Endress+Hauser Dosimag Brief Operating Instructions page 27

Dosimag
Version 1: Status input via connection A/B
A
2
8
3
1
7
6
5
A
+
E
-
 6 Connection to device
A Coupling: Supply voltage, Modbus RS485, status input
B Connector: Supply voltage, Modbus RS485, status input
C Coupling: Switch output (batch)
D Connector: Switch output (batch)
E PELV or SELV power supply
V1 Valve (batch), level 1
V2 Valve (batch), level 2
1 to Pin assignment
8
Endress+Hauser
RSE 8
M12x1
B
2
8
3
1
4 4
6
5
B
1
2
3
4
5
6
7
8
M12x1
5
4
7
Electrical connection
RSE 5
C D
1 1
2 2
3 3
C
D
1
2
3
4
5
5
4
V2
V1
A0053319
27
