Benchtop PRO Assembly
Gantry Installation
The following parts and bags will be used in this section:
• (1) [CRP920-01-L] Benchtop PRO Linear Gantry Riser, Left
• (1) [CRP920-01-R] Benchtop PRO Linear Gantry Riser, Right
• (1) [CRP920-00-FAST] Benchtop PRO Linear Gantry Riser Fasteners
– (16) M8 x 25mm Socket Head Cap Screw
– (16) M8 Slide In T-Nut
• (1) 80160 Extrusion - 800 mm
• (1) [CRP840-00-650] PRO Linear Ballscrew Axis, 650 mm travel
• (1) [CRP930-00-FAST] Benchtop PRO Linear Gantry Fasteners
– (14) M8 x 25mm Flat Socket Head Screw
– (16) M8 x 25mm Socket Head Cap Screw
– (14) M8 Slide In T-Nut
