- Page 1 A b s e n i c o n X Series X163 User Manual Shenzhen Absen Optoelectronic Co.,Ltd.
-
Page 2: Table Of Contents
Contents Product Introduction ......................... 6 Main product features ....................7 Product specifications ....................9 Screen dimensional drawing(mm) ................11 1.3.1 The wall mounting dimensional drawing of X163(mm) ........11 1.3.2 The dimensional drawing of Electric lifting bracket X163(mm) ...... 13 The interface of Device .................... - Page 3 Follow safety instructions in this manual and on the product. If you have any questions, please seek help from Absen. Beware of Electric Shock! •To prevent electric shock the device must be properly grounded during installation, Do not ignore using the grounding plug, or else there is a risk of electric shock.
- Page 4 • Before using this product check all electrical distribution equipment, cables and all connected devices, and make sure all meet current requirements. • Use appropriate power cords. Please select the appropriate power cord according to the required power and current capacity, and ensure the power cord is not damaged, aged or wet.
- Page 5 WARNING: The manufacturer shall not bear any responsibility for any incorrect, inappropriate, irresponsible or unsafe system installation. Product Disposal • Any component that has a recycling bin label can be recycled. • For more information on collecting, reusing and recycling, please contact the local or regional waste management unit.
-
Page 6: Product Introduction
16:9 standard ratio. Absenicon X series has features of super high level display effect and micro-pitch, which are based on new technology of Micro LED. The purpose of Absenicon X series is to satisfy the requirement of high-end meeting room, lecture theater，lecture hall and other middle-and large-sized spaces better. -
Page 7: Main Product Features
⚫ Infrared touch improve the interactive function Absenicon X series can choose to install the frame of infrared touch, which improves the function of interaction. The function of infrared touch can recognize some gestures and precise control of multi-points touch function. Therefore, the product can be more suitable and convenient for diverse meeting schemes. - Page 8 The maintenance of modules does not need to reverse space. The daily cleaning process can use wet cleaning tool to wipe directly, which is easy to clean and protect. The Absen serve can go directly to your place to help at any time and any place.
-
Page 9: Product Specifications
Product specifications Parameter Absenicon X163 LED Type Flip Chip COB Display Diagonal Size (Inch) Pixel Pitch (mm) 1.87 Display Size （ W× H ） / （ mm ） 3600*2025 Physical Screen Size （ W× H× D ） / （ mm ） 3610*2070*39.3/3642*2101*39.3 (touch vision) Parameter Packaging Size(W×... - Page 10 64-bit quad-core 1.8 GHz CPU System Memory DDR4-4GB Storage 32GB RJ45*1 ， RS232*1 Control Interface HDMI1.3 IN*1 ， HDMI OUT*1 ， USB2.0*2 ， Audio OUT*1 ， SPDIF OUT*1 I/O Interface Optional Operating Temperature （ ℃ ） -10℃ ～ 40℃ Operating Humidity （ RH ） 10 ～...
-
Page 11: Screen Dimensional Drawing(Mm)
Screen dimensional drawing(mm) 1.3.1 The wall mounting dimensional drawing of X163(mm) Figure 1. The dimensional drawing of non-touch version wall mounting X163 Figure 2. The back view of non-touch version wall mounting X163 11 / Absenicon X163Installation Guide... - Page 12 Figure 3. The dimensional drawing of touch version wall mounting X163 Figure 4. The back view of touch version wall mounting X163 12 / Absenicon X163Installation Guide...
-
Page 13: The Dimensional Drawing Of Electric Lifting Bracket X163(Mm)
The dimensional drawing of Electric lifting bracket X163(mm) 1.3.2 Figure 5. The dimensional drawing of non-touch version mobile stand X163 Figure 6. The back view of non-touch version mobile stand X163 13 / Absenicon X163Installation Guide... - Page 14 Figure 7. The dimensional drawing of touch version mobile stand X163 Figure 8. The back view of touch version mobile stand X163 14 / Absenicon X163Installation Guide...
-
Page 15: The Interface Of Device
The interface of Device HDMI IN SPDF HDMI OUT AUDIO OUT RS-232 4 / 5 USB2.0 POWER 15 / Absenicon X163Installation Guide... -
Page 16: Absenicon X163 Installation Guide
2. Absenicon X163 Installation Guide 2.1 Wall Mount Installation Guide Tools for installation 2.1.1 serial serial Tool name photos Tool name photos number number art knife Pre-maintenance tools Allen key PH2 Phillips screwdriver flexible rubber mallet sleeve laser level pneumatic drill Installation steps for Wall bracket installation 2.1.2 Step 1: Take out the back frame from the packing box, including the horizontal and vertical beams. - Page 17 Step 2：the installation of the back frame fixed corner code, the following chart corner code size chart in the wall holes to install the corner code and align the corner code of the silkscreen installation of wall brackets Note: When installing the wall bracket, the groove at the bottom of the wall bracket needs to be in contact with the protruding part of the corner code.
-
Page 18: Screen Installation
Screen Installation 2.1.3 Step 1, take out the box, use 40 M6X16 screws to install the hook connection piece on the back of the box, the left and right sides of the box only need to install a side Step 2: Install the box columns in the order of 4-3-5-2-6-1, with the hook connectors on the back of the box hooked into the grooves of the back frame beam profile. - Page 19 Step 3: Use 98 M8X20 fixing screws to install the leveling connecting piece inside the box. 98 x M8X20 screws Step 4: Control Box Installation: Front Installation: Lift the control box up from the back of the box to install it between the second column and the fifth column, and then use 4 M6*30 screws to lock it from the front to complete the installation of the control box structure.
- Page 20 Step 6: Install the lower wrap Use 9 M6X16 countersunk head screws to install the lower wrap around edge to the lower side of the box, and use 4 KM3X8 screws to fix the lower wrap around edge to the connecting piece and adjust the flatness to complete the wrap around edge installation.
-
Page 21: Module Installation
network connection Power cord connection Step 8: Connect the antenna, audio cable, and other wires from the lower wrap to the control box ① OPS Infrared Bezel 4Pin Cable (Connection required when touch control is included) ② OPS USB Transmissive Interface 5Pin Cable Connect 3 antennas (Connection required with OPS) ③... - Page 22 accordance with the order of our company logo. Installation numbering schematic (front view): Box mounting sequence coding: Module mounting sequence coding: Numbering instructions: The first bit is the screen number; the second bit is the box row number, from top to bottom, the top is the first row;...
- Page 23 23 / Absenicon X163Installation Guide...
-
Page 24: Touch Wrap Installation (Touch Version)
3.2 Touch wrap installation (touch version) Touch bezel exploded view ⚫ Touch Bezel Bill of Materials ⚫ Absenicon X136 Installation Guide 24 / 34... - Page 25 Touch Outer Bezel Schematic ⚫ ABS-6X6-4/5-B ABS-6X6-4/5-B Corner outer cover (top) Corner outer cover (top) ABS-6X6-4-A ABS-6X6-5-A ABS-6X6-9-A ABS-6X6-8-A ABS-6X6-1-A Corner outer cover (lower left) Corner outer cover (lower right) ABS-6X6-1/8/9-B ABS-6X6-1/8/9-B Step 1: First install the "A edge" on the left and right edges of the use of snap installation, refer to the regular version of the installation guide Two PM3X8 screws and fixing tabs are used between the top, left and right edges to connect the edges.
- Page 26 Step 4: Connect the FPC cable to the touch panel, refer to the schematic diagram. Be careful when connecting the FPC connection cable: Pay attention to the position of ⚫ the pins when inserting them. Avoid bending pins due to hard ⚫...
- Page 27 Take care of alignment when plugging in the wires; ⚫ Step 5: Connect the power cord and network cable, refer to the regular version of the power cord installation. Step 6: Secure (lower left, upper left, lower right) ground wire using 3 HM3X6 screws Step 7: Installation of the module, module installation and the conventional version of the installation of the same Step 8: Module installation is complete, the touch bezel function test Step 9: After the test is completed, use four KM3X8 and PM3X8 screws to secure the four corners of the wrap around...
- Page 28 Test result: Pass X-axis signal models Test results Y-axis signal Test Result: NG The matrix can be viewed by clicking on it Connect to a computer to test the drawing line ⚫ 28 / 34 Absenicon X136 Installation Guide...
- Page 29 The diameter of the touching object used to draw the line test (a stylus is recommended) is required to be greater than ➢ 8mm; When drawing a line with more than two points, the gap between two touches (two pens) is required to be more than ➢...
-
Page 30: Maintenance Guide
3. Maintenance Guide 3.1 Tool preparation Tools Picture Function Front maintenance Install/Remove LED tool Module Maintenance tool Remove/install the screws PH2 Phillips list for the HUB, receiving card screwdriver and power supply Measuring power supply Multimeter system 3.2 Maintenance instructions 3.2.1 module maintenance X163 series modules can be quickly removed using passive front maintenance. -
Page 31: Precautions For Use
screw fixing the HUB board for replacement HUB board maintenance Picture ❶ After removing module with maintenance tool, remove the current equalizing wire on the HUB board ❷Use a PH2 Phillips screwdriver to remove the screws fixing the HUB board and replace the faulty HUB board Receiving card maintenance Picture... - Page 32 b. The screen is strictly grounded, and the grounding resistance is required to be ≤10 ohms, and a point inspection is carried out every six months; 2. When cleaning the surface of the lamp panel, do not use unknown chemical liquids, but use a clean dust-free or clean water damp cloth to wipe lightly.
- Page 33 Damage to the equipment caused by failure to follow documentation is not covered by the equipment warranty. Professional Service, Best Experience Absen has built up a global network , able to provide prompt and professional local services. Absen service philosophy Initiative Efficiency...
- Page 34 All rights reserved by Shenzhen Absen Optoelectronic Co., Ltd. Shenzhen Absen Optoelectronic Co., Ltd. reserves the rights to modify contents without any further notice. 34 / 34 Absenicon X136 Installation Guide...
