Dual Installations - Sub-Zero IC27RLH Installation Manual

Integrated Installation

Dual Installations

Two integrated units may be placed side by side in a dual
installation. Panel width dimensions will vary slightly from
single installations. A dual installation kit is required for
installations with 2" (51) or less space between units.
Dual installation kits are available through your authorized
Sub-Zero dealer.
IMPORTANT NOTE: If a 27" (686) unit is installed next to a
36" (914) tall unit, the decorative front panels will align,
however, the face frames will not. This is only apparent
when both doors are open at the same time. Due to a
more robust hinge on 36" (914) units, the face frame was
reconfigured to maintain a consistent overall panel height.
Typical Panel Dimensions
COLUMN MODELS
Door
27" MODELS
(686)
Door
Top Drawer
Bottom Drawer
36" MODELS
(914)
Door
Top Drawer
Bottom Drawer
W
13 7
26 / " 76 / "
(681) (1953)
16 8
W
13 3
26 / " 45 / "
(681) (1153)
16 8
13 9
26 / " 13 / "
(681) (345)
16 16
13 11
26 / " 16 / "
(681) (424)
16 16
W
13 3
35 / " 45 / "
(910) (1153)
16 8
13 9
35 / " 13 / "
(910) (345)
16 16
13 11
35 / " 16 / "
(910) (424)
16 16
90° Door Stop
Integrated columns and tall units have a 90° door stop
built into the hinge system. Use the blade edge of a
standard screwdriver and rotate the cam in the center
portion of the hinge. You must make this adjustment to
both the bottom and top hinge. Refer to the illustration.
H
H
90° door stop.
