ThinkSystem Micro DataCenter 6U 1200mm
Deep Rack Cabinet
User Guide
Machine Type: 7D3H and 7D3J

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7D3H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lenovo 7D3H

Summary of Contents for Lenovo 7D3H

  • Page 1 ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide Machine Type: 7D3H and 7D3J...
  • Page 2 First Edition (June 2020) © Copyright Lenovo 2020. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration (GSA) contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No.

  • Page 3: Table Of Contents

    Index ....59 Install the DPI universal rack power distribution unit....© Copyright Lenovo 2020...
  • Page 4 ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...

  • Page 5: Safety

    Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza. Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet. Antes de instalar este produto, leia as Informações sobre Segurança. © Copyright Lenovo 2020...

  • Page 6: Safety Statement

    Antes de instalar este producto, lea la información de seguridad. Läs säkerhetsinformationen innan du installerar den här produkten. Safety statement Read this section carefully before operating any task on the cabinet. R001 CAUTION: To ensure safety, all configurations of the rack cabinet must be certified by a nationally recognized testing laboratory to verify compliance with country-specific safety regulations.
  • Page 7 2. Remove the signal cables from the connectors. 4. Attach signal cables to other devices. 3. Remove all cables from the devices. 5. Connect power cords to their sources. 6. Turn ON all the power sources. © Copyright Lenovo 2020...
  • Page 8 S036 18 - 32 kg (39 - 70 lb) 32 - 55 kg (70 - 121 lb) > 55 kg (121 lb) CAUTION: Use safe practices when lifting. R006 CAUTION: Do not place any object on top of a rack-mounted device unless that rack-mounted device is intended for use as a shelf.
  • Page 9 Pack the rack cabinet in the original packaging material, or equivalent. Also, lower the leveling pads to raise the casters off the pallet and bolt the rack cabinet to the pallet. © Copyright Lenovo 2020...
  • Page 10 viii ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...

  • Page 11: Chapter 1. Introduction

    ThinkSystem Micro DataCenter 1200mm Deep Rack Cabinet is a 6U cabinet designed for Micro DataCenter servers. Figure 1. ThinkSystem Micro DataCenter 1200mm Deep Rack Cabinet The cabinet comes with a limited warranty. For details about the warranty, see: https://support.lenovo.com/us/en/solutions/ht503310 For details about your specific warranty, see: http://datacentersupport.lenovo.com/warrantylookup © Copyright Lenovo 2020...
  • Page 12 ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...

  • Page 13: Chapter 2. Specifications

    • SE350 E1 Enclosure (1U 2-node): up to four units of E1 enclosures with Toolless Friction Rail v2 for more information. https://thinksystem.lenovofiles.com/help/topic/SE350/pdf_files.html Note: This rack cabinet does not support SE350 E2 Enclosure (2U 2-node). See https:// for details about SE350 thinksystem.lenovofiles.com/help/topic/SE350/server_specifications.html configurations. • SR670: up to two units with vertical mounting kit © Copyright Lenovo 2020...
  • Page 14 ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...

  • Page 15: Chapter 3. Parts Listing

    Table 1. Rack cabinet components Rack cabinet frame Shipping bracket Wheeled trays Removable and reversible door Removable side panel Hardware box (see “Hardware box” on page Removable side panel Hardware box Figure 3. Components in the hardware box © Copyright Lenovo 2020...
  • Page 16 Table 2. Components in the hardware box 20 M6 screws One socket wrench 16 flange nuts One spud socket wrench 15 cable ties 20 G-type cage nuts One combination wrench Two bolt-down brackets ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...

  • Page 17: Chapter 4. Moving The Rack Cabinet

    WARNING: Failure to follow these instructions could result in equipment damage, severe injuries, or death. Before moving the rack cabinet, complete the following steps: 1. Unlock and open both doors by pulling up the handle and turning it clockwise. © Copyright Lenovo 2020...
  • Page 18 Figure 4. Opening the door 2. Remove the four shipping brackets that secure the cabinet to the pallet. Figure 5. Removing shipping brackets ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...

  • Page 19: Casters

    Two options are available when moving the cabinet: Casters S037 CAUTION: The weight of this part or unit is more than 55 kg (121.2 lb). It takes specially trained persons, a lifting device, or both to safely lift this part or unit. Complete the following steps to move the cabinet to the designated site: Step 1.

  • Page 20: Crane Lifter

    Figure 7. Adjusting the rack cabinet feet Step 2. Make sure the ramp board is lowered and balanced, and then push the cabinet from the rear until it reaches the designated site. Figure 8. Sliding the cabinet down from the pallet Notes: •...
  • Page 21 Attention - Drop hazard. Complete the following steps to lift and move the cabinet to the designated site: Step 1. Remove the four plugs from the four corners on the top of the cabinet frame. Figure 9. Lifting the rack cabinet Step 2.
  • Page 22 Figure 10. Loosening the nut b. Insert the open end of the combination wrench in the hardware box (see “Hardware box” on page 5) into the hexagonal head of the foot, and turn it clockwise until the foot makes firm contact with the floor.
  • Page 23 Figure 12. Tightening the nut 2. To secure the cabinet to the ground, you can install the bolt-down brackets that is included in the hardware box (see “Hardware box” on page Figure 13. Installing the bolt-down brackets Chapter 4 Moving the rack cabinet...
  • Page 24 ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...

  • Page 25: Chapter 5. Managing Cables

    See this section to learn how to connect ground cable in the rack cabinet. The following grounding pins close to door frame bottom are available for grounding cable connection. Grounding cable from the cabinet frame This cable is required for grounding. © Copyright Lenovo 2020...
  • Page 26 Figure 15. Grounding cable from the cabinet frame Grounding cable from the cabinet door This is an optional grounding cable. ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...
  • Page 27 Figure 16. Grounding cable from the cabinet door Grounding cable from the side panel This is an optional grounding cable. Chapter 5 Managing cables...
  • Page 28 Figure 17. Grounding cable from the side panel ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...

  • Page 29: Chapter 6. Installing Optional Kits

    In this section, however, it is illustrated with the top of server facing right as an example. P P r r o o c c e e d d u u r r e e Step 1. Remove the inner rails. © Copyright Lenovo 2020...
  • Page 30 Figure 18. Removing the inner rails ① Pull the inner rail outward until the release latch becomes visible. ② Press on the release latch. ③ Remove the inner rail from the outer rail. Step 2. Install the inner rails to the enclosure. Figure 19.
  • Page 31 ① Align the mounting holes in the inner rail with the corresponding rail mounting pins on the side of the enclosure. ② Push the inner rail as shown until the mounting pins on the enclosure lock into place with the inner rail.
  • Page 32 Figure 21. Installing the front mounting bracket to the EIA flange Note: Make sure the rail stays horizontal. ① Open the front bracket and align the front end of the outer rail to the EIA flange. ② Pull the outer rail into the EIA flange until the pins are inserted into the corresponding holes. ③...
  • Page 33 Figure 23. Rotating SE350 E1 Enclosure Step 9. Install the E1 Enclosure into the rack. Figure 24. Slide the E1 Enclosure into the rails in the rack. Chapter 6 Installing optional kits...
  • Page 34 Note: Make sure the top of the enclosure is facing right. ① Have the person on the front side support the weight, while the other person on the rear side align the enclosure to the slide rails. Position the enclosure as shown, and slide it into the rack. ②...

  • Page 35: Install The Rail Kit And Sr250

    Figure 26. Removing SE350 E1 enclosure ① Disconnect all the cables that are connected to the enclosure, and slide the enclosure out until it stops. ② Press the release latches to disengage the inner rails. ③ Have one person hold the front end of the enclosure, while the other person removes the enclosure. Install the rail kit and SR250 A A b b o o u u t t t t h h i i s s t t a a s s k k See the following table to identify the components that come with the rail kit.
  • Page 36 • Two units: 3U and 4U • Three units: 3U, 4U, and 5U • Four units: 3U, 4U, 5U, and 6U The cabinet supports up to four units of SR250 and corresponding rail kit. For optimal use of space, it is advised to determine the location to install the rail kits based on the number of units that are installed.
  • Page 37 Figure 28. Installing the inner rails to the enclosure ① Align the mounting holes in the inner rail with the corresponding rail mounting pins on the side of the server. ② Push the inner rail as shown until the mounting pins on the server lock into place with the inner rail.
  • Page 38 Step 4. Install the rear mounting bracket of the right outer rail to the lower EIA flange. Figure 30. Installing the rear mounting bracket to the EIA flange ① Align the rear pins on the outer rails to the EIA flange. ②...
  • Page 39 Step 6. Repeat the previous two steps to install the left outer rail to the upper EIA flange. Step 7. (Optional) If you need to ship the rack cabinet with servers installed or place the rack cabinet in a vibration-prone area, install two M6 screws into the mounting flanges between the two rear pins on both sides.

  • Page 40: Install The Rail Kit And Sr670

    Figure 34. Securing the server Rack release latches Front screw Remove the server from the rack Figure 35. Removing SR250 ① Disconnect all the cables that are connected to the server, and slide the server out until it stops. ② Press the release latches to disengage the inner rails. ③...
  • Page 41 The cabinet supports up to two units of SR670 and corresponding rail kit. For optimal use of space, it is advised to determine the location to install the rail kits based on the number of units that are installed. • One unit: 1-3U •...
  • Page 42 Figure 36. Removing screws from the rack mounting brackets Note: Do not fully remove the rack mounting brackets as they are required to secure the server into the vertical rack. Step 2. Secure the mounting glides to the server. Figure 37. Securing the mounting glides ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...
  • Page 43 ① Align the key hole slots in the glides to the T-head pins on both sides of the server, and slide the mounting glides forward until the pins are secured in the slots. ② Align the two holes on the mounting glide to the threaded standoffs on the front end of the server.
  • Page 44 Figure 39. Installing the upper C-channel ① Have one person hold and align the C-channel between the upper rack EIA flanges. ② Secure the front end of the C-channel to the front EIA flange with one M5 x 20 mm screw through the left most hole in the channel.
  • Page 45 Figure 40. Rotating the server Step 6. Lift the server with two people, and slide it into the C-channels. Figure 41. Installing the server into the rack cabinet Step 7. Tighten both the upper and lower captive thumb screws. Chapter 6 Installing optional kits...
  • Page 46 Figure 42. Securing the rack mounting brackets Step 8. Secure each rack mounting bracket with two M5 x 20 mm screws. ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...

  • Page 47: Install The Dpi Universal Rack Power Distribution Unit

    Figure 43. Securing the rack mounting brackets Install the DPI universal rack power distribution unit Follow the instructions in this section to install the DPI universal rack power distribution unit. A A b b o o u u t t t t h h i i s s t t a a s s k k See the following table to identify the components that come with the rail kit.
  • Page 48 One small mounting plate One cable management bracket One horizontal mounting plate One power distribution unit One 1U blank filler panel P P r r o o c c e e d d u u r r e e Step 1. Secure the power distribution unit to one side of the horizontal mounting plate with two screws.

  • Page 49: Installing Switches

    Installing switches See this section to learn how to install switches into ThinkSystem Micro DataCenter 6U 800mm Deep Rack Cabinet. This rack cabinet supports the following switches. See the corresponding links for installation instructions. • https://systemx.lenovofiles.com/help/topic/com.lenovo.thinksystem.ne0152t.doc/ts_ne0152t.html • https://systemx.lenovofiles.com/help/topic/com.lenovo.thinksystem.ne1032t.doc/ts_ne1032t.html • https://systemx.lenovofiles.com/help/topic/com.lenovo.thinksystem.ne2572.doc/ts_ne2572.html •...

  • Page 50: Installing Uninterruptible Power Systems (Ups)

    Note: Before installing NE1032T and NE1072T RackSwitch with corresponding rail-kit into the rack cabinet, tilt them slightly so that they can slide through the cabinet frame. Figure 46. Tilting the switch to fit in the cabinet Installing uninterruptible power systems (UPS) See this section to learn how to install uninterruptible power systems (UPS).

  • Page 51: Chapter 7. Hardware Removal, Installation And Conversion

    Complete the following steps to install the side panels. Step 1. Align the bottom of the panel to the slot on the bottom of the cabinet frame, and pivot the top of the panel towards the cabinet frame. © Copyright Lenovo 2020...

  • Page 52: Removing, Installing And Reversing The Doors

    Figure 48. Installing the side panel Step 2. Insert the key and turn it clockwise to secure the panel to the cabinet frame. Removing, installing and reversing the doors Follow the instructions in this section to remove, install, and reverse the doors. Remove the door Follow the instructions in this section to remove the cabinet door.
  • Page 53 Figure 49. Opening the door A A f f t t e e r r t t h h i i s s t t a a s s k k i i s s c c o o m m p p l l e e t t e e d d Step 1.

  • Page 54: Install The Door

    Figure 50. Removing the door Install the door A A b b o o u u t t t t h h i i s s t t a a s s k k Note: For safety, this task must be done by two people. P P r r o o c c e e d d u u r r e e Step 1.

  • Page 55: Reverse The Door

    A A f f t t e e r r t t h h i i s s t t a a s s k k i i s s c c o o m m p p l l e e t t e e d d 1.
  • Page 56 Figure 53. Opening the door P P r r o o c c e e d d u u r r e e Step 1. Pull up and hold both of the hinge shafts to disengage the door from the cabinet frame; then, remove the door.
  • Page 57 Figure 54. Removing the door Step 2. Remove the screws that secure the hinges to the cabinet frame. Step 3. Rotate both hinges 180 degree, switch the top and bottom hinges; then, install them to the opposite side of the frame. Chapter 7 Hardware removal, installation and conversion...
  • Page 58 Figure 55. Converting the cabinet frame hinges Step 4. If the cabinet comes with door position monitor devices, complete the following steps to remove and reinstall the devices. Remove the two screws that secure the door position monitor device to the cabinet frame. Figure 56.
  • Page 59 Figure 57. Installing the door position monitor device Remove the device from the door, and install it to the equivalent location on the opposite side of the door. Figure 58. Removing and installing the door position monitor device Step 5. Remove the screws that secure the handle to the door;...
  • Page 60 Figure 59. Installing the handle brackets Step 6. Align the door to the frame hinges, and push the shafts in to secure the door to the frame. ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...
  • Page 61 Figure 60. Installing the door A A f f t t e e r r t t h h i i s s t t a a s s k k i i s s c c o o m m p p l l e e t t e e d d 1.

  • Page 62: Door Position Monitor Device Replacement

    See this section for replacement of the door position monitor device. Note: This component is a Third Party Option parts. Not with standing anything to the contrary, third party options are excluded from Lenovo Statement of Limited Warranty. See https://support.lenovo.com/us/en/ for details.

  • Page 63: Remove The Door Position Monitor Device

    documentation on https://www.se.com : enter the part number in the search field, and select Documents and Software under Product information. Remove the door position monitor device A A b b o o u u t t t t h h i i s s t t a a s s k k 1.
  • Page 64 a. Close the cabinet door, and turn the door handle counterclockwise to secure it. Figure 65. Closing the cabinet door b. If necessary, insert the key and turn it counterclockwise to lock the door. ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...

  • Page 65: Appendix A. Getting Help And Technical Assistance

    Appendix A. Getting help and technical assistance If you need help, service, or technical assistance or just want more information about Lenovo products, you will find a wide variety of sources available from Lenovo to assist you. On the World Wide Web, up-to-date information about Lenovo systems, optional devices, services, and support are available at: http://datacentersupport.lenovo.com...

  • Page 66: Contacting Support

    Gathering information needed to call Support If you believe that you require warranty service for your Lenovo product, the service technicians will be able to assist you more efficiently if you prepare before you call. You can also see http:// for more information about your product warranty.

  • Page 67: Appendix B. Notices

    Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.

  • Page 68: Trademarks

    Trademarks Lenovo, the Lenovo logo, Micro DataCenter, ThinkSystem, Flex System, System x, NeXtScale System, and X Architecture are trademarks of Lenovo in the United States, other countries, or both. Intel and Intel Xeon are trademarks of Intel Corporation in the United States, other countries, or both.

  • Page 69: Index

    ThinkSystem Micro DataCenter 6U 1200 mm Deep Rack Cabinet 1, 3, 5, 7, 15, 19, 37, 39–40, 42, 45, 53 managing cables ThinkSystem Micro DataCenter 6U 800 mm Deep Rack Micro DataCenter Cabinet moving trademarks notices © Copyright Lenovo 2020...
  • Page 70 ThinkSystem Micro DataCenter 6U 1200mm Deep Rack Cabinet User Guide...
