Setting the torque Lowering the braking current to 5 Amp maximum (if necessary) Setting the braking force Tests for protective devices Tests Force and impact measurements Measuring equipment Measurement instruction Safety stickers Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
This procedure provides a start-up for the site engineer to successfully optimise the operation of the product in order to meet the safety requirements. Generally, the door will be pre-configured by Boon Edam and is almost ready for use after proper installation. User programmable settings have been set to their default values and most of them need no further adjustment.
Page 4
Check that the EBS operates in the correct area and that the EBS keeps on working till the trailing edge of the turning wall has passed the SRB. The area in which the EBS is active can be enlarged by giving the EBS position a positive value in the “Positioning” section. Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
Page 5
Frequency Inverter settings: The FI has the standard Boon Edam settings and needs no further adjustments. The settings can be adjusted for special circumstances or to suit special customer requirements. Quick check: Door must be stoppable with one hand, without triggering sensors.
Page 6
LED at the back, which is on when a signal is received. The third step is to align the receivers in the direction of the transmitter. After adjustment make sure the sensors are properly tightened. Check the HBS Slow and Stop functionality by interrupting the beam whilst the doorset is rotating. Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
Page 7
The width of the AIR field can be set using the click-in plastic cover in front of the detector’s lens. Narrowing the detector field to 1.3x0.2m, by fitting the covers in position A and D, is only necessary for the 3.6m Duotour. The detector field width without covers is 2.3x0.2m.
Page 8
If any further settings or calibrations are required, proceed as described in the following sections. Mechanical fine tuning AIR- field Setting of the inclination angle with the adjustment screw. Inclination: -5° …+7° continuously adjustable Radar field Manual settings of the inclination. Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
Page 9
Set the AIR exit contact logic to 1. • Set the Reglobeam address respectively to 1 and 2 In case of two sensors. AIR functions Symbol Parameter (Mode) Value (Data) AIR exit contact logic Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
Page 10
Check that the UPS powers the door in case of a main power loss. *= OPTION Faults: Check that no fault indications are shown on the service display. Commissioning checklist: Fill in the Commissioning checklist. Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
Appendix Generally, the door will be pre-configured by Boon Edam and is almost ready for use after proper installation. User programmable settings have been set to their default values and most of them need no further adjustment. However the following procedure will ensure a proper operation of the door after installation.
Setting the speed Adjust the speed to the required setting. The maximum speed recommended by Boon Edam for the Duotour is 0.6 m/s. Tests have proven that a pre-set speed of max. 0.6 m/s, in combination with a properly installed and adjusted CE safety package, ensures that the dynamic forces stay within permissible levels.
DIP-switch 3 must be switched ON for both rotating EBS sensors. This will set them to a different frequency than the stationary EBS sensors to avoid the possibility of ghosting. DIP-switch 4 must be switched ON for all EBS sensors. Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
The width of the AIR field can be set using the click-in plastic cover in front of the detector’s lens. Narrowing the detector field to 1.3x0.2m, by fitting the covers in position A and D, is only necessary for the 3.6m Duotour. The detector field width without covers is 2.3x0.2m.
Setting of the inclination angle with the adjustment screw. Inclination: -5° …+7° continuously adjustable Radar field Manual settings of the inclination. 0° …+90° in 5° steps -20° …+20° in 5° steps Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
Check the SRB, SRD and SRT-stop functionality whilst the door is rotating. The doorset must stop upon activation. TRS * For adjustment of the TRS please refer to the Duotour Installation and Maintenance Manual. Fire alarm action For the DTC check that the collapsible lock is free, when a fire alarm signal is present.
Note For situations where soft-switches need to be activated and setting values have to be changed, the door can be set up with the BEDiX wireless control unit. See Duotour Installation and Maintenance Manual for more information. Keys C-key (Cancel) •...
To ? Hold-open time Day 0…45 s (standaard 1 s) Tn ? Hold-open time Night 0…45 s (standaard 5 s) Tvn ? Delay time for switching over to Night 0…90 s Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
The torque is set with FI parameter Pr.19. Set parameter Pr.19 to 170V and clock the time needed for one revolution. Reduce the setting of parameter Pr.19 in steps of 10 Volt till the door speed drops noticeable. Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
(2 seconds maximum per revolution) than timed in step 1. Setting the torque in this way will ensure that the Duotour rotates with as little force as necessary. Ensure that smooth operation of the door is still guaranteed.
The CA reference body shall be positioned next to the opposing closing edge (position c). The test is passed when the reference body CA is not touched by the door set leaf. Protection area (area x). Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
Page 25
Contact with the flexible parts of the protective equipment is accepted. The test is passed when these criteria are met. Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
The purpose of the measurements is to ensure that the safety of the Boon Edam revolving door is in compliance with the European standard. The results of the measurement are to be registered by the site engineer in accordance with the attached "Commissioning Checklist".
All safety buffers and presence sensors fitted on the door must be operational during the measurement. The measurement for each distance should be carried out 3 times to get a reliable result. This brings the total number of measurements to nine for each door. Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
Page 28
Example of dynamic force test results Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
Safety sticker positions all doors Contrasting stickers The dotted stickers are to be applied in line with the safety sticker between 1400 and 1600 mm from the finished floor level. Contrasting sticker position Page: Quick Start-up Guide Version: 2014/05/20 Duotour Edition: DT-QSG-UK...
Page 30
T +91 (0)222 825 7582 I www.boonedam.hk E info@boonedam.in I www.boonedam.in Boon Edam Ireland Ltd. Boon Edam South East Asia Sdn Bhd. Boon Edam Nederland B.V. Unit 1 Naas Road Business Park No. 32A, Jalan Astaka U8/84A Postbus 26, 1135 ZG Edam...
