Fill Valve
Refill manifold for use with Graco Auto-Fill Shut Off Valve only. For professional use only.
Part Number:
77X542
132230
5000 psi (34.4 MPa, 344.7 bar) Maximum Working Pressure
Part No. 132230: 3000 psi (20.7 MPa, 206.8 bar)
Important Safety Instructions
Read all warnings and instructions in this
manual and in Electric Dyna-Star and
Auto-Fill Shut Off Valve Instruction
manuals before using the equipment.
Save all instructions.
333393G
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 77X542 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Graco 77X542

Summary of Contents for Graco 77X542

  • Page 1 Instructions Fill Valve 333393G Refill manifold for use with Graco Auto-Fill Shut Off Valve only. For professional use only. Part Number: 77X542 132230 5000 psi (34.4 MPa, 344.7 bar) Maximum Working Pressure Part No. 132230: 3000 psi (20.7 MPa, 206.8 bar)
  • Page 2 Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.
  • Page 3 Warnings WARNING EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Do not operate the unit when fatigued or under the influence of drugs or alcohol. • Do not exceed the maximum working pressure or temperature rating of the lowest rated system component.

  • Page 4: Installation

    Installations with a drain hose connected to a Graco Compact Dyna-Star pump manifold requires the supplied check valve to be installed. See Installation for Compact Dyna-Star Pumps Only, page 6.
  • Page 5 Installation Fill Valve Component Installation Identification The reference letters used in the following instructions refer to the Typical Installation (F . 1, page 4), and the Fill Valve Component Identification (F . 2). 1. Select a clean, flat, and easily accessible location. 2.

  • Page 6: Operation

    Installation Operation Installation for Compact Dyna-Star Pumps Only Pressure Relief Procedure Install the check valve, the male thread side facing the pump and the female thread side facing the drain hose (L), into the pump refill vent port using bushings before Follow the Pressure Relief Procedure whenever connecting drain hose (L).
  • Page 7 Installation The reference letters used in the following instructions 6. Start the remote filling station pump (H). refer to the Typical Installation (F . 1, page 4), and the 7. When the reservoir (E) is filled: Fill Valve Component Identification (see F .

  • Page 8: Recycling And Disposal

    Recycling and Disposal Recycling and Disposal End of Product Life At the end of the product’s useful life, dismantle and recycle it in a responsible manner. • Perform the Pressure Relief Procedure, page 6. • Drain and dispose of fluids according to applicable regulations.

  • Page 9: Troubleshooting

    Troubleshooting Troubleshooting 1. Follow Pressure Relief Procedure, page 6, before checking or repairing the equipment. 2. Check all possible problems and causes before disassembling the equipment. Problem Cause Solution Refill pump slows down or stalls Auto-fill shut off valve has not reset. Relieve pressure by pulling the and no output at the fill valve.

  • Page 10: Dimensions And Mounting

    Dimensions and Mounting Dimensions and Mounting 333393G...

  • Page 11: Technical Specifications

    3000 psi +/- 10 percent 20.7 MPa, 206.8 bar +/- 10 percent Maximum fluid flow 2 gpm 7.57 lpm Outlet port size 77X542, 132230 3/4 NPT Vent port size 77X542, 132230 3/8 NPT Inlet ISO 7241-11, Series B standard hydraulic quick disconnect 1/4 in.

  • Page 12: California Proposition

    For the latest information about Graco products, visit www.graco.com. For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call to identify the nearest distributor. Phone: 612-623-6928 or Toll Free: 1-800-533-9655, Fax: 612-378-3590 All written and visual data contained in this document reflects the latest product information available at the time of publication.

This manual is also suitable for:

132230

Table of Contents
