3.9. PIO Support

Current support allows you to define Programmable IO (PIO) Assembler blocks and using them in the PIO peripheral, more
documentation around PIO can be found in
C/C++ SDK book.
The Raspberry Pi Pico MicroPython introduces a new
PIO program, and the configuration of the state machine, into 2 logical parts:
•
The program definition, including how many pins are used and if they are in/out pins. This goes in the
definition. This is close to what the
in Python).
•
The program instantiation, which sets the frequency of the state machine and which pins to bind to. These get set
when setting a SM to run a particular program.
The aim was to allow a program to be defined once and then easily instantiated multiple times (if needed) with different
GPIO. Another aim was to make it easy to basic things without getting weighed down in too much PIO/SM configuration.
Example usage, to blink the on-board LED connected to GPIO 25,
Pico MicroPython Examples:
1 import
2 from
3 from
4
5 # Define the blink program.
output pin.
6 # Use lots of delays to make the blinking visible by eye.
7 @asm_pio(set_init=rp2.PIO.OUT_LOW)
8 def blink():
9 wrap_target()
10 set(pins, 1)
11 nop()
12 nop()
13 nop()
14 nop()
15 set(pins, 0)
16 nop()
17 nop()
3.9. PIO Support
