Benchtop PRO Assembly
Cable Track Installation
The following parts and bags will be used in this section:
• (1) [CRP950-00-FAST] Benchtop PRO Cable Track Hardware
– (6) M8 Roll In T-Nut
– (4) M8 x 16mm Socket Head Cap Screw
– (4) M5 x 12mm Socket Head Cap Screw
– (2) M8 x 30mm Socket Head Cap Screw
– (2) 40 Series Anchor Fastener
– (4) M5 x 16mm Socket Head Cap Screw
– (4) M5 Roll In T-Nut
• (1) [CRP950-01] Cable Track Bracket
• (1) [CRP950-02] Cable Track Bracket
• (1) [CRP950-03] Cable Track Bracket Extrusion
• (2) Cable Track Chains
