ZEDGE
220/240V
50/60Hz
In caso di dubbi sulla simbologia,
riferirsi al catalogo o al sito web.
If in doubt about the symbols refer
to catalog or website
RG1 secondo norma IEC/TR 62778:2014 / RG1 in accordance with IEC/TR 62778:2014
RG1 selon la norme IEC/TR 62778:2014 / RG1 nach der norm IEC/TR 62778:2014
RG1 enlight IEC/TR 62778:2014 / RG1 volgens IEC/TR 62778:2014
Targetti Sankey S.p.A. Via Pratese, 164 50145 Florence Italy
PRO
2.3Kg
RG1 de acordo com norma IEC/TR 62778:2014
13W Sorgente Led / Led source
15W Apparecchio / Fixture
COD. 1E3192 / 1E3193 / 1E3194
COD. 1E3195 / 1E3196 / 1E3197
COD. 1E3198 / 1E3199 / 1E3200
COD. 1E3201 / 1E3202 / 1E3203
COD. 1E3204 / 1E3205 / 1E3206
COD. 1E3207 / 1E3208 / 1E3209
COD. 1E3210 / 1E3211 / 1E3212
COD. 1E3213 / 1E3214 / 1E3215
COD. 1E3216 / 1E3217 / 1E3218
COD. 1E3760 / 1E3761 / 1E3762
1 E
X X
X X
IP66
IK10
200
2DN8CS00_102
E
L
Electronic
D A
DALI Dimmable
+35°C
-25°C
94
www.targetti.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Targetti ZEDGE PRO 1E3192
Summary of Contents for Targetti ZEDGE PRO 1E3192
- Page 1 RG1 secondo norma IEC/TR 62778:2014 / RG1 in accordance with IEC/TR 62778:2014 RG1 selon la norme IEC/TR 62778:2014 / RG1 nach der norm IEC/TR 62778:2014 RG1 enlight IEC/TR 62778:2014 / RG1 volgens IEC/TR 62778:2014 RG1 de acordo com norma IEC/TR 62778:2014 www.targetti.com Targetti Sankey S.p.A. Via Pratese, 164 50145 Florence Italy...
- Page 2 L’appareil doit être installer par électriciens qualifies. Targetti ne peut pas être responsable pour toutes les installations qui ne respectent pas les normes de sécurité en vigueur. Diese Leuchte darf nur von qualifiziertem Fachpersonal des Elektrohandwerks installiert werden.
- Page 3 Försiktighet i produkten enligt webbplatsen - www.targetti.com, det kan finnas en mer aktuell version av manualen på produktområdet på web-sidan Para más información acerca del producto puede visitar nuestra página web - www.targetti.com - podría estar disponible una versión más actualizada del presente manual AКТУАЛЬНАЯ...
- Page 4 9 mm INSTALLAZIONE TIPO "A" INSTALLATION TYPE "A" INSTALLAZIONE TIPO "B" INSTALLATION TYPE "B" Accessorio / Accessory COD.1E3219 www.targetti.com TARGETTI SANKEY S.p.A. Via Pratese n°164 Florence Italy...
- Page 5 Ø 21 STANDARD DALI USARE CAVO 2x1,5mm² MAX USARE CAVO 4x1mm² MAX H07RN-RF Ø7mm÷12mm MAX H07RN-F Ø7mm÷11,5mm MAX USE CABLE 2x1,5mm² MAX USE CABLE 4x1mm² MAX H07RN-RF Ø7mm÷11,5mm MAX H07RN-F Ø7mm÷11,5mm MAX www.targetti.com TARGETTI SANKEY S.p.A. Via Pratese n°164 Florence Italy...
- Page 6 Solo per apparecchi con sistema di regolazione Only for fixture with regulation system Regolazione / Adjustable Posizione standard (DEEP) DEEP WIDE Standard position (DEEP) 75° Max Regolazione / Adjustable WIDE DEEP 75° Max www.targetti.com TARGETTI SANKEY S.p.A. Via Pratese n°164 Florence Italy...
- Page 7 2,5mm www.targetti.com TARGETTI SANKEY S.p.A. Via Pratese n°164 Florence Italy...
- Page 8 SCHEMA DI COLLEGAMENTO ALIMENTAZIONE E LOOPING WIRING SCHEME FOR MAIN AND LOOPING www.targetti.com TARGETTI SANKEY S.p.A. Via Pratese n°164 Florence Italy...
