ABSCO SHEDS 15151XK Manual

Highline shed
Hide thumbs

Advertisement

Table of Contents

AU: 1800 029 70 1
N Z: 0800 466 444
For construction in non-cyclonic areas
Wind rating: N2 as per AS4055-2021.
If you require a higher wind rating please contact
us: admin@absco.com.au or 1800 029 701
DOWNLOAD
OUR APP FOR
ASSEMBLY
VIDEOS
*Most models available
Absco Industries
Assembly Instruction Manual
ABSCO HIGHLINE SHED
MODEL: 15151XK
1.52m W x 1.52m D x 2.24m H
admin@absco.com.au
www.abscosheds.com.au
WHEN LAYING YOUR CONCRETE
SLAB, ENSURE THERE IS A
REBATED EDGE 25mm DEEP
AROUND THE PERIMETER
THIS WILL HELP WATER EGRESS
FROM THE BASE OF THE SHED
We thank you for choosing an Australian made
shed. For further assistance please visit our detailed
instructional video library at
Http://www.abscosheds.com.au/watch-videos
At ABSCO Industries we are always looking to be
number ONE, so please let us know what you think
of our instructions. Feedback makes us better.
feedback@absco.com.au
ABSCO INDUSTRIES
ASSEMBLY INSTRUCTION MANUAL
Model: 15151XK
Absco Industries
Premier Shed Model: 23151GK
When laying concrete slab, ensure there
is a rebated edge 25mm deep around
PLEASE LEAVE A REVIEW
the perimeter. This will help water egress
from the base of the shed.
Tell us about your experience!
Visit www.abscosheds.com.au/review
SHED MODEL: 23151GK
28/10/2024
FRONT: 2.26m
SIDE:
1.52m
HEIGHT: 1.95m
BOTTOM CHANNEL
REBATED EDGE
75mm WIDE REBATE
CONCRETE SLAB
21-11-2017
PAGE 01
2.1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15151XK and is the answer not in the manual?

Questions and answers

Leonard Mayfield
February 23, 2025

How does the RR3 channel attach to the CTB channel on the rear panal assembly. See Page 10 para 6 of manual

0
1 comments:
Mr. Anderson
February 23, 2025

The RR3 channel attaches to the CTB channel on the rear panel assembly by ensuring that the edge of the RR3 channel is flush with the CTB channel. Some overlap of the RR3 channel should be visible. The connection is secured using four self-drilling screws (FAST096) at each corner.

This answer is automatically generated

0

Related Manuals for ABSCO SHEDS 15151XK

Summary of Contents for ABSCO SHEDS 15151XK

  • Page 1 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H AU: 1800 029 70 1 admin@absco.com.au N Z: 0800 466 444 www.abscosheds.com.au Absco Industries Premier Shed Model: 23151GK FRONT: 2.26m SIDE: 1.52m HEIGHT: 1.95m WHEN LAYING YOUR CONCRETE...
  • Page 2 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H GENERAL INSTRUCTIONS • Before commencing any assembly, read through these instructions in detail to gain a thorough understanding of assembly methods and associated details. • Unpack the carton and carefully identify and check off all the parts against the parts described and illustrated on "COMPONENTS PACKING LIST"...
  • Page 3 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H COMPONENT PACKING LIST Check off all components. COMPONENT PART COMPONENT PART CHECK QTY CHECK DESCRIPTION DESCRIPTION STEEL SHEET STEEL SHEET 1615mm X 773mm 695mm X 773mm STEEL SHEET...

  • Page 4: Component Description

    ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H COMPONENT PACKING LIST Check off all components. COMPONENT PART COMPONENT PART CHECK QTY CHECK DESCRIPTION DESCRIPTION JAMB L = 1970mm LIMP TRIM L = 790mm JAMB L = 1957mm...
  • Page 5 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H COMPONENT PACKING LIST Check off all components. FITTINGS PACK FAST FAST 8G x 12mm SELF DRILLING PAN HD SCREW SCREW TIP COVER FAST FAST SBS43E POP RIVET...
  • Page 6 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H SNAPTiTE ASSEMBLY GUIDE The Snaptite Assembly System locks end channels to all roof and wall sheets without the need for tools and fasteners. To assemble each panel, the perimeter channels are secured to the top and bottom of each panel.
  • Page 7 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H OVERVIEW OF ROOF COMPONENTS BKT17 C1485 BKT17 Absco Industries Assembly Instruction Manual Model: 15151XK 28/10/2024...
  • Page 8 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H OVERVIEW OF WALL COMPONENTS D1H-T D1H-T Absco Industries Assembly Instruction Manual Model: 15151XK 28/10/2024...

  • Page 9: Rear Panel Assembly

    ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H REAR PANEL ASSEMBLY 1 required 1. Layout and overlap sheets by two ribs as shown. Make sure to Orientateate the sheet to with colour side up. 2. Make sure the ends of the sheets are flush at overlap before continuing.
  • Page 10 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H REAR PANEL ASSEMBLY CONTINUED Sheet & Channel are 4. Before proceeding to the next flush step make sure that Sheets & Channel are propely flush. This hole should Sheet &...
  • Page 11 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H LEFT PANEL ASSEMBLY 1 required 1. Layout and overlap sheets by two ribs as shown. Make sure to Orientate the sheet to with colour side up. 2. Make sure the ends of the sheets are flush at overlap before continuing.
  • Page 12 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H LEFT PANEL ASSEMBLY CONTINUED Sheet & 4. Before proceeding to the next Channel are step make sure that Sheets & flush Channel are propely flush. 5. Take the LCF Lip and place on top of the XC1 Channel.
  • Page 13 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H LEFT PANEL ASSEMBLY CONTINUED 7. Take both CTB Channel and place on top of the sheet and Channel. Make sure that the side with the hole is on the top.
  • Page 14 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H RIGHT PANEL ASSEMBLY 1 required Sheet & Channel are flush NOTE: Step 1 - 5 can also be applied for the right panel assembly. Sheet & Channel are...
  • Page 15 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H RIGHT PANEL ASSEMBLY CONTINUED 7. Take both CTB Channel and place on top of the sheet and Channel. Make sure that the side with the hole is on the top.

  • Page 16: Front Panel Assembly

    ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H FRONT PANEL ASSEMBLY 1 required 1. Layout and overlap sheets by two ribs as shown. Make sure to Orientateate the sheet to with colour side up. 2. Make sure the ends of the sheets are flush at overlap before continuing.
  • Page 17 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H FRONT PANEL ASSEMBLY CONTINUED 4. Before proceeding check if both sheet and Channels are flush together. 5. Take JH6 JAMB and place on top of FR5 Channel.
  • Page 18 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H FRONT PANEL ASSEMBLY CONTINUED 9. Next, Use FAST096 self drilling FAST096 screws to fasten the Channel from each hole. Do this at all corners - four screws total.
  • Page 19 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H FRONT PANEL ASSEMBLY CONTINUED 12. Take JUP jamb and arrange between FR1 and FR2 Channel. Orientateate the JUP jamb as shown below before aligning. 13. Then fasten each hole with the self tapping screws FAST096.

  • Page 20: Door Panel Assembly

    ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H DOOR PANEL ASSEMBLY 1 required 1. Layout and overlap sheets by two ribs as shown. Make sure to orientate the D1H-T sheets so the colour side is up.
  • Page 21 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H DOOR PANEL ASSEMBLY CONTINUED 4. Before proceeding check if both sheet and Channels are flush together. 5. Take 58C Channel and arrange it on top and bottom of the panel.
  • Page 22 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H DOOR PANEL ASSEMBLY CONTINUED FAST009 Flip the panel over, Check you have the panel Orientateated as shown for the next step. Before proceeding be sure to fasten each corner of the panel using FAST009.
  • Page 23 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H DOOR PANEL ASSEMBLY CONTINUED 8. After aligning the cover Channel fasten with a self drilling FAST096 screw FAST096 through the hole in the Channel. Fasten three screws at the top and three at the bottom - Total of 6 screws.
  • Page 24 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H DOOR PANEL ASSEMBLY CONTINUED 10. Let’s attach the hinges. Use the supplied 3 mm drill bit DRILL and go through these existing Channel holes into the sheet behind.
  • Page 25 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H DOOR PANEL ASSEMBLY CONTINUED 12. Next, align the padbolt in the middle of the door panel as shown. FAST096 The padbolt is fastened to the sheet with four bolts FAST047, washer FAST107 and nyloc nuts FAST064.
  • Page 26 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H ROOF PANEL ASSEMBLY 1 required 1. Layout and overlap sheets by one rib as shown. Make sure to Orientateate the sheet to with colour side up. 2. Make sure the ends of the sheets are flush at overlap before continuing.
  • Page 27 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H ATTACH DOOR Let’s attach the doors to the front panel. We’ll start with the right door panel. 1. Use the supplied 3 mm drill bit DRILL and go through these existing jamb holes, do all six.

  • Page 28: Wall Panel Assembly

    ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H WALL PANEL ASSEMBLY 1. Carefully stand up the right panel, use a 1.8m ladder (or equivalent) to keep it upright. 2. Also carefully bring the front panel and align the jamb with the edge of the Channel of right panel.
  • Page 29 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H WALL PANEL ASSEMBLY CONTINUED 4. After stabilizing both panel, carefully align the rear panel to the right panel. Slide the flashing of the side panel into the top and bottom Channels of the rear panel.
  • Page 30 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H ATTACH HASP 1 required 1. Take a hasp, and with the door in the closed position, place it centered over the padbolt shaft. Use two self drilling screws FAST096 to secure it.
  • Page 31 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H ATTACH INFILL PANELS 1. Take the rectangular panel 16A and attach it the the top of the front panel. Make sure to flush the Channel at the top and inside of the front panel.
  • Page 32 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H ATTACH INFILL PANELS CONTINUED 4. Make sure to flush the both side infill panels to the front infill panels 5. The side infill panel should be underneath the front infill panel.
  • Page 33 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H ATTACH OVER DOOR FRAMING 1 required 1. Take a BKT17 and flush it the edge of side infill panel. Orientateate as shown below. 2. From the inside the shed, using...
  • Page 34 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H ATTACH OVER DOOR FRAMING CONTINUED 4. Gently slide C1485 to the front Slide until it flush on the fonrt panel infill 16A. Orientateate as the channel as shown.
  • Page 35 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H ATTACH ROOF PANEL ASSEMBLY 1 required Make a quick inspection, check if the walls are square. 1. Before lifting and placing the roof panel, make sure that the channel on the roof panel is facing the front edge of the 16A Infill panel.
  • Page 36 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H ATTACH ROOF PANEL ASSEMBLY 1 required 4. Before placing the lip L2H on the roof panel make sure to remove the rear corner screw of the side wall.
  • Page 37 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H ATTACH ROOF PANEL ASSEMBLY 1 required 8. Next, slide and flush the lip fornt of 16A infill panel. Orientateate as shown below. 9. Before fasten the lip...
  • Page 38 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H FINAL CONSTRUCTION Anchoring Each anchor consists on one nut, bolt, washer, dynabolt and steel angle. 1. Drill a 10mm hole into the wall sheet. 2. Drill a 10mm hole into the concrete slab.
  • Page 39 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H Absco Skillion Roof Shed Notes General • 1.G This instruction manual shall be read in conjunction with other consultants drawings, specifi cations and written instructions provided by Absco and/or their representatives.
  • Page 40 ABSCO HIGHLINE SHED MODEL: 15151XK 1.52m W x 1.52m D x 2.24m H Absco Skillion Roof Shed Notes Steelwork • 1.S All structural steelwork shall have a corrosion protection system applied consistent with AS/NZS 2312- 2002. • 2.S All structural steelwork detailed within this installation manual shall be minimum Grade 550 for roll formed sections (including roof and wall sheeting) and Grade 250 for angle sections.
  • Page 41 Absco Sheds Storage Guidelines • Absco Sheds are designed to be weatherproof for normal weather conditions. In the event of extreme weather conditions such as heavy rain, combined with high wind gusts, the ridge capping, sheeting joins, screw fi xings etc., may exhibit minor deformations which may allow some water entry. These areas should be checked regularly to ensure that maximum strength and protection is maintained.
  • Page 42 Lifetime Warranty Statement 1. DEFINITIONS 3. WARRANTY CLAIM PROCEDURE In this document, capitalised terms have the following meaning: 3.1. If, during the Lifetime Warranty Period, You believe the Product has a “ABSCO” means John Scholtes Investments (No. 1) Pty Ltd trading Defect, You must comply with the procedure set out in this clause 3.
  • Page 43 4. WARRANTY LIMITATIONS / EXCLUSIONS 4.1. To the extent permitted by law, this warranty will not apply where: the Product has been installed or used for a purpose that is not an Authorised Purpose; the Product has not been installed, assembled, maintained and/or special, indirect or consequential loss or damage of any nature operated in complete compliance with ABSCO’s Product Guide;...
