XTR
5 and XTR
Instructions/Parts
See Parts, beginning on page 8, for model numbers.
Maximum Working Pressure:
XTR 5: 5000 psi (35 MPa, 345 bar)
XTR 7: 7250 psi (50 MPa, 500 bar)
For use with protective coating materials
IMPORTANT SAFETY INSTRUCTIONS.
Refer to your sprayer instruction manual for pressure relief, prim-
ing, and spraying instructions. Keep these instructions.
IMPORTANT MEDICAL INFORMATION.
Keep the wallet-sized medical alert card provided with this gun
with the operator at all times. The card contains important treat-
ment information for the physician should a skin injection injury
occur. Additional cards are available at no charge.
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. Refer back
to these warnings. Additional product-specific warnings may be found throughout the body of this manual where
applicable.
SKIN INJECTION HAZARD
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This may look like
just a cut, but it is a serious injury that can result in amputation. Get immediate surgical treatment.
•
Do not spray without tip guard and trigger guard installed.
•
Engage trigger lock when not spraying.
•
Do not point gun at anyone or at any part of the body.
•
Do not put your hand over the spray tip.
•
Do not stop or deflect leaks with your hand, body, glove, or rag.
•
Follow the Pressure Relief Procedure when you stop spraying and before cleaning, checking, or
servicing equipment.
•
Tighten all fluid connections before operating the equipment.
•
Check hoses and couplings daily. Replace worn or damaged parts immediately.
™
7 Airless Spray Gun
WARNING
ING
312145J
ti5045b
II 2 G c T6
EN

Advertisement

Table of Contents
loading

Related Manuals for Graco XTR 5

Summary of Contents for Graco XTR 5

  • Page 1 7 Airless Spray Gun Instructions/Parts See Parts, beginning on page 8, for model numbers. Maximum Working Pressure: XTR 5: 5000 psi (35 MPa, 345 bar) XTR 7: 7250 psi (50 MPa, 500 bar) For use with protective coating materials IMPORTANT SAFETY INSTRUCTIONS.
  • Page 2 Warnings WARNING FIRE AND EXPLOSION HAZARD Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. Paint or sol- vent flowing through the equipment can cause static sparking. To help prevent fire and explosion: • Use equipment only in well-ventilated area.
  • Page 3 Warnings WARNING TOXIC FLUID OR FUMES HAZARD Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled or swallowed. • Read Safety Data Sheets (SDSs) for handling instructions and to know the specific hazards of the fluids you are using, including the effects of long-term exposure.

  • Page 4: Pressure Relief Procedure

    Pressure Relief Procedure Pressure Relief Procedure Grounding Follow the Pressure Relief Procedure whenever you see this symbol. The equipment must be grounded to reduce the risk of static sparking. Static sparking can cause fumes to ignite or explode. Grounding provides an escape wire for the electric current.

  • Page 5: Tip Installation

    Tip Installation Tip Installation Operation To avoid serious injury from skin injection do not put your hand in front of the spray tip when installing or removing the spray tip and tip guard. 1. Connect a grounded fluid hose. RAC Tip 2.

  • Page 6: Maintenance

    Maintenance Cleaning Tips/Clearing Clogs 5. Disengage trigger lock, then trigger gun into the paint pail. When solvent appears, release trigger. NOTE: Clean tip and tip guard at end of each work day. 6. Trigger gun into solvent pail. Circulate fluid until sys- 1.
  • Page 7 Repair Repair 3. Before installing trigger, grease the actuator pins (7) and the pivot pin (16a). XTR 5 Guns 1. Using a socket wrench, remove screw (16c) from each side of the gun body and remove trigger. Disassembly 2. Before installing trigger, grease the actuator pins 1.
  • Page 8 Parts Parts XTR5 16c† 16c† Flat Tip RAC Tip 13‡ ti10051a ti10050a ti21834a 312145J...
  • Page 9 Parts Quantity Ref. Part Description XTR500 XTR501 XTR502 XTR503 XTR504 XTR505 XTR510 15J771 BODY, gun 245881 SEAL, retainer assembly GASKET 15K000 CAP, end 117350 SPRING 15E088 RETAINER, needle 15E085 PIN, actuator 248591 NEEDLE 156766 GASKET 245858 SEAT, valve 255275 HANDLE; includes trigger guard and 13‡...
  • Page 10 Parts XTR7 312145J...
  • Page 11 Parts Quan- tity XTR700 XTR701 XTR702 XTR703 XTR704 XTR705 XTR706 17V677 Part Description 15E178 BODY, gun 17V381 BODY, gun 245881 SEAL, retainer assembly GASKET 15A864 CAP, end 117350 SPRING 15E088 RETAINER, needle 15E085 PIN, actuator 248591 NEEDLE 156766 GASKET 245858 SEAT, valve 248952 HANDLE KIT...
  • Page 12 Parts Quan- tity XTR700 XTR701 XTR702 XTR703 XTR704 XTR705 XTR706 17V677 Part Description 222385 TAG, warning (not 29 shown) 166969 GASKET 220251 GUARD, flat tip 163519 TIP, flat 194744 TOOL, repair, packing --- Not for sale.  Replacement Danger and Warning labels, tags, and cards are available at no cost. Parts included in Repair Kit 248837, purchased separately.

  • Page 13: Technical Data

    Technical Data Technical Data Maximum working pressure: XTR 5 5000 psi (35 MPa, 345 bar) XTR 7 7250 psi (50 MPa, 500 bar) Fluid orifice 0.090 in. (2.3 mm) Fluid inlet 1/4 npsm (m) or 3/8 NPT (XTR706) Max. fluid temperature 160°F (71°C)

  • Page 14: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
  • Page 15 Original instructions. This manual contains English. MM 312145 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC. AND SUBSIDIARIES • P.O. BOX 1441 • MINNEAPOLIS MN 55440-1441 • USA Copyright 2007, Graco Inc. All Graco manufacturing locations are registered to ISO 9001. www.graco.com...
