Benchtop PRO Assembly
Tabletop Extrusion Installation
• 2' Table
– (8) [8020-720-CS6] T-Slot Machine Table Extrusion
– (1) [CRP8020-720-CS6-BT-FAST] Benchtop PRO Table Fasteners
∗ (48) M5 x 16mm Flat Head Screw
∗ (48) M5 Roll-in T-Nut
• 3' Table
– (8) [8020-960-CS8] T-Slot Machine Table Extrusion
– (1) [CRP8020-960-CS8-BT-FAST] Benchtop PRO Machine Table Fasteners
∗ (64) M5 x 16mm Flat Head Screw
∗ (64) M5 Roll-in T-Nut
