Accessory, Instructions
SmartDisplay XT™
Add wireless communication to XT professional airless paint sprayers. For professional
use only.
Model: 20B432
Important Safety Instructions
Read all warnings and instructions in this
manual and related manuals before
using the equipment. Be familiar with the
proper control and usage of the
equipment. Save these instructions.
Related Manuals
Find English manuals and any available translations at
www.graco.com.
English
Manual
Description
Number
3A9095
490-650 XT Instructions
3B0070
695-1095, Mark IV-VII XT Instructions
3B0149
Contractor PowerShot Instructions
3B0111A
EN
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Graco SmartDisplay XT 20B432
Summary of Contents for Graco SmartDisplay XT 20B432
- Page 1 Be familiar with the proper control and usage of the equipment. Save these instructions. Related Manuals Find English manuals and any available translations at www.graco.com. English Manual Description Number 3A9095 490-650 XT Instructions...
-
Page 2: Table Of Contents
BlueLink App....... 5 Graco Standard Warranty....11 Operation with Contractor PowerShot XT . -
Page 3: Component Identification
Component Identification Component Identification Performance Mode Button Menu Button LED Display SmartDisplay Indicator Light Performance Mode Indicator Watch Dog Indicator Light 3B0111A... -
Page 4: Installation
Installation Installation Tools Required 4. Pull LED display module straight out from XT sprayer to disconnect and remove. • T20 Torx Tool. 1. Turn ON/OFF switch to the OFF position and unplug the power cord. 5. Insert new SmartDisplay XT onto XT sprayer. 6. -
Page 5: Bluelink App
Units equipped with BlueLink have a BlueLink Indicator Light on the SmartDisplay XT, see Component Identification, page 3. Download the Graco BlueLink app from the Apple App Store, Google Play, or other available application stores ® to connect to the paint sprayer via Bluetooth... -
Page 6: Operation With Contractor Powershot Xt
Operation with Contractor PowerShot XT Operation with Contractor PowerShot XT Pairing Contractor PowerShot 6. While “SEARCHING” is scrolling across display, press and hold both pressure adjustment buttons XT with SmartDisplay XT simultaneously on the PowerPak™ System until “GUN CONNECTED” scrolls across the display. For the additional features of the Contractor PowerShot Once connected, both buttons can be released and XT spray gun to work effectively, it must be paired with... -
Page 7: Disabling Smartstall
Operation with Contractor PowerShot XT Disabling SmartStall™ Unpairing Contractor PowerShot XT from For more information on the SmartStall feature, see the SmartDisplay XT Contractor PowerShot spray gun manual (3B0149). Upon first installation, the SmartDisplay XT will enable In some cases, it may be preferred to unpair the the XT sprayer to run with the SmartStall feature when Contractor PowerShot XT spray gun from a paired with a Contractor PowerShot XT spray gun. -
Page 8: Maintenance
3. Replace battery with a new CR2032 battery. Maintenance can be scheduled and tracked via the Graco SmartDisplay app. Replacing SmartDisplay Battery In order to keep your sprayer synced, your unit has a small battery built-in. -
Page 9: Compliance
Compliance Compliance Radio Frequency Approvals The enclosed device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:(1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 10: Technical Specifications
Technical Specifications Technical Specifications SmartDisplay XT Battery CR2032 3V Coin Cell Transmitter Protocol Trasnsmitter RF Frequency Band 2400-2483 MHz Maximum BLE Transmitter Power +8 dBm 3B0111A... -
Page 11: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective. - Page 12 Original instructions. This manual contains English. MM 3B0111 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2024, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...
