yellow jacket HORNET RecoverXLT Operation And Maintenance Manual

Oil-less universal refrigerant recovery system

Advertisement

Quick Links

HORNET RecoverXLT
®
Oil-Less Universal Refrigerant Recovery System
Operation and Maintenance
Manual for 95760 and 95762
NOW UP TO 25% FASTER RECOVERY RATES
(For serial numbers
22180065
and higher)
English, Spanish, French and German manuals available at:
https://yellowjacket.com/.
PN 151204 RevD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HORNET RecoverXLT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for yellow jacket HORNET RecoverXLT

  • Page 1 HORNET RecoverXLT ® Oil-Less Universal Refrigerant Recovery System Operation and Maintenance Manual for 95760 and 95762 NOW UP TO 25% FASTER RECOVERY RATES (For serial numbers 22180065 and higher) English, Spanish, French and German manuals available at: https://yellowjacket.com/. PN 151204 RevD...
  • Page 2: Table Of Contents

    Warranty Information……………………………….……………………….…………..10 General Safety Instructions ® 1) Know your equipment. Read and understand the Use the HORNET RecoverXLT only in operation manual and the labels affixed to this locations where mechanical ventilation which unit. Learn the applications and limitations, as...
  • Page 3: Care And Maintenance Auto Purge Instructions

    ® 13) Use the HORNET RecoverXLT only with Caution: All refrigerant hoses, recovery tanks, the proper refrigerants. (See specifications for refrigerant lines, other vessels containing refrigerants ® a complete list of compatible refrigerants.) and the HORNET RecoverXLT should be handled as if under high pressure. When opening a ®...
  • Page 4: Hornet

    10. Open the Utility and either High Side or Low ® Because the HORNET RecoverXLT is capable Side valves on the manifold. Remember it is of recovering direct liquid, it is best to first recover more efficient to recover the liquid refrigerant all of the liquid, followed by the vapor.
  • Page 5: Push-Pull Liquid Recovery

    1) Turn off power to the system to be serviced. The auto purge feature makes the reconfiguration ® 2) Hook up the HORNET RecoverXLT , the to vapor recovery easier and faster to do. system to be recovered, and the recovery tank Some HVAC systems will not allow for the push- as shown in the diagram above.
  • Page 6: Recovery Tips & Techniques

    This connector to the hose going to the Suction is critical to avoid contamination and know ® Port of the HORNET RecoverXLT how much refrigerant will be recovered. The ® first job of the day usually means a fresh,...
  • Page 7: Troubleshooting Guide

    15 inHg *UL Certified Rates to ARI Standard 740-2016 ® Other Refrigerants - The HORNET RecoverXLT is approved for use with other refrigerants which have not been certified for a particular recovery rate including, but not limited to: R-1234yf, R -32, R-401A, R401B, R-402A, R-402B, R-404A, R-406A, R-407A, R-407B, R-407C, R-407D, R- 408A, R-409A, R-411A, R-411B R-454B.
  • Page 8: Wiring Diagrams

    Technical Data, cont. Compressor: 1.25 HP 2 Cylinder Oil-less Reciprocating, Air Cooled Power Source: 100-240VAC 1ph 50/60Hz Amperage: 12.0 amps Motor Type: Variable Speed Brushless DC, 1200-3000 RPM Height: 12.50” Size: Width: 19.25” Depth: 12.50” Weight: 26.7 lbs. Wiring Diagrams...
  • Page 9: Replacement Parts

    REPLACEMENT PARTS HORNET Recov- Part # Description Part # Description 95156 12A Breaker 95575 XLT Compressor ONLY 95210 Strain Relief 95215 Power Cord 95573 Momentary Rocker Switch 95451 Gauge High 95217 Rubber Feet 95452 Gauge Low 95444 Case Front 95453 Manifold Assembly 95445 Case Back...
  • Page 10: Important Notice To Purchaser

    IMPORTANT NOTICE TO PURCHASER Check for damage immediately. Prior to Engineering Company, Inc. will cooperate in ® shipment, all YELLOW JACKET HORNET assessing damage if the recovery system is ® RecoverXLT Refrigerant Recovery Systems are returned to the factory prepaid.
