Draper Expert KFT Manual

KEY FOB
TESTER
24446
Read this manual in full before using this product and
retain it for future use. Always use the latest version of
the manual. Please visit drapertools.com/manuals for
the latest version.
1. Intended Use
This product is designed for checking radio and infrared
wavelength emissions from vehicle key fobs and remote
controls to assist with diagnosing faults. The tester
operates between 418–434MHz.
Any other application beyond the conditions established
for use will be considered misuse. Draper Tools accepts no
responsibility for improper use of this product.
Part of our Expert range, this product is intended for
frequent trade use, with the quality and features to meet
and exceed expectations of the most demanding user.
2. Specification
Stock No.
Part No.
Radio frequency ranges 418Mhz, 433–434MHz
Power consumption
Automatic power off
Ambient conditions
Operation
Storage
Battery
Dimensions
Weight (incl. battery)
24446
KFT
26mA approx.
70–100 seconds after power on
0 to 50°C, humidity <85%
-10 to 60°C, humidity <85%
1 x 9v PP3 (not supplied)
W 81 x H 132 x D 28mm
130g approx
3. Health and Safety Information
• Use this product only for its intended purpose and do
not modify it in any way.
• DO NOT expose this product to liquids or wet
environments.
• Check the device carefully before use.
− DO NOT use this product if it is damaged in any way
or if there is evidence of battery leakage.
− If battery acid comes into contact with your skin,
wash it off immediately with plenty of clean water.
− If battery acid comes into contact with your eyes,
flush them with plenty of clean water and seek
medical attention immediately.
• DO NOT immerse this device in water or allow the
battery to come into contact with liquids.
• DO NOT abuse, mutilate or burn the battery.
• Keep this product out of reach of children.
4. Identification
(1) Radio signal indicator (red)
(2) Power indicator (green)
(3) Infrared signal indicator (red)
(4) Signal receptor
(5) Power button
(6) Battery compartment
(4)
(5)
(6)
EN
Original Instructions
Version 3
(1)
(2) (3)
