  • Page 1 INSTALLATION GUIDE Integrated Refrigeration...

  • Page 2: Table Of Contents

    Integrated Refrigeration ..... . . 3 To ensure the safe and efficient installation of Sub-Zero equipment, please take note of the following types of Model Specifications .

  • Page 3: Sub-Zero Integrated Refrigeration

    Any questions or problems regarding the installation TOOLS AND MATERIALS REQUIRED should be directed to your authorized Sub-Zero dealer or • Appliance dolly able to support 500 lbs (227 kg) and Sub-Zero customer service at 800-222-7820. You may adequate manpower to handle the weight of the unit.

  • Page 4: Model Specifications

    Model Specifications Overall Dimensions COLUMN MODELS 27" TALL MODELS (686) 27" 24" 27" 24" (686) (610) (686) (610) 14" 14" (356) (356) " " (41) (21) " " (1995) (1995) 81" 80" (2057) (2032) TO TOP OF TO TOP OF OPENNG "...
  • Page 5 Model Specifications subzero.com/specs Overall Dimensions 36" TALL MODELS (914) 36" 24" (914) (610) 14" (356) " (33) " (1976) 80" (2032) TO TOP OF " OPENNG (10) " " (337) (13) " " (876) (260) " (518) " (248) 4" HEIGHT DIMENSIONS ±...
  • Page 6 Model Specifications Interior Capacity and Weight Overall Dimensions DRAWER MODELS Interior Capacity R cu ft F cu ft COLUMN MODELS 27" 24" " (686) (610) IC-27R 16.2 (459) (10) IC-27FI 16.3 (462) 27" TALL MODELS (686) 700TR 15.5 (439) " "...

  • Page 7: Site Preparation

    Site Preparation subzero.com/specs Opening Dimensions INTEGRATED MODELS IMPORTANT NOTE: The depth of each integrated model is 24" (610) from the front of the unit to its back. Your design may necessitate moving the unit back or cabinets forward to achieve TOP VIEW a flush fit.

  • Page 8: Electrical Requirements

    Site Preparation Electrical Requirements The electrical supply should be located within the shaded area shown in the illustrations. Follow the National The outlet must be checked by a qualified electrician Electrical Code and local codes and ordinances when to be sure that it is wired with the correct polarity. installing the receptacle.

  • Page 9: Plumbing Requirements

    Do not use self-piercing valves. A saddle valve kit (4200880) is available from your " (343) authorized Sub-Zero dealer. BACK WALL 6" An in-line filter is required when water conditions have "...

  • Page 10: Anti-Tip Bracket Installation

    Site Preparation Anti-Tip Bracket Installation WOOD FLOOR APPLICATIONS Use the six #12 x 2 " wood screws and the six " flat To prevent the unit from tipping forward and provide washers provided. Drill pilot holes " (5) diameter a stable installation, the unit must be secured in place with the anti-tip brackets shipped with the unit.

  • Page 11: Position The Unit

    Site Preparation subzero.com/specs Anti-Tip Bracket Installation Position the Unit INSTALL CONCRETE WEDGE ANCHORS: 1) Drill a " (10) diameter hole any depth exceeding the Before moving the integrated unit into position, minimum embedment. Clean the hole or continue protect any finished flooring, secure the door closed and remove the drawers.

  • Page 12: Integrated Installation

    Integrated Installation Position the Unit Level the Unit If two integrated units are installed closer than 2" (51) to Level the integrated unit by turning the front leveling legs one another, refer to dual installations on page 18. clockwise to raise or counterclockwise to lower the unit. To assist you in adjusting the front leveling legs up or Plug the power cord into the electrical outlet.

  • Page 13: Molding Installation

    Integrated Installation subzero.com/specs Molding Installation Water Line Connection Install the decorative white molding strips to the top and QUICK CONNECT WATER VALVE sides of the integrated unit for a finished look. The top For units with an ice maker, the quick connect water valve molding strip, used on column and tall models, must be and PEX tubing are located on the bottom right side of the installed before the side molding can be attached.
  • Page 14 Check panel dimensions before proceeding. Additional IMPORTANT NOTE: The unit must be allowed to have panel information can be found in the Sub-Zero design ventilation through the fins of the kickplate/grille. You may guide and on our website, subzero.com.
  • Page 15 Integrated Installation subzero.com/specs Panel Considerations TYPICAL PANEL DIMENSIONS " " " (679) (679) (908) PANEL WIDTH PANEL WIDTH PANEL WIDTH " " " (1953) (1153) (1153) " " " (2054) (2029) (2029) " " (345) (345) " (876) " " (424) (424) 4"...

  • Page 16: Toe Kick Clearance

    Integrated Installation Panel Considerations DOOR PANEL HEIGHT TOE KICK CLEARANCE The height of the door panel can extend beyond the The toe kick clearance can vary with the height of the typical panel height, provided you do not exceed the panel panel.

  • Page 17: Door Panel Installation

    Integrated Installation subzero.com/specs Panel Installation Before attaching the door panel to the door, place a screw DOOR PANEL INSTALLATION in the center of the upper and lower mounting positions, Remove the two pieces of mounting hardware attached to just enough that the slotted holes on the hinge side door the front of the door and set aside.
  • Page 18 Integrated Installation Panel Installation PANEL BRACKET POSITIONING The illustrations below show placement of panel mounting brackets. Dimensions are based on a 4" (102) toe kick and " (3) reveal. A reveal of up to " (6) is possible, but panel dimensions need to be adjusted accordingly. "...

  • Page 19: Drawer Panel Installation

    Integrated Installation subzero.com/specs Panel Installation With the two mounting brackets in place, install the DRAWER PANEL INSTALLATION drawer panel by engaging the top tabbed bracket first, Remove the mounting hardware provided and set aside. then slide the lower ’L’ bracket onto the positioning As with the door panel, you should work on the back side screws.

  • Page 20: Dual Installations

    Dual installation kits are available through your authorized both the bottom and top hinge. Refer to the illustration. Sub-Zero dealer. IMPORTANT NOTE: If a 27" (686) unit is installed next to a 36" (914) tall unit, the decorative front panels will align, however, the face frames will not.

  • Page 21: Installation Checklist

    Integrated Installation subzero.com/specs Installation Checklist To ensure a safe and proper installation, the following INSTALLATION CHECKLIST checklist should be completed by the installer to ensure Has the anti-tip bracket been installed properly and is that no part of the installation has been overlooked. it making contact with the unit? Is the unit level? Are all leveling legs making contact with the floor?

  • Page 22: Service Information

    If you are storing or disposing of your old refrigerator center. or freezer, please do it safely. Remove the To obtain the name and number of a Sub-Zero authorized doors or tightly secure service center, check the contact & support section of our the doors closed.
  • Page 23 The information and images in this guide are the copyright property of Sub-Zero, Inc. Neither this guide nor any information or images contained herein may be copied or used in whole or in part without the express written permission of Sub-Zero, Inc. ©Sub-Zero, Inc. all rights reserved.
  • Page 24 SUB-ZERO, INC. P. O. BOX 44848 MADISON, WI 53744 SUBZERO.COM 800.222.7820 7018809 REV-A 6/2010...
