Table of Contents

π
H-11333
LOVESEAT
TOOL NEEDED
4 mm T-handle Hex Key
(included)
Arm x 2
1.
Using one 1¾" bolt, attach arm to leg. Repeat on
opposite side. (See Figure 1)
Figure 1
Arm
PAGE 1 OF 6
1-800-295-5510
uline.com
Seat x 1
Back x 1
1¾" Bolt
Leg
PARTS
Leg x 2
ASSEMBLY
2. Attach back leg to seat using 1¾" bolt in top hole.
Attach front leg to seat using two 2" screws. Repeat
on opposite side. (See Figures 2-3)
Figure 2
Top Hole
1¾" Bolt
2" Screws
Figure 3
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
1½" Bolt x 2
2" Screw x 6
1¾" Bolt x 4
3" Screw x 2
1¾" Bolt
2" Screws
0224 IH-11333
