- Page 1 Operating manual (Original) Duotour Page: Version: 2017/03/17 Edition: DT-OML-UK...
-
Page 2: Table Of Contents
Safety and security Safety plan CE Plus safety package * Emergency function (fire alarm) * 6.3.1 Sliding doors 6.3.2 Collapsible doors Power Failure 6.4.1 Off/night position 6.4.2 Sliding doors 6.4.3 Collapsible doors Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... - Page 3 6.16.2 Bi-stable Lock * 6.16.3 Espagnolet Lock * 6.16.4 Low temperature package * Service display Maintenance Daily Weekly Monthly Annually Troubleshooting Mechanical Electrical CE Compliance 10.1 Machine Directive 10.2 Low Voltage Directive Enclosures Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK...
-
Page 4: Introduction
This manual was prepared and issued by Boon Edam. All rights are reserved. The information in this manual is property of Boon Edam. Disclosure of this information or any part of it to third parties is not permitted, except with prior and express written permission of Boon Edam. -
Page 5: Abbreviations
• Duotour with Collapsible doors • Printed Circuit Board • Duotour with Sliding doors • Passive Infrared • Duotour with Sliding doors, without • Programmable Logic Controller showcase • Safety Rail Bent wall • End Buffer Sensor • Showcase Boon Sensor •... -
Page 6: Safety
Operational Safety The Duotour has an extensive number of safety features like: switches, safety buffers and active infrared sensors. These safety features are fixed at different places of the door to protect the users. If one of these safety features is activated the door will rotate slowly or stop immediately. -
Page 7: Operation Restrictions For High Wind Loads
Operation restrictions for high wind loads All Duotour door types are safe to use up to at least a wind load of 11 Beaufort. It is advisable to take the door out of use when the given maximum wind load is exceeded, in order to avoid damage or dangerous situations. -
Page 8: Maintenance Safety
It is not allowed to make changes or switch off any safety features without authorisation from Boon Edam. WARNING! All installation and maintenance work on the door must be carried out by Boon Edam personnel or by an approved agent. WARNING! The warranty of the product will end prematurely if the door is installed, maintained or modified by unapproved personnel. -
Page 9: Product Description
It provides simple, bi-directional, straight-line access and has a high capacity throughput of people. The Duotour is available with sliding doors or collapsible doors. The sliding door version is available with or without showcases. -
Page 10: Technical Specifications
• Disabled switch • Low temperature package • Tourlock 360N • Battery back-up (UPS) • Bi-stable Lock • CE Plus safety package • Espagnolet Lock • Various country specific safety packages Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 11: Operating Concept
There are two different control panels for the two different types of the Duotours. In addition an electronic control panel is fitted to all Duotour types consisting of a touch screen control panel that also functions as a Service display. -
Page 12: Off/Night Position Mode
In the winter position, both showcases block the daytime opening. 5.1.3 Sliding Door Mode: In the sliding door position, the showcases are positioned along the curved wall in such a way that the sliding door is exactly in the middle. Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 13: Collapsible Door Mode
Collapsible Door Mode: Collapsible doors open When the key switch is in the collapsible door position, the Duotour will stop according to the symbol and the collapsible lock will unlock. The DC-brakes will be activated after a short delay. The door wings can be collapsed by hand. -
Page 14: Touch Screen Control Panel (Service Display)
Touch screen control panel (Service display) In addition to changing the operation of the Duotour with the key switches, the Duotour has another possibility to customize the operation of the door by means of a touch screen control panel (Service display). -
Page 15: Sliding Door Function
• Duration :The time the door stays in the transport mode. Back Back • Forced resume :Forces the opening time to the set duration time. Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 16: Lighting Control
Pressing the Version button will display software version information. This information can be of DT Display use to the service engineer for possible trouble shooting. 02,000 DT PLC Main 5.2.6 Back 23,456 Pressing the Back button will return to the previous screen. DT PLC Sec1 23,456 DT PLC Sec2 23,456 Back Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 17: Operator-Presence Mode
10. Once the procedure is finished log out. control 11. Press the “Back” button to go to the main menu. Turn key switch to Night or Slid. mode. Press the Turn slow button after the counter 56 has expired. Caution, be sure the door is not blocked. Turn Slow Back Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 18: Cleaning Mode
Turn Slow Log out Press the “Back” button to go to the main menu. Operator‐ presence control Turn key switch to Night or Slid. mode. Press the Turn slow button after the counter 56 has expired. Caution, be sure the door is not blocked. Turn Slow Back Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 19: Safety And Security
Safety plan The Duotour has an extensive number of safety features like safety buffers and active infrared sensors. These safety features are installed at different places of the door to protect the users. If one of these safety features is activated the door will rotate slowly or stop immediately. -
Page 20: Ce Plus Safety Package
The motor brakes will be activated. When the fire alarm is over, the door wings will have to be set back in the operation position also by hand. The Duotour will then resume its last set operation mode. -
Page 21: Collapsible Doors
When the door stands completely still, the door wings can be collapsed by hand. When the emergency situation is over, the door wings will have to be set back in the operation position also by hand. The Duotour will then resume its last set operational mode. Page:... -
Page 22: Anti-Lock In Button
Service display. A delay (configurable) is then built in to avoid abuse of this function. In case the button is pressed and held for that delay, the Duotour will stop in the sliding door position and open the sliding doors. -
Page 23: Voice Module For Hbs
Code: 21 6.13 Safety sticker As a standard procedure Boon Edam applies safety stickers to the door set. These stickers notify users that children or minors must be supervised and accompanied by a responsible adult, and that the product should not be considered as a playground. -
Page 24: End Buffer Sensor, Rotating Section (Ebs)
The EBS on the stationary section is enabled when the distance between the door and the curved wall is less than 800 mm. When the EBS is activated, the door will stop turning immediately. Once the EBS is no longer activated, Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 25: Horizontal Boon Sensor (Hbs)
When the sliding doors are open and the sensor is activated the door will have a new pulse to open the sliding doors. Collapsible door mode • HBS slow and HBS stop • No function. Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 26: Threshold Sensor (Ths) For Sliding Door (Dts, Dtt)
When the sliding doors are no longer blocked at that point, they will continue to open at low speed. When the sliding doors are forced open, they will close normally when the opening time has expired. Both mechanisms can be set to 80N or 150N. Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 27: Safety Rail Door Wing (Srd)
The sliding doors will open, even when the sensor is activated. The SWS function is disabled when the door is operating in the Revolving Door Mode. Front Active Back Code: 26 Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 28: Showcase Boon Sensor (Sbs)
TL360N * The Duotour is equipped with a secured night access function, the TL360N. This system provides a controlled access over card reader (or similar) and a free exit by means of push button. When this “Pulse 360°” push-button is pressed (located on the end stile of the curved wall at the inside of the door and/or external (like at a reception desk)), the door will make one complete turn at normal speed and stop. -
Page 29: Espagnolet Lock
This lock is equipped with a limit switch, which deactivates the drive system. Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 30: Low Temperature Package
The heaters on the wheel and drive units keep the temperature of the gear oil and bearings at acceptable levels in order to reduce the rotating resistance. Set the thermostat to 10° Celsius. The heating system works fully automatic. Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... -
Page 31: Service Display
A Service display is fitted on the door style and gives information on the operation of the door. The current operation is shown when the Operation function is selected. Activations of safety sensors and problems are presented as normal text messages. When the Duotour has a failure, which makes it unsafe or impossible to Main Rev. - Page 32 Safety Rail Turning Wall (SRT), inside and outside • Horizontal Boon Sensor (HBS) (no audio signal in sliding door position) • Country specific safety sensors. The buzzer will sound with a frequency of 1.0 Hz. Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK...
-
Page 33: Maintenance
Do not use water near the drive unit and control box. This schedule may be used as a checklist for optimal maintenance of the Duotour. Please note that it is important that all maintenance actions are recorded. For this purpose a log book is provided with this Duotour. -
Page 34: Annually
Annually The Duotour needs to be serviced at least once a year. It is recommended to have the Duotour serviced by Boon Edam or an approved agent. Doors supplied with a service display: See service display for Boon Edam contact information. -
Page 35: Troubleshooting
WARNING! Use for replacement original parts, so that a correct operation is guaranteed. CAUTION! All installation and maintenance work on the product must be carried out by Boon Edam personnel or by an approved agent. CAUTION! Do not use water near the drive unit and control box. -
Page 36: Mechanical
• Loose mechanical parts or damaged • Localise the source of the unusual parts noise. • Consult your Boon Edam service department. Door turns slower than • Door set is turning heavily. • Switch the power off and find the usual cause of heavy turning. -
Page 37: 10 Ce Compliance
10 CE Compliance EC Declaration of Conformity According to the Machinery Directive (2006/42/EC), Annex II-1A Manufacturer Boon Edam BV Ambachtstraat 4 1135 GG Edam The Netherlands P +31 (0)299 380808 F +31 (0)299 372859 I www.boonedam.nl Declare under her responsibility that the powered pedestrian door... -
Page 38: Emc Directive
<= 16A per phase and not subject to conditional connection. NEN-EN-IEC 61000-6-2: Electromagnetic compatibility (EMC) – Part 6-2: Generic standards. Immunity for industrial environments. Product documentation by Royal Boon Edam International BV, Mr. Dingerdis, Techn. director. Page: Operating manual (Original) Version:... -
Page 39: Enclosures
11 Enclosures In this Chapter specific information regarding the Project can be added Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK... - Page 40 I www.boonedam.hk E info@boonedam.in I www.boonedam.in Boon Edam Ireland Ltd. Boon Edam Italy S.r.l. Boon Edam South East Asia Sdn Bhd. Unit 1 Naas Road Business Park Largo Augusto 8 No. 32A, Jalan Astaka U8/84A Muirfield Drive, Naas Road 20122 Milano...
- Page 41 Page: Operating manual (Original) Version: 2017/03/17 Duotour Edition: DT-OML-UK...
