodegradable detergent or common kitchen cleaning products. Avoid using aggressive products. These surfaces are best cleaned with a neutral cleaning product diluted in water. REPAIRING DAMAGED POWDER COATING When damaged The impact of sharp objects can damage the coating.
- Page 28 All rights reserved. Unless otherwise specified, all designs and photographs contained in this publication are copyright protected and are the property of Extremis. No part of this publication may be copied or distributed without Extremis’ prior written consent. The names of the authors of photographs to which we do not hold rights are mentioned here. We have done our utmost to provide a...
