- Page 1 OLED Monitor As an OLED product, this display needs regular screen maintenance to reduce the risk of image retention (burn-in). User Manual AG326UD www.aoc.com ® 2024 AOC.All Rights Reserved © Version: A00...
-
Page 2: Table Of Contents
Safety ....................................1 Notational Conventions ............................1 Power ..................................2 Installation ................................3 Cleaning .................................4 Other ..................................5 Setup ....................................6 Contents in Box ..............................6 Setup Stand & Base ..............................7 Adjusting the monitor ............................8 Connecting the Monitor ............................9 Wall Mounting ..............................10 Adaptive-Sync function ............................. 11 HDR .................................. -
Page 3: Safety
Safety Notational Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system. -
Page 4: Power
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. -
Page 5: Installation
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. -
Page 6: Cleaning
Cleaning Clean the cabinet regularly with a water-dampened, soft cloth. When cleaning use a soft cotton or microfiber cloth. The cloth should be damp and almost dry, do not allow liquid into the case. Please disconnect the power cord before cleaning the product. -
Page 7: Other
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the OLED monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation. -
Page 8: Setup
Quick Start Guide Warranty card Stand Base Bracket Screws Screwdriver Power Cable DisplayPort HDMI Cable USB Cable Stand Cable Screws Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation. -
Page 9: Setup Stand & Base
Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove:... -
Page 10: Adjusting The Monitor
Adjusting the monitor For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. Hold the stand to steady the monitor, and grasp only the bezel to adjust the monitor’s angle. You are able to adjust the monitor as below: 18°... -
Page 11: Connecting The Monitor
Connecting the Monitor Cable Connections In Back of Monitor: 1. Power 2. HDMI1 3. HDMI2 4. DisplayPort 5. Earphone 6. USB3.2 Gen1 upstream 7. USB3.2 Gen1 downstream x2 8. USB3.2 Gen1 downstream + fast charging x1 Connect to PC 1. Connect the power cord to the back of the display firmly. 2. -
Page 12: Wall Mounting
M=4.0Max M4-P0.7 Dk=8.0 H=2.0 L=12+X Noted: VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. 0° 90° -5° Display design may differ from those illustrated. Warning: 1. To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward by more than -5 degrees. -
Page 13: Adaptive-Sync Function
Adaptive-Sync function 1. Adaptive-Sync function is working with DisplayPort/HDMI 2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting www.AMD. Graphics Cards • Radeon™ RX Vega series • Radeon™ RX 500 series • Radeon™ RX 400 series •... -
Page 14: Hdr
It is compatible with input signals in HDR10 format. The display may automatically activate the HDR function if the player and content are compatible. Please contact the device manufacturer and the content provider for information on the compatibility of your device and content. -
Page 15: Adjusting
Adjusting Hotkeys Source/Up Dial Point/Down Game Mode/Left Light FX /Right Power/ Menu/Enter Power/Menu/Enter Press the Power button to turn on the monitor. When there is no OSD, Press to display the OSD or confirm the selection. Press about 2 seconds to turn off the monitor. -
Page 16: Osd Key Guide (Menu)
OSD Key Guide (Menu) Enter Move Exit Enter : Use Enter key to enter the next OSD level Move : Use Left / Up / Down key to move OSD selection Exit : Use Right key to exit OSD Enter Move Exit Enter : Use Enter key to enter the next OSD level... - Page 17 Enter Select Select : Use Up / Down key to adjust OSD setting Enter Select Enter : Use Enter key to exit OSD to previous OSD level Select : Use Left / Right key to adjust OSD setting...
-
Page 18: Osd Setting
OSD Setting Basic and simple instruction on the control keys. PIP Se�ng Color Setup PIP Se�ng Audio Light FX OLED Care/Extra Audio Light FX OSD Setup Enter Move Exit Enter Move Exit 1). Press the MENU-button to activate the OSD window. 2). -
Page 19: Game Setting
Game Setting Game Setting Game Mode Shadow Control Game Color Sniper Scope Adaptive-Sync Low Input Lag Frame Counter HDMI1 HDMI1 Console/DVD Console/DVD HDMI2 HDMI2 Exit Enter Select No optimization by Game Mode. For playing FPS (First Person Shooters) games. Improves dark theme black level details. - Page 20 Shutting down the frame buffer can reduce input delay. Note: Low Input lag at UHD 120Hz/165Hz resolution, and Low Input lag On / Off PIP/PBP , Sniper Scope turn off can be adjusted . It is enabled by default in the Adaptive-Sync state and cannot be adjusted.
-
Page 21: Luminance
Luminance Luminance Contrast Brightness Dark Boost ECO Mode Standard Gamma Gamma1 HDR Mode Exit Enter Select Contrast 0-100 Contrast from Digital-register. Brightness 0-100 Backlight Adjustment Enhance the screen details in the dark or bright area Level 1 Dark Boost to adjust the brightness in the bright area and ensure Level 2 that it is not oversaturated. - Page 22 Optimized for the color and contrast of the picture, which will simulate showing the HDR effect. HDR Picture HDR Mode Note: HDR Movie When HDR is not detected, the HDR Mode option is HDR Game displayed for adjustment. Note: 1). When“HDR Mode”...
-
Page 23: Pip Setting
PIP Setting Disable or Enable PIP or PIP Setting Off / PIP / PBP PBP. Select main screen Main Source source. Sub Source Select sub screen source. Size Small / Middle / Large Select screen size. Right-up Right-down Position Set the screen location. Left-up Left-down Disable or Enable Audio... -
Page 24: Color Setup
Color Setup Color Setup LowBlue Mode Color Temp. Warm Color Gamut Panel Native Green Blue Exit Enter Select Off / Multimedia / Decrease blue light wave by controlling LowBlue Mode Internet / color temperature. Office / Reading Recall Warm Color Temperature from Warm EEPROM. -
Page 25: Audio
Audio Audio Volume Exit Enter Select Volume 0-100 Adjust volume setting... -
Page 26: Light Fx
Light FX Light FX Light FX Medium Light FX Mode Static Pattern Rainbow Foreground R Foreground G Foreground B Background R Background G Background B Exit Enter Select Off / Low / Medium / Light FX Select the intensity of Light FX. Strong Audio1 / Audio2 / Static / Dark Point Sweep /... -
Page 27: Oled Care/Extra
OLED Care/Extra OLED Care/Extra OLED Care/Extra OLED Care/Extra Weak Pixel Orbiting Auto Warning Off Timer Boundary Dimmer Pixel Refresh Taskbar Dimme Image Ratio Wide Screen Saver ThermalProtection DDC/CI Logos Protection Input Select Auto Reset Time after Off-RSS Resolution: 3840(H)x2160(V) SDR Time after Off-RSS Off-RS Counts... - Page 28 When a static image is detected for a certain period of time, the screen saver function will dim the screen to protect the panel from sticking. When a moving image is detected, the monitor will recover luminance to previous working Screen Saver status.
-
Page 29: Osd Setup
OSD Setup OSD Setup Language English Timeout DP Capability 1.2/1.4 H.Position V.Position Transparence Break Reminder Exit Enter Select Language Select the OSD language Timeout 5-120 Adjust the OSD Timeout Note: Only DP1.2/DP1.4 support Adaptive-Sync DP Capability 1.1 / 1.2 / 1.4 functionality. -
Page 30: Led Indicator
LED Indicator Status LED Color Full Power Mode White Active-off Mode Orange Pixel Refresh under Flashing White (1 second on / 1 second off) process OLED panel Flashing Orange (1 second on / 1 second off) malfunction Shutdown mode The indicator is not lit. -
Page 31: Troubleshooting
Instructions in the official website. Please refer to Regulation & Service Information which is in the CD manual Regulation & Service or www.aoc.com (to find the model you purchase in your country and to find Regulation & Service Information in Support page. -
Page 32: Specification
Specification General Specification Model Name AG326UD Driving System OLED Panel Viewable Image Size 80.3 cm Diagonal Pixel Pitch 0.1814mm(H) x 0.1814mm(V) Display Color 1.07B Colors Horizontal Scan Range 30k-370kHz Horizontal scan Size(Maximum) 699.48 Vertical Scan Range 48-165Hz Vertical Scan Size(Maximum) 394.73 Optimal Preset Resolution 3840 x 2160@60Hz Max Resolution... - Page 33 [1]:The maximum number of display colors supported by this product is 1.07 billion, and the setting conditions are as follows (there may be differences due to the output limitation of some graphics cards): HDMI2.1 DisplayPort1.4 YCbCr422 YCbCr444 YCbCr422 YCbCr444 YCbCr420 YCbCr420 Color Bit 3840x2160 165Hz 10bpc...
-
Page 34: Preset Display Modes
Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION (±1Hz) FREQUENCY(kHz) FREQUENCY(Hz) 640×480@60Hz 31.469 59.940 640x480@72Hz 37.861 72.809 640x480@75Hz 37.500 75.000 640x480@100Hz 51.080 99.769 640x480@120Hz 60.938 119.720 800x600@56Hz 35.156 56.250 800×600@60Hz 37.879 60.317 800x600@72Hz 48.077 72.188 SVGA 800x600@75Hz 46.875 75.000 800x600@100Hz 62.760 99.778 800x600@120Hz 76.302... -
Page 35: Pin Assignments
Pin Assignments 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS Data 0- DDC/CEC Ground TMDS Data 2 Shield TMDS Clock + +5V Power TMDS Data 2- TMDS Clock Shield Hot Plug Detect TMDS Data 1+ TMDS Clock-... -
Page 36: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
