DART small
IP66 IK10
220/240V
50/60Hz
76
88
RG1 secondo norma IEC/TR 62778:2014 / RG1 in accordance with IEC/TR 62778:2014
RG1 selon la norme IEC/TR 62778:2014 / RG1 nach der norm IEC/TR 62778:2014
RG1 enlight IEC/TR 62778:2014 / RG1 volgens IEC/TR 62778:2014
Targetti Sankey S.p.A. Via Pratese, 164 50145 Florence Italy
0,8Kg
103
1,5mt
70
RG1 de acordo com norma IEC/TR 62778:2014
3W Sorgente Led / Led source
5,2W Apparecchio / Fixture
COD. 1E3056EL / 1E3057EL
11W Sorgente Led / Led source
13W Apparecchio / Fixture
COD. 1E3058EL / 1E3059EL
12W Sorgente Led / Led source
14W Apparecchio / Fixture
COD. 1E3060EL / 1E3061EL
COD. 1E3062EL / 1E3063EL
+40°C
-20°C
In caso di dubbi sulla simbologia,
riferirsi al catalogo o al sito web.
If in doubt about the symbols refer
to catalog or website
cod. 2CT4CS00_103
www.targetti.com
