Graco Xtreme PFP Instructions-Parts List Manual

Instructions - Parts
Xtreme
For use with bulk supply of medium to high viscosity sealants and adhesive materials. For
professional use only.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Model 16T311
5 gallon (20 liter), XL6500
7250 psi (50 MPa, 500 bar) Maximum Fluid Working Pressure
100 psi (0.7 kPa, 7 bar) Maximum Air Working Pressure
100 psi (0.7 kPa, 7 bar) Maximum Air Inlet Pressure
Model 16P957
5 gallon (20 liter), XL6500
7250 psi (50 MPa, 500 bar) Maximum Fluid Working Pressure
100 psi (0.7 kPa, 7 bar) Maximum Air Working Pressure
100 psi (0.7 kPa, 7 bar) Maximum Air Inlet Pressure
Model 24X069
5 gallon (20 liter), XL10000
7250 psi (50 MPa, 500 bar) Maximum Fluid Working Pressure
100 psi (0.7 kPa, 7 bar) Maximum Air Working Pressure
100 psi (0.7 kPa, 7 bar) Maximum Air Inlet Pressure
Model 24X068
5 gallon (20 liter), XL10000
7250 psi (50 MPa, 500 bar) Maximum Fluid Working Pressure
100 psi (0.7 kPa, 7 bar) Maximum Air Working Pressure
100 psi (0.7 kPa, 7 bar) Maximum Air Inlet Pressure
®
PFP
™
air motor, with cart
™
air motor, no cart
™
air motor, with cart
™
air motor, no cart
Model 24X069 shown
Model 16T311 shown
II 2 G Ex h IIC 230°C (T2) Gb
3A2798L
EN
