Queen-size woven bed
Hide thumbs

Advertisement

Quick Links

Download this manual
Bristol Queen-Size Woven Bed
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions
and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Stock # DJ1346679071113
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenstyle.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2023-07-21
LOT NUMBER:
DATE PURCHASED:
Rev. 0001-A
/
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the dave jenny Bristol DJ1346679071113 and is the answer not in the manual?

Questions and answers

Related Manuals for Better Homes and Gardens dave jenny Bristol DJ1346679071113

Summary of Contents for Better Homes and Gardens dave jenny Bristol DJ1346679071113

  • Page 1 LOT NUMBER: DATE PURCHASED: Bristol Queen-Size Woven Bed Stock # DJ1346679071113 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 Pacific Standard Time: 8:30 a.m.

  • Page 2: Special Note

    IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-abrasive surface. You will need the parts identified on page 3 and 4 of this instruction manuals. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH DAMP CLOTH.
  • Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Headboard (Qty. 1) B- Footboard (Qty. 1) C- Mattress Side Rail (Qty. 2) D- Bottom Stretcher (Qty. 1) E- Left Post (Qty.
  • Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) 1/4” x 35 mm Bolt (2) 1/4” x 45 mm Bolt (Qty. 9+1 extra) (Qty. 14+1 extra) (3) Lock Washer (4) Flat Washer (Qty.
  • Page 5 Assembly Instructions ④ x 3 ② x 3 ③ x 3 NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. 1.
  • Page 6 Assembly Instructions ③ x 1 ④ x 1 ① x 1 4. Using the inserted wood dowels as a guide, align and attach the Bottom Stretcher (D) to the Left Post (E) with one 35 mm Bolt (1), one Lock Washer (3) and one Flat Washer (4).
  • Page 7 Assembly Instructions ④ x 1 ③ x 1 ① x 1 5. Repeat the same process to attach the Right Post (F) at the opposite end.
  • Page 8 Assembly Instructions ④ x 3 ② x 3 ③ x 3 6. Insert three 45 mm Bolts (2) with the Washers (3 and 4) through the countersunk holes on the Right Post (F) and securely screw into the threaded inserts on the Headboard (A).
  • Page 9 Assembly Instructions B/E/F The solid strip is located at bottom. ⑤ x 8 ③ x 8 ④ x 8 ② x 8 7. Ask for assistance to stand the assembled headboard upright and position it against wall and near the final location.
  • Page 10 Assembly Instructions ① x 7 11. Fasten the Slat Supports (H) underneath the Mattress Support Slats (G) with seven 35 mm Bolts (1). 12. Lay out the Mattress Support Slats (G) onto the strips on both Mattress Side Rails (C). Make sure that the end slats are located close to the posts.
  • Page 11 Assembly Instructions ⑥ x 14 13. Insert and screw the 35 mm Screws (6) into the countersunk holes on each slat. Tighten the screws using a Phillips screwdriver.
  • Page 12 Assembly Instructions Floor leveler 14. Adjust the floor levelers pre-attached at the bottom of the Slat Supports (H) to level the unit. 15. This bed can be used with or without a box spring.

  • Page 13: Quality Guarantee

    Care and Maintenance  Use a soft, clean cloth that will not scratch the surface when dusting.  Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area.  Using solvents of any kind on your furniture may damage the finish. ...
  • Page 15 NÚMERO de LOTE:__________ FECHA de COMPRA: Cama Queen Bristol con tejido Modelo # DJ1346679071113 ENSAMBLE REQUERIDO POR ADULTO Si tienen alguna pregunta acerca del ensamble o si alguna parte está faltante, no retorne esté producto a la tienda donde lo compro. Por favor llame a nuestro departamento de ayuda al cliente teniendo su instructivo y lista de partes para proveer el modelo, nombre de parte o el número de fábrica: 1-866-942-5362 Hora estándar del Pacífico: 8:30 a.m.
  • Page 16 IMPORTANTE Antes de comenzar: Abra, identifique y cuente todas las partes antes del ensamble. Coloque las piezas sobre una superficie plana y no abrasiva. Tendrá las partes identificadas en la página 3 y 4 de este manual de instrucciones. NOTA: ES MUY IMPORTANTE EL USO DE GOMA CON LAS CLAVIJAS DE MADERA.
  • Page 17 Lista de partes y material de ferretería Por favor lea completamente las instrucciones y verifique que estén todas las partes y partes de ferretería antes de iniciar el ensamblado. A- Cabecera (Cant. 1) B- Piecero (Cant. 1) C- Riel lateral del colchón (Cant. 2) D- Soporte inferior (Cant.
  • Page 18 Lista de partes y material de ferretería Por favor lea completamente las instrucciones y verifique que estén todas las partes y partes de ferretería antes de iniciar el ensamblado. (1) Perno de 1/4 de pulgada x 35 mm (2) Perno de 1/4 de pulgada x 45 mm (Cant.
  • Page 19 Instructivo de ensamble ④ x 3 ② x 3 ③ x 3 NOTA: Por favor no apriete completamente todos los pernos, hasta que termine con el ensamble de las partes. Una vez ensamblado, volver y apretar todos los pernos. Esto hará el ensamble de la unidad más fácil . 1.
  • Page 20 Instructivo de ensamble ③ x 1 ④ x 1 ① x 1 4. Usando las clavijas de madera insertadas como guía, alinear y adjuntar el soporte inferior (D) al poste izquierdo (E) con un perno de 35 mm (1), una arandela de presión (3) y una arandela plana (4).
  • Page 21 Instructivo de ensamble ④ x 1 ③ x 1 ① x 1 5. Repetir el mismo proceso para adjuntar el poste derecho (F) al lado opuesto.
  • Page 22 Instructivo de ensamble ④ x 3 ② x 3 ③ x 3 6. Insertar 3 pernos de 45 mm (2) con las arandelas (3 y 4) a través de los agujeros avellanados en el poste derecho (F) y atornillar en los insertos roscados en la cabecera (A).
  • Page 23 Instructivo de ensamble B/E/F La parte solida está en la parte inferior. ⑤ x 8 ③ x 8 ④ x 8 ② x 8 7. Pedir asistencia para poner la cabecera ensamblada en posición vertical y poner contra la pared y el lugar final.
  • Page 24 Instructivo de ensamble ① x 7 11. Sujetar los soportes para tablillas (H) abajo de las tablillas soporte del colchón (G) con 7 pernos de 35 mm (1). 12. Descansar las tablillas soporte del colchón (G) sobre las partes solidas en ambos rieles laterales del colchón (C).
  • Page 25 Instructivo de ensamble ⑥ x 14 13. Insertar y atornillar los pernos de 35 mm. (6) en los agujeros avellanados en cada tablilla. Apretar los pernos con el desarmador estrella.
  • Page 26 Instructivo de ensamble Nivelador de piso 14. Ajustar los niveladores de piso pre-adjuntados en la parte inferior de los soportes de las tablillas (H) para nivelar la unidad. 15. Esta cama se puede usar con o sin resortes.
  • Page 27 Mantenimiento y Cuidados  Use una toalla suave y limpia para evitar daños y rayaduras.  Uso de cera para pulir muebles no es necesario. Si desea usar cera, pruébela en un área que no sea visible para revisar su funcionamiento. ...
