Targetti Zedge Pro Installation Instructions Manual

Zedge Pro
120-277VAC
5.07 lbs
+95°F
-13°F
Fixture Dimensions
Distribution of Light
Mounting Diagram
Electrical/Mounting Instructions
Optics Adjusting Instructions
Face Plate Mounting Instructions
Maintenance
Support Page
Targetti USA - A Targetti Group Company - 750-A W. 17th. St. Costa Mesa, CA 92627 - (714)
Table of Contents
513-1991 Email: targettiusa@targetti.com - www.targetti.us - 05.2018 - Page 1 of 7
Part number: ZEP41FW-
WARNING
To ensure a maximum efficient use
of the product, read the instructions
before proceeding installment.
This fixture must be installed by a licensed and
qualified electrician. The installer must comply with
NEC and local building codes when installing the
fixture
Electrical current can cause painful shock, serious
injury, or even death. Make sure you turn off the
power supply, ground fixture(s), and make sure all
electrical connections are correct and secured
tightly
For use in IP66 installations.
Keep the label of the original packaging if any
eventual future claims are needed
Pg.2
Pg.2
Pg.2
Pg.3
Pg.4
Pg.5
Pg.6
Pg.7
