Absenicon X-Series Widescreen User Manual
Absenicon
X-Series Ultrawide Screen User
Manual
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the Absenicon X Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Absen Absenicon X Series

  • Page 1 Absenicon X-Series Widescreen User Manual Absenicon X-Series Ultrawide Screen User Manual - 1 -...
  • Page 2: Table Of Contents

    Absenicon X-Series Widescreen User Manual Catalogue Safety Information ....................................... 3 1. Product Presentation ....................................6 1.1 Main characteristics of products ............................. 7 1.2 Product Specification ...................................8 1.3 Screen body size drawing (mm) ............................10 1.3.1 X151 Screen Body Size Drawing (mm) ..........................10 1.3.2 X178 screen body size drawing (mm) ..........................
  • Page 3: Safety Information

    Follow safety instructions in this manual and on the product. If you have any questions, please seek help from Absen. Beware of Electric Shock! • To prevent electric shock the device must be properly grounded during installation, Do not ignore using the grounding plug, or else there is a risk of electric shock.
  • Page 4 Absenicon X-Series Widescreen User Manual • The AC power used in this product must comply with local building and electric codes, and should be equipped with overload and ground fault protection. • The main power switch should be installed at a location near the product and should be clearly visible and easily reached.
  • Page 5 Absenicon X-Series Widescreen User Manual functions to look at the screen to avoid burning the eyes Product Disposal • Any component that has a recycling bin label can be recycled. • For more information on collecting, reusing and recycling, please contact the local or regional waste management unit. •...
  • Page 6: Product Presentation

    Absenicon X-Series Widescreen User Manual 1. Product Presentation Absenicon X Series widescreen is an ultra-high-definition micro-pitch intelligent display terminal created by Absenon based on Micro LED display technology. Available in 151", 178" and 205" screen sizes, the series is suitable for displaying on-screen content in a 21:9 ratio for a more natural and efficient hybrid meeting experience.
  • Page 7: Main Characteristics Of Products

    1.1 Main characteristics of products 1、Micro LED display technology to real picture quality experience Absenicon X series widescreen products use flip COB packaging technology and Micro LED display technology, compared with traditional SMD display, all-round improve the display effect, with 15,000: 1 contrast, color gamut is 90% BT2020 film breadth, with ≥3840 refresh rate and 14 bit gray scale level, more accurately restore corporate logo, brand identity and color scheme.
  • Page 8: Product Specification

    9、Split screen mode supports a variety of display layouts Through innovative system UI design, Absenicon X Series widescreen enables the screen to present a variety of screen layouts, including full screen mode, standard split screen mode, left and right split screen mode and auxiliary split screen mode.
  • Page 9 Absenicon X-Series Widescreen User Manual Gray scale(Bit) Refresh Rate(Hz) 3840 Viewing 160/160 Angle(H/V) (°) AC Operating AC 100~240 Voltage(V) Electric mean power (W) parameter maximum power 1500 2100 2700 Android system Android11.0 Wifi Support WiFi 6.0 Bluetooth Support Bluetooth 5.0 64-bit quad-core 1.8 GHz CPU System System memory...
  • Page 10: Screen Body Size Drawing (Mm)

    Absenicon X-Series Widescreen User Manual 1.3 Screen body size drawing (mm) 1.3.1 X151 Screen Body Size Drawing (mm) lateral view front view back view 1.3.2 X178 screen body size drawing (mm)
  • Page 11: X205 Screen Body Size Drawing (Mm)

    Absenicon X-Series Widescreen User Manual lateral view 侧视图 front view 正视图 正视图 正视图 正视图 back view 1.3.3 X205 Screen body size drawing (mm)
  • Page 12 Absenicon X-Series Widescreen User Manual front view lateral view back view...
  • Page 13: Standard Packaging

    Absenicon X-Series Widescreen User Manual 1.4 Standard packaging 1.4.1 X151 standard packaging X151 is mainly packed in two flight case  Case No. 1 includes unmodular case, edge wrapping, control case and wall hanger. The specifications  and dimensions are 950*765*1692mm Case No.
  • Page 14: X205 Standard Packaging

    Absenicon X-Series Widescreen User Manual 1.4.3 X205 standard packaging X178 is mainly packed in two flight case  Case No. 1 contains unmodular case, fitting tool, control case and spare parts. The  dimensions are 987*745*1785mm Case No. 2 includes module, wire, wrapping, sequencer and wall hanger. The specifications ...
  • Page 15: Product Installation

    Absenicon X-Series Widescreen User Manual 2. Product Installation This product only supports wall mounting Suggested thickness from the wall: 40 mm for the screen body, 51 mm for the wall bracket plus the corner code, at least 96 mm is recommended. 2.1 Installation Instructions This product adopts the whole machine calibration, in order to ensure the best display effect, it is recommended to install according to our company logo sequence number.
  • Page 16 Absenicon X-Series Widescreen User Manual 2.2.2 Installation of the back frame fixing angle code (1)Instructions for installing the backstay fixing corners; Angle code for fixing the back frame. (each fixed with 3 M8 expansion screws) (2)After confirming the installation position of the back frame fixing corner code and the position of the screen, punch holes on the wall to install the fixing corner code;...
  • Page 17 Absenicon X-Series Widescreen User Manual Note: 12 M6X20 locks at the corner code 2.2.4 Control Box and Power Sequencer Installation (1)Control box mounting: Use 4 M6 screws to secure the control box bracket to the rightmost column (front view) of the box, the second box below. 每个角码上下至少各拧紧一颗螺丝...
  • Page 18 Absenicon X-Series Widescreen User Manual 2.2.5 Mounting box (1)Hang and mount each column of boxes on the back frame in order of serial number, with the edge columns of boxes on either side mounted last. (2)Hang the left and right side of the box in turn, lock the left and right connecting bolts on the box and lock the box safety screws.
  • Page 19 Absenicon X-Series Widescreen User Manual 2.2.6mounting brackets (1)Installation of the screen body on the left, right and left edge through the edge of the positioning column and the corresponding positioning holes with the box, and then use the edge of the internal fittings shrapnel fixed mounting (2)Installation of the lower edge: the power cord, network cable and infrared button 5pin cable should be threaded into the lower edge before assembling the edge on the box.
  • Page 20 Absenicon X-Series Widescreen User Manual 2.2.7 Installation of control box Connect the control box network cable. According to the order of proximity to the control box, start connecting from port 1. Assemble the control box by following the control box slides 2.2.8 Mounting Module Box arrangement coding: Lamp panel arrangement coding:...
  • Page 21: X178 Wall Mount Version Installation

    Absenicon X-Series Widescreen User Manual 2.3 X178 Wall Mount Version Installation 2.3.1 Mounting Bracket Remove the backpack from the box, including the horizontal and vertical beams. Lay it out on the ground with the front side facing up (the crossbeam with the silkscreen logo side is the front side); First assemble the beams, using 4 M3 screws.
  • Page 22 Absenicon X-Series Widescreen User Manual 2.3.3 Fixed wall bracket After installing the corner bracket, install the wall bracket and fix it with two M8X60 screws at each position; and tighten the M4 safety screws to prevent the back bracket from falling off. Each 2pcs M8X60 locking Note: 12 M6X20 locks at the corner code...
  • Page 23 Absenicon X-Series Widescreen User Manual (2)POWER TIMING INSTALLATION: Use the screws inside the power network timer package to secure the bracket to the power network timer as shown in the illustration, and then mount the whole thing to the box above the control box bracket. 2.3.5 Mounting box (1)Hang and mount each column of boxes on the back frame in order of serial number, with the edge columns of boxes on either side mounted last.
  • Page 24 Absenicon X-Series Widescreen User Manual Note: Details show. Lock M4*4 security screws after hanging. (3)After completing the box installation, use M8X20 screws to install the box leveling connecting piece. Note: The internal structure is based on the real thing. 2.3.6 Mounting brackets (1)Installation of the screen body on the left, right and left edge through the edge of the positioning column and the corresponding positioning holes with the box, and then use the edge of the internal fittings shrapnel fixed mounting...
  • Page 25 Absenicon X-Series Widescreen User Manual Remarks: The internal structure is subject to the real thing; the wrapping edge with logo and start button is installed on the right side, it is recommended to assemble the lower wrapping edge on the right side first and then assemble the lower wrapping edge on the left side.
  • Page 26 Absenicon X-Series Widescreen User Manual 2.3.8 Mounting Module Box arrangement coding: Lamp panel arrangement coding: Install the modules in numbered sequence.
  • Page 27: X205 Wall Mount Version Installation

    Absenicon X-Series Widescreen User Manual 2.4 X205 Wall Mount Version Installation 2.4.1 Mounting Bracket Remove the backpack from the box, including the horizontal and vertical beams. Lay it out on the ground with the front side facing up (the crossbeam with the silkscreen logo side is the front side); First assemble the beams, using 4 M3 screws.
  • Page 28 Absenicon X-Series Widescreen User Manual 2.4.3Fixed wall bracket After installing the corner code, install the wall bracket and fix it with 2pcs of M8X60 screws in each position; and tighten the M4 safety screws to prevent the back bracket from falling off. Each 2pcs M8X60 locking Note: 12 M6X20 locks at the corner code...
  • Page 29 Absenicon X-Series Widescreen User Manual 2.4.4 Control Box and Power Sequencer Installation (1)Control box mounting: Use 4 M6 screws to secure the control box bracket to the rightmost column (front view) of the box, the second box below. (2) POWER TIMING INSTALLATION: Use the screws inside the power network timer package to secure the bracket to the power network timer as shown in the illustration, and then mount the whole thing to the box above the control box bracket.
  • Page 30 Absenicon X-Series Widescreen User Manual (2)Hang the left and right side of the box in turn, lock the left and right connecting bolts on the box and lock the box safety screws. Note: Details show. Lock M4*4 security screws after hanging. (3)After completing the box installation, use M8X20 screws to install the box leveling connecting piece.
  • Page 31 Absenicon X-Series Widescreen User Manual (1)Installation of the screen body on the left, right and left edge through the edge of the positioning column and the corresponding positioning holes with the box, and then use the edge of the internal fittings shrapnel fixed mounting (3)Installation of the lower edge: the power cord, network cable and infrared button 5pin cable should be threaded into the lower edge before assembling the edge on the box.
  • Page 32 Absenicon X-Series Widescreen User Manual 2.4.7Installation of control box (1)Connect the control box network cable. Connect the cables in order of proximity to the control box, starting with port 1. (2)Assemble the control box by following the control box slides 2.4.8 Mounting Module Box arrangement coding: Lamp panel arrangement coding:...
  • Page 33: 3.Product Maintenance

    Absenicon X-Series Widescreen User Manual 3.Product Maintenance 3.1 Tool Preparation Tools Picture Function Front maintenance Install/Remove LED tool Module Maintenance tool Remove/install the screws PH2 Phillips list for the HUB, receiving card screwdriver and power supply Measuring power supply Multimeter system 3.2 Maintenance Instructions 3.2.1 Module Maintenance...
  • Page 34 Absenicon X-Series Widescreen User Manual Use the maintenance tool to remove the module on the faulty panel, and then use a screwdriver to remove the screw fixing the HUB board for replacement HUB board maintenance Picture ❶ After removing module with maintenance tool, remove the current equalizing wire on the HUB board...
  • Page 35 Absenicon X-Series Widescreen User Manual a. Wear a grounded electrostatic wrist strap or electrostatic gloves; b. The screen is strictly grounded, and the grounding resistance is required to be ≤ 10 ohms, and a point inspection is carried out every six months; 2.
  • Page 36: Handling Of Common Problems

    Absenicon X-Series Widescreen User Manual 4. Handling of common problems Common faults Solution 1. Check whether the power plug of the corresponding module is tightly inserted; 2. Check whether the power cable of the corresponding module is burnt out; 3. Check whether the switch power supply of the corresponding module has no output;...
  • Page 37 Absenicon X-Series Widescreen User Manual All LED panels display 1. Set the screen connection on software; the same content 2. Check whether the data port is wrong. 1. Check the USB cable; 2. Check whether the computer USB port is malfunctioning; No control system 3.
  • Page 38 Damage to the equipment caused by failure to follow documentation is not covered by the equipment warranty. Professional Service, Best Experience Absen has built up a global network , able to provide prompt and professional local services. Absen service philosophy Initiative Efficiency...

This manual is also suitable for:

Absenicon x151Absenicon x178Absenicon x205
