Targetti ZEDGE PRO BOLLARD Manual

ZEDGE PRO BOLLARD
, (32), (40)
ZPB41-(16)
If in doubt about the symbols please
refer to catalog or website
6.65"
Packaging Contents /Mounting Base
Mounting Base Installation / Drainage / J-Box Installation 1US34501
Mounting Base Installation / Drainage / J-Box Installation 1US34502
Wiring Diagram
Bollard Installation
Maintenance / Support
Targetti USA - A Targetti Group Company
4.5"
3.3"
7.9"
Table of Contents
th St. Costa Mesa, CA 92627
- 750-A W. 17
ADJUSTABLE ILLUMINATION PROFESSIONAL
LED BOLLARD
To ensure a maximum efficient use
of the product, read the instructions
before proceeding installment.
This fixture must be installed by a licensed
and qualified electrician. The installer must
comply with NEC and local building codes
when installing the fixture
Electrical current can cause painful shock,
serious injury, or even death. Make sure you
turn off the power supply, ground fixture(s),
and make sure all electrical connections are
correct and secured tightly
For use in IP66 installations.
Keep the label of the original packaging if any
eventual future claims are needed
For available options refer to spec sheet pg. 1
+95 °F
-77 °F
16" Bollard
11.10 lbs.
- Phone (714) 513-1991
WARNING
120/277V IP66
50/60Hz IK10
32" Bollard 40" Bollard
16.32 lbs.
Pg.2/3
Pg.4/5
Pg.6/7
Pg.8
Pg.9
Pg.10
20024-01 Pg.1
- Email: targettiusa@targetti.com -
18.95 lbs.
www.Targettiusa.com
