Targetti ZEDGE Manual

ZEDGE MINI BOLLARD
ZESB41FW
If in doubt about the symbols
please refer to catalog or website
2.50"
Packaging Contents / Mounting Base
Mounting Base Installation 1E3741
Mounting Base Installation 1E3740
Bollard Installation
Wiring Diagram / Distribution of Light
Maintenance / Support
Targetti USA - A Targetti Group Company
SMALL SCALE PROFESSIONAL LED BOLLARD
2.50"
2.76"
0.79"
Table of Contents
th St. Costa Mesa, CA 92627
- 750-A W. 17
WARNING
To ensure a maximum efficient use
of the product, read the instructions
before proceeding installment.
This fixture must be installed by a licensed
and qualified electrician. The installer must
comply with NEC and local building codes
when installing the fixture
Electrical current can cause painful shock,
serious injury, or even death. Make sure you
turn off the power supply, ground fixture(s),
and make sure all electrical connections are
correct and secured tightly
For use in IP66 installations.
Keep the label of the original packaging if any
eventual future claims are needed
-77°F
120/277V IP66
1.18"
50/60Hz IK10
- Phone (714) 513-1991 - Email: targettiusa@targetti.com -
+95°F
2.20 lbs.
