  • Page 1 Original Instructions Version 1 CAN BUS 13 AND 7 PIN TOWBAR SOCKET TESTER 27198...
  • Page 2: Product Reference

    WARNING! – Situations or actions that may result in personal injury or death. Stock No: 27198 CAUTION! – Situations or actions that may Part No: TST13C result in damage to the product or surroundings. Important: – Information or instructions of particular 1.2 Revisions importance.
  • Page 3: Product Introduction

    This towing socket tester is designed to test bulbs, Any other application beyond the conditions established indicators and diagnose wiring faults on 12 volt for use will be considered misuse. Draper Tools accepts controller network (CAN BUS) systems on towing no responsibility for improper use of this product.
  • Page 4: Health And Safety Information

    European conformity • DO NOT modify any parts and only use accessories and spare parts supplied by Draper Tools. • Keep this product out of reach of children and keep children and unauthorised persons away from the UK Conformity Assessed work area.
  • Page 5: Product Overview

    Carefully remove the product from the packaging and examine it for any signs of damage that may have occurred during shipment. If any part is damaged or missing, do not attempt to use the product. Please contact the Draper Helpline; contact details can be found at the back of this manual.
  • Page 6: Operating The Tester

    5. Operating Instructions Important: Before operating this product, read and • The tester has a resistive tester internally load area (6) understand all the safety instructions listed in this which generates some heat during operation. DO NOT hold this area for a long time and allow the manual.
  • Page 7: Maintenance, Storage And Disposal

    5. Operating Instructions 13-Pin & 7-Pin Function Table Wiring Description/function 13-Pin 7-Pin Left hand indicator ✓ ✓ Fog light ✓ ✓ Earth (terminal 1-6 ✓ ✓ return path) Right hand indicator ✓ ✓ Right hand side/tail light ✓ ✓ Brake light ✓...
  • Page 8: Contact Details

    Telephone Sales Desk: +44 (0) 23 8049 4333 General Enquiries: +44 (0) 23 8026 6355 General Fax: +44 (0) 23 8026 0784 Please contact the Draper Tools Product Helpline for repair and servicing enquiries. © Published by Draper Tools Limited © Published by Draper Tools Limited...
