Benchtop PRO Assembly
Motor Installation
The following parts and bags will be used in this section:
• (1) [CRP900-00-MOTOR-HW] Benchtop PRO Motor Hardware
– (4) Oldham Assembly - Motor Half
– (16) M5 x 12mm Socket Head Cap Screw
• (4) NEMA 23 Stepper Motor
Benchtop PRO Assembly
Copyright©2019 CNC Router Parts LLC.
All Rights Reserved.
Version 2019Q1.1
44
