Benchtop PRO Assembly
Table Assembly
The following parts and bags will be used in this section:
• (3) 8080 Extrusion - 641 mm
• (2) [CRP840-00-650] PRO Linear Ballscrew Axis, 650 mm travel
• (1) Bag [CRP910-00-24-FAST] Benchtop PRO Linear Base Fastener Kit, 2' Travel
– (24) 40 Series Anchor Fastener
– (24) M8 x 25mm Socket Head Cap Screw
– (8) M8 Slide-In T-nut
• (4) [CRP913-00] Benchtop PRO Linear Leg Kit
– (1) M12 T-Slot Leg Bracket
– (1) M12 Leveling Foot 50mm
– (2) M8 x 30mm Socket Head Cap Screw
– (2) M8 Roll-In T-Nut
Benchtop PRO Assembly
