Operation & Safety
Manual
Original Instructions -
Keep this manual with the machine at all times.
RT2669, RT3369,
ERT2669, ERT3369
PVC 2104, 2110
31219164
March 11, 2024 - Rev F
Copyright ©
ANSI
AS/NZS GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RT2669 and is the answer not in the manual?

Questions and answers

Related Manuals for JLG RT2669

Summary of Contents for JLG RT2669

  • Page 1 Operation & Safety Manual Original Instructions - Keep this manual with the machine at all times. RT2669, RT3369, ERT2669, ERT3369 PVC 2104, 2110 31219164 March 11, 2024 - Rev F Copyright © ANSI AS/NZS GB...
  • Page 2 WARNING Operating, servicing and maintaining this vehicle or equipment can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other repro- ductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle or equipment in a well-ventilated area and wear gloves or wash your hands frequently when servicing.

  • Page 3: Foreword

    Due to continuous product improvements, JLG Industries, Inc. reserves the right to make specification changes without prior notification. Contact JLG Industries, Inc. for updated information.

  • Page 4: Safety Alert Symbols And Safety Signal Words

    It may also alert against unsafe practices. This decal will have a yellow background. NOTICE Indicates information or a company policy that relates directly or indirectly to the safety of personnel or protection of property. 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 5 NOTICE JLG Industries, Inc. sends safety related bulletins to the owner of record of this machine. Contact JLG Industries, Inc. to ensure that the current owner records are updated and accurate.
  • Page 6 Questions Regarding Product Modifications Contact: Product Safety and Reliability Department JLG Industries, Inc. 13224 Fountainhead Plaza Hagerstown, MD 21742 or Visit www.jlg.com to find your local JLG office. In USA: Toll Free: 877-JLG-SAFE (877-554-7233) Outside USA: Phone: 240-420-2661 Fax: 301-745-3713 E-mail: ProductSafety@JLG.com...

  • Page 7: Revision Log

    REVISION LOG DATE REVISION DESCRIPTION Original Issue October 11, 2021 October 20, 2021 Revision February 18, 2022 Revision May 24, 2022 Revision July 3, 2023 Revision March 11, 2024 Revision RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 8 This Page is intentionally left blank...

  • Page 9: Table Of Contents

    (All Markets Except CE/UKCA) ..........36 QuikLevel Advanced Test (If Equipped) ......37 SECTION 3 MACHINE CONTROLS, INDICATORS, AND OPERATION................... 39 General ................39 Description...............39 Operating Characteristics and Limitations......40 Platform Loading ..............40 Battery Charging (ERT Machines) ........41 Ground Control Station .............44 RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 10 3.20 Platform Rails Fold-Down Procedure .........69 3.21 Towing................73 3.22 Lifting and Tie Down Chart ..........74 3.23 RT2669, RT3369 Decal Locations ........74 3.24 ERT2669, ERT3369 Decal Locations .........80 SECTION 4 EMERGENCY PROCEDURES ........... 85 General ................85 Incident Notification ............85 Emergency Operation ............85 Platform Manual Descent Control ........86...
  • Page 11 Operator Maintenance ............ 114 6.11 Propane Fuel System ............. 119 6.12 Tires and Wheels............120 6.13 Supplemental Information Only Applicable to CE/UKCA Machines ............... 122 6.14 EC Declaration of Conformity .......... 123 6.15 UKCA Declaration of Conformity........124 RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 12 This Page is intentionally left blank...

  • Page 13: Safety Precautions

    If there are any questions with regard to safety, training, inspection, maintenance, application, and operation, please contact JLG Industries, Inc. (“JLG”). WARNING Failure to comply with the safety precautions listed in this manual could result in machine damage, property damage, personal injury or death.
  • Page 14 Do not travel on unsupported surfaces. • This machine can be operated in nominal ambient temperatures of 0° F to 104° F (-20° C to 40° C). Consult JLG to optimize operation outside of this temperature range. 1.2.3 Machine Inspection •...

  • Page 15: Operation

    Do not allow personnel to tamper with or operate the machine from the ground with personnel in the platform, except in an emergency. • Do not carry materials directly on platform railing unless approved by JLG. • When two or more persons are in the platform, the operator shall be responsible for all machine operations.
  • Page 16 Prior to operation, ensure all gates and rails are fastened and secured in their proper position. • JLG Industries, Inc. recommends that all persons in the platform wear a full body harness with a lanyard attached to an authorized lanyard anchorage point while operating this machine. For further information regarding fall protection requirements on JLG products, contact JLG Industries, Inc.
  • Page 17 Maintain a clearance of at least 10 ft (3 m) between any part of the machine and its occupants, their tools, and their equipment from any electrical line or apparatus carrying up to 50,000 volts. One foot additional clearance is required for every additional 30,000 volts or less. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 18 Before driving on floors, bridges, trucks, and other surfaces, check allowable capacity of the surfaces. • Never exceed the maximum platform capacity as specified on the platform. Keep all loads within the confines of the platform, unless authorized by JLG. 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 19 Do not increase the platform size with unauthorized modifications, deck extensions, or attachments. WARNING Do not operate the machine when wind conditions exceed specifications shown in the General Specifications section of this manual or as shown on the capacity placard on the platform billboard. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 20 • During operation, keep all body parts inside platform railing. • Keep hands and limbs out of the scissor arm assembly during operation and when elevated without safety prop engaged. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 21: Towing, Lifting, And Hauling

    When lifting machine with a forklift, position forks only at designated areas of the machine. Lift with a forklift of adequate capacity. • Refer to the Machine Operation section of this manual for lifting information. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 22: Maintenance

    Wear gloves to help protect hands from spraying fluid. • Use only replacement parts or components that are approved by JLG. To be considered approved, replacement parts or components must be identical or equivalent to original parts or components.
  • Page 23 Immediately rinse any contacted area with clean water and seek medical attention. • Charge batteries only in a well ventilated area. • Avoid overfilling the battery fluid level. Add distilled water to batteries only after the batteries are fully charged. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 24 This Page is intentionally left blank...

  • Page 25: User Responsibilities, Machine Preparation, And Inspection

    Operator Responsibility The operator must be instructed that they have the responsibility and authority to shut down the machine in case of a malfunction or other unsafe condition of either the machine or the job site. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 26: Preparation, Inspection, And Maintenance

    6. Accessories and optional equipment. PREPARATION, INSPECTION, AND MAINTENANCE The following table covers machine inspections and maintenance required by JLG Industries, Inc. Consult local regulations for further requirements for MEWPs. The frequency of inspections and maintenance must be increased as necessary when the machine is used in a harsh or hostile environment, if the machine is used with increased frequency, or if the machine is used in a severe manner.

  • Page 27: Pre-Start Inspection

    Mechanic tenance Manual Service & Main- tenance Manual Note: Inspection forms are available from JLG. Use the Service & Maintenance Manual to perform inspections. NOTICE JLG Industries, Inc. recognizes a factory trained service technician as a person who has successfully completed the JLG Service Training School for the specified JLG product model.
  • Page 28 11. Function Check – Once the Walk-Around Inspection is complete, perform a functional check of all systems in an area free of overhead and ground level obstructions. Refer to Section – Machine Controls, Indicators, And Operation for more specific instructions on the operation of each function. 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 29 Ensure the gate closes properly and is not bent or damaged. Keep gate closed at all times except when entering/exiting the platform and loading/unloading materials. 13. Lanyard Attach Points – JLG Industries, Inc. recommends personnel in the platform wear a full body harness with a lanyard attached to an authorized lanyard anchorage point.

  • Page 30: Walk-Around Inspection

    User Responsibilities, Machine Preparation, and Inspection WALK-AROUND INSPECTION Figure 3. RT2669, RT3369 OAD02320 Figure 4. ERT2669, ERT3369 Begin the Walk-Around Inspection at Item 1 as noted on the diagram. Continue to the right (counterclockwise viewed from top) checking each item in sequence for the conditions listed in the following checklist.
  • Page 31 16. Wheel Drive Hub – No evidence of leakage. Refer to Inspection Note. 17. Spindle, Tie Rod, and Steer Linkage – No loose or missing parts, no visible damage. No steer cylinder leaks or damage. 18. Static Strap (If Equipped) – Refer to Inspection Note. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 32: Function Check

    Ensure all machine functions are disabled when the Emergency Stop button is activated. d. Check that auxiliary descent, lift down operates with engine off and power e. Check that manual descent operates properly (refer to Section 4 for more information). 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 33 80 in (2.03 m) d. Ensure that all machine functions are disabled when the Emergency Stop button is activated. e. Ensure all machine functions stop when function control is released or when joystick trigger is released. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 34: Oscillating Axle - Lockout Cylinder Test (If Equipped) (Ce/Ukca Markets Only)

    3. Set the drive control switch into position and carefully drive the machine up ascension ramp until left oscillating axle wheel is on top of block. 4. Verify the axle oscillates to maintain contact with the ground/ramp. (All four wheels on the ground). 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 35 11. Lower the machine platform; the lockout cylinder should then release and allow the axle to oscillate. It may be necessary to activate drive to release cylinders. 12. If the lockout cylinders do not function properly, have qualified personnel correct the malfunction prior to any further operation. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 36: Oscillating Axle - Lockout Cylinder Test (If Equipped) (All Markets Except Ce/Ukca)

    4. Verify the axle oscillates to maintain contact with the ground/ ramp. (All four wheels on the ground). 5. Raise machine platform above stowed position to drive cutout height. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 37: Quiklevel Advanced Test (If Equipped)

    QuikLevel Set), engage the joystick backwards to perform QuikLevel Return. Have an assistant verify the chassis rotates in the opposite direction when compared to QuikLevel Set. 8. Once the platform and ground alarms both sound two times, QuikLevel Return is complete. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 38 14. Engage the joystick backwards to realign the chassis and rear axle and then drive off the ramp. 15. If the system does not function properly, have qualified personnel correct the malfunction prior to any further operation. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 39: Machine Controls, Indicators, And Operation

    Ground controls operate lift up and down. Except for performing inspections and function checks, ground controls are to be used only in an emergency to lower the platform to the ground should the operator in the platform be unable to do so. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 40: Operating Characteristics And Limitations

    3. All machine systems are functioning properly. 3.3.3 Stability This machine, as originally manufactured by JLG and operated within its rated capacity on a smooth, firm surface, within the limits of the maximum operating slope, provides a stable aerial platform for all platform positions.

  • Page 41: Battery Charging (Ert Machines)

    3. The charge cycle is complete when the single green LED light on the hood between the AC plug and battery disconnect becomes solid green. Additionally, the green LEDs on the top and bottom panels of the battery charger illuminate. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 42 High State of Charge: Bottom Panel — Green LED on; Top Panel — Green LED flashing • Charge Complete: Bottom Panel — Green LED on; Top Panel — Green LED on • Fault Indicator: Red LED on • External Error Condition Caution: Amber LED flashing 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 43 (2) Charging (High State of Charge): Green LED fast flash • (3) Full Charge (100%): Solid green LED • (4) Charger Fault: Amber LED rapid flash • (5) LED Light • No AC Current: LED is off RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 44: Ground Control Station

    7. Genset Start Switch (If Equipped) 8. Genset Indicator (If Equipped) OAD02050 Figure 6. ERT Machines 3.6.1 Ground Control Station Functions WARNING Do not operate from ground control station with personnel in the platform except in an emergency. 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 45 7. Genset Start Switch (If Equipped) — This button activates the genset system to charge the batteries. 8. Genset Indicator (If Equipped) — This will illuminate when a genset system fault is present. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 46: Ground Control Station Display Gauge

    Diagnostics Screen. The indicator lamp will light when there is an active DTC in the Fault Log. Figure 7. Splash Screen The Diagnostic Screen will show active and inactive faults from the JLG Control System on the screen. An asterisk (*) will be displayed to show active faults. 31219164...
  • Page 47 Machine Controls, Indicators, and Operation Figure 8. Diagnostic Screen RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 48: Platform Control Station

    4. Engine Start Switch 11. USB Charge Port 5. Horn 12. Indicator Display 6. Speed Select Switch 13. Steer Control Switch 7. Leveling Jacks OR QuikLevel Advanced Switch 14. Joystick Controller with Trigger (Enable) Switch 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 49 Always position emergency stop switch to the off position (pushed in) when machine is not in use. 2. Lift Select Switch — The lift switch provides for raising and lowering the platform. Lift is activated by pressing the switch and position the joystick forward or backward. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 50 10. Generator Switch (If Equipped) — Enables the generator that supplies AC power to the platform. 11. USB Charge Port — Provides a USB charge port to the operator. 12. Indicator Display — Shows a variety of machine operation information. Refer to ABCD for more information. 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 51 Power is removed from the plat- form controls when the footswitch is released. Note: Once a function has been selected, the operator has seven seconds to engage the function. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 52: Indicator Display

    12. Drive Speed 5. Current Platform Height 13. DTC Messages Display 6. Leveling Jacks Indicator (If Equipped) 14. Lift/Lower Indicator 7. Leveling Jacks Status (If Equipped) 15. Maximum Allowed Platform Height 8. Drive Select Indicator 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 53 10. Battery State-of-Charge 4. Platform Load Gauge 11. Drive Speed 5. Current Platform Height 12. DTC Messages Display 6. Leveling Jacks Indicator (If Equipped) 13. Lift/Lower Indicator 7. Drive Select Indicator 14. Maximum Allowed Platform Height RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 54 7. Regenerative Braking 3.9.1 Indicator Display Functions CAUTION If the tilt indicator warning light/alarm is activated when platform is raised, lower platform and drive to a smooth firm surface within the limits of the maximum operating slope. 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 55 Glow Plug (not shown) When diesel engine-powered machines are turned on, the glow plug indicator will illuminate on the display, regardless of engine or ambient temperature. Do not start the engine until the glow plug indicator light disappears. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 56 The LiftSense pane can be hidden by pressing the far left button of the display. Press this button again to return the pain to view. Figure 15. LiftSense Pane Hidden 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 57 Indicates if QuikLevel Advanced function has been selected. QuikLevel Advanced Status (If Equipped) • Rear Axle Extend • Rear Axle Retract • Rear Axle Aligned • Rear Axle Not Aligned • Drive at Height Allowed RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 58: Navigating The Indicator Display

    When a system fault has been detected, the upper right hand corner of the display will show the DTC readout. Additionally, the system fault indicator will flash the appropriate distress code. 3.10 NAVIGATING THE INDICATOR DISPLAY 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 59 5. Use the Scroll Page Left and Scroll Page Right buttons (6) to cycle through the different pages of the menu selection. 6. The page icon (7) will inform what page is currently being viewed. 7. To return to the Home Screen, press the Left Navigation button (5). RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 60 Display Settings: Allows operators to adjust display features (brightness, contrast, time, date, units, etc.). 6. Menu Select: Press to display submenu screen. 7. Help Menu Select: Press and hold for quick access to Help (3) screens. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 61: Engine Operation

    When operating a machine at high ambient temperatures, a decrease in ma- chine performance and an increase in engine coolant temperature may occur. Contact JLG Customer Service for operation under abnormal conditions. 3.11.1 Starting Procedure Note: Perform initial start-up from Ground Controls.

  • Page 62: Dual Fuel System (If Equipped)

    LPG position until the engine regains smoothness, then return the switch to the gas select position. Repeat as necessary until the engine runs smoothly on gasoline. 3. Close the hand valve on the LPG supply tank by turning clockwise. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 63: Traveling (Driving)

    3. Press the drive switch and move the joystick rearward and hold for the duration of travel. Drive speed is determined by the distance the joystick is moved from the center off position. Do not activate the high drive speed switch when traveling in reverse. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 64: Traveling (Grade/Side Slope)

    The drive pump will shift back into high speed once the incline decreases to 5° — 8° (depending on machine configuration). There will be a two second delay before the machine returns to high speed. OAD02660 Figure 17. Grade/Side Slope (RT2669, ERT2669) OAD02670 Figure 18. Grade/Side Slope (RT3369, ERT3369) 31219164...

  • Page 65: Platform

    Machine lowering can continue after a three (3) second delay. Once the lowering function is re-engaged an audible alarm will sound. After a one and a half (1.5) second delay the platform will continue lowering. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 66: Leveling Jacks (If Equipped)

    The platform and ground alarms will both sound three times to indicate this is complete. Note: If a 2/5 flash code appears through the system fault light at the platform control station, the machine is unable to level. Reposition and try again. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 67: Quiklevel Advanced (Dual Oscillating Axles) (If Equipped)

    These axles are activated through a switch on the platform control station. 3.17.1 Auto-Leveling 1. With the machine in the stowed position, turn the power on and start the machine. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 68 At this time the machine will no longer lift but the machine can be lowered. Note: The machine must be in the stowed position before the trim function is operable. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 69: Parking And Stowing

    Only fold down the rails when the machine is in the stowed (platform fully lowered) position. Do not raise the platform with the rails folded down. The rails must be in the upright position and properly pinned when raising the platform. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 70 3. Lift up inner side rails and fold down to floor. 4. Pull pins at rear rails. Lift up and fold down rear gate to floor. 5. Lift up outer side rails and fold down to floor. 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 71 Machine Controls, Indicators, and Operation ART_OAD02780 RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 72 Machine Controls, Indicators, and Operation ART_OAD02790 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 73: Towing

    It is not recommended that this machine be towed, except in the event of an emergency such as a machine malfunction or a total machine power failure. Refer to Section — Emergency Procedures for emergency towing procedures. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 74: Lifting And Tie Down Chart

    Machine Controls, Indicators, and Operation 3.22 LIFTING AND TIE DOWN CHART OAD02390 3.23 RT2669, RT3369 DECAL LOCATIONS China ANSI ANSI Export CE/AUS OAD02270 Figure 19. View 1 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 75 Machine Controls, Indicators, and Operation OAD02260 Figure 20. View 2 OAD02280 Figure 21. View 3 RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 76 Machine Controls, Indicators, and Operation China ANSI Export ANSI CE/AUS OAD02290 Figure 22. View 4 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 77 Machine Controls, Indicators, and Operation RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 78 Machine Controls, Indicators, and Operation 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 79 Machine Controls, Indicators, and Operation RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 80: Ert2669, Ert3369 Decal Locations

    Machine Controls, Indicators, and Operation 3.24 ERT2669, ERT3369 DECAL LOCATIONS OAD02360 Figure 23. View 1 China ANSI ANSI Export CE/AUS OAD02370 Figure 24. View Two 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 81 Machine Controls, Indicators, and Operation 19 20 China ANSI Export OAD02380 CE/AUS ANSI Figure 25. View 3 RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 82 Machine Controls, Indicators, and Operation 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 83 Machine Controls, Indicators, and Operation RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 84 Machine Controls, Indicators, and Operation 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 85: Emergency Procedures

    INCIDENT NOTIFICATION JLG Industries, Inc. must be notified immediately of any incident involving a JLG product. Even if no injury or property damage is evident, JLG must be contacted by telephone and provided with all necessary details. • USA: 877-JLG-SAFE (554-7233) •...

  • Page 86: Platform Manual Descent Control

    The platform manual descent control is used in the event of total power failure to lower the platform using gravity. The red T-handle is located at the rear of the machine behind the ladder. Look for the instruction decal located beside the handle. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 87: Emergency Towing Procedures

    4.5.1 RT Machines 1. Ensure the machine is in the stowed position. Chock wheels securely. 2. Disengage drive hubs by reversing disconnect caps. 3. Connect suitable equipment, remove chocks, and move machine. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 88 4. Remove chocks and tow machine. 5. After towing is complete, chock the wheels. 6. To reset the brakes, push the yellow button again, recycle power to the machine, or position the keyswitch to platform mode. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 89: Accessories

    ✔ ✔ ✔ ✔ * This accessory is not available for RT2669 or ERT2669 machines. ** This accessory is not available for ERT machines. FOOTSWITCH The Footswitch serves as another enable switch in the function control circuit. It must be depressed in sequence with the platform control joystick trigger switch to enable operation of machine functions when using the platform controls.

  • Page 90: Generator (2500W)

    Do not overload platform. • Ensure no personnel are beneath platform. • Keep lanyard attached at all times. • Do not use electrical tools in water. • Use correct voltage and frequency for tool being used. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 91: Onboard Generator (3500W)

    Run time at 25% of rated load: 11 hr 5.4.2 Safety Precautions • Do not use electrical tools in water. • Use correct voltage and frequency for tool being used. • Do not overload circuit. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 92: Pipe Racks

    Safety Precautions WARNING This accessory affects overall platform capacity. Refer to capacity decal and adjust accordingly. Weight in racks plus weight in platform must not exceed rated capacity. NOTICE Retract platform extension before loading material. 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 93 2. Route the tie-down straps at each end across loaded material. Hook into place and tighten until secure. 3. To remove material, loosen and unhook tie-down straps, then carefully remove material from racks. Note: Reinstall straps across any remaining material before continuing machine operations. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 94: Platform Worklights

    These lights can be moved around the platform as needed. Use the bracket to coil any excess cable. WORKSTATION 1. Adjustable Work Surface 2. Accessory Decal The Workstation offers an adjustable work surface and additional space for storage of tools and objects. 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 95 Ensure the Workstation is secured to the platform. • Check for missing or damaged components. Replace if necessary. • Check for loose nuts and bolts. Torque to JLG Torque Chart Specifications if necessary. • Replace any missing or illegible decals.
  • Page 96 This Page is intentionally left blank...

  • Page 97: Machine Specifications And Operator Maintenance

    Axle — – Dual Oscillating 8,340 lb (3783 9,330 lb (4232 Axle Maximum 40% (22°) 40% (22°) 35% (19°) 35% (19°) Stowed Travel Grade (Gradeability) Maximum 5° 5° 5° 5° Stowed Travel Grade (Side Slope) RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 98 (Rated Load) Hydraulic Pressures Main Relief 3800 psi 2700 psi 3800 psi 2750 psi Steer Relief 2500 psi 2500 psi 2500 psi 2500 psi (Right) Steer Relief 1900 psi 1900 psi 1900 psi 1900 psi (Left) 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 99 Side to Side beyond Model the following limits: the following limits: 4° at 0% — 55% Capacity RT2669, 3° at 56% — 75% Capacity 3° ERT2669 2.5° at 76% — 100% Capacity RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 100 90 lb (400 N) zontal Side Force 6.3.5 Fluid Capacities Specification RT2669, RT3369 Fuel Tank Diesel 10 gal (38 L) Gasoline 10 gal (38 L) LP Tank 33.5 lb (15.2 kg) Hydraulic Tank 13.2 gal (50 L) 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 101 26 x 12 D460 Foam-Filled Ply Rating Inflation Pressure 70 psi (4.8 bar) Wheel Nut Torque 105 ft. lb. (230.5 Nm) 6.3.8 Battery Charger (ERT Machines) Battery Charger Type Delta-Q Electrical System Voltage (DC) 48V (1200 W) RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 102: Engine Specifications

    2600 RPM Alternator 40 Amp, 12V, Belt-Driven Battery 69 Amp-Hour, 700 Cold-Cranking Amps, 12V DC Fuel Consumption Low RPM 0.41 gal/hr (1.5 L/hr) High RPM 2.0 gal/hr (7.6 L/hr) Displacement 1.261 L (77 cu. in.) 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 103 1.85 lb/hr (0.84 kg/hr) High RPM 9.3 lb/hr (4.23 kg/hr) Displacement 0.962 L (58.7 cu. in.) Gross Power Gas — 31.1 Hp (23.2 kW) @ 3600 RPM LP — 29.5 Hp (22.0 kW) @ 3600 RPM Gross Torque RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 104: Engine Oil Operating Temperature

    LP — 48.8 ft. lb. (66.2 Nm) @ 1800 RPM ENGINE OIL OPERATING TEMPERATURE NOTICE Machine operation using non-JLG approved engine oil or operation outside of the temperature boundaries outlined in the “Engine Oil Operating Temperature” charts may result in premature wear or damage to components of the engine.

  • Page 105: Lubrication

    Multipurpose Grease having a minimum dripping point of 350° F. Excellent water re- sistance and adhesive qualities, and being of extreme pressure type. (Timken OK40 pounds minimum.) EPGL Extreme Pressure Gear Lube (oil) meeting API service classification GL-5 or MIL- Spec MIL-L-2105. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 106 Note: Aside from JLG recommendations, it is not advisable to mix oils of different brands or types, as they may not contain the same required additives or be of comparable viscosities.
  • Page 107 † Virtually Non-toxic classification indicates a LC50 > 5000 ppm per OECD 203 ‡ Fire Resistant classification indicates Factory Mutual Research Corp. (FMRC) Approval Note: Shell Tellus S4 V32/Univis HVI 26 is available only to RT machines. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 108 Machine Specifications and Operator Maintenance NOTICE Machine operation using non-JLG approved hydraulic fluids or operation outside of the temperature boundaries outlined in the “Hydraulic Fluid Operation Chart” may result in premature wear of damage to components of the hydraulic system.
  • Page 109 Figure 29. RT Machines — Hydraulic Oil Higher Ambient Temperature Arrow The addition of a hydraulic oil-cooler is highly recommended for prolonged operation in this temperature range (Consult JLG Service). Lower Ambient Temperature Arrow Operation in this temperature range should include the use of hydraulic system heating aids (Consult JLG Service).

  • Page 110: Scissor Arm Safety Prop

    2. Pull the ring to release the prop, then pull the prop down until it hangs vertically. 3. Lower the platform until the prop rests on the cross-shaft below. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 111: Battery Maintenance And Charging

    2. Scissor Arm Safety Prop BATTERY MAINTENANCE AND CHARGING WARNING To avoid injury from an explosion, do not smoke or allow sparks or a flame near battery during servicing. Always wear eye and hand protection when servicing batteries. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 112 Note: To avoid electrolyte overflow, add distilled water to batteries after charging. When adding water to the battery, fill only to level indicated or 3/8'' above separators. 1. Open battery compartment cover to allow access to battery terminals and vent caps. 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 113: Battery Disconnect (Ert Machines)

    Turn the switch counterclockwise to return battery power to the machine. NOTICE When charging the machine’s batteries, the battery disconnect switch must be set to the on position (3) or the batteries will not charge. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 114: Operator Maintenance

    • Fuel — Diesel or gasoline (per engine type, refer to decal on the machine) • Fill as required. 6.10.2 Hydraulic Oil Tank OAD02420 • Lube Point — Fill cap/fill level • Lube — HO 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 115 Interval — Check coolant level daily. Ensure it is between the full and low lines. If coolant level is low, allow fluid to cool, then add as required. Replace coolant annually in accordance with engine manual. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 116 Once a week squeeze the evacuator valve on bottom of air cleaner assembly to allow collected debris to fall out of the air cleaner. 6.10.7 Oil Change with Filter Kubota Diesel (D1305–E4B) OAD02450 • Lube Point — Fill cap/spin-on element • Lube — EO — Minimum API CF 31219164 RT2669, RT3369, ERT2669, ERT3369...
  • Page 117 Interval — Initial oil and filter change at first 50 hours of operation, then every year or 200 hours of operation. • Check oil level daily (1) and maintain within marked level. Change oil and filter (2) in accordance with engine manual. RT2669, RT3369, ERT2669, ERT3369 31219164...
  • Page 118 Machine Specifications and Operator Maintenance 6.10.8 Fuel/Water Separator Filter (Diesel) OAD02400 6.10.9 Fuel Strainer (Diesel) OAD02460 • Lube Point — Replaceable • Interval — Every year or 750 hours of operation 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 119: Propane Fuel System

    2. Start and run the vehicle until the engine stalls. 3. Turn the ignition switch OFF. CAUTION Residual vapor pressure will be present in the fuel system. Ensure the work area is well ventilated before disconnecting any fuel line. RT2669, RT3369, ERT2669, ERT3369 31219164...

  • Page 120: Tires And Wheels

    JLG recommends a replacement tire be the same size, ply and brand as originally installed on the machine. Please refer to the JLG Parts Manual for the part number of the approved tires for a particular machine model. If not using a JLG approved...
  • Page 121 When selecting and installing a replacement tire, ensure that all tires are inflated to the pressure recommended by JLG. Due to size variations between tire brands, both tires on the same axle should be the same.

  • Page 122: Torque Sequence

    The vibration total value to which the hand-arm system is subjected does not exceed 2,5 m/s . The highest root mean square value of weighted acceleration to which the whole body is subjected does not exceed 0,5 m/s 31219164 RT2669, RT3369, ERT2669, ERT3369...

  • Page 123: Ec Declaration Of Conformity

    EN 61000-6-2:2005 • EN 60204-1:2018 • EN 280:2013+ A1:2015 • EN ISO 12100:2010 JLG Industries, Inc. hereby declares that the above mentioned machine conforms with the requirements of: • 2006/42/EC — Machinery Directive • 2014/30/EU — EMC Directive • 2014/53/EU — RED Directive (If fitted with optional equipment) •...

  • Page 124: Ukca Declaration Of Conformity

    EN 60204-1:2018 • EN 280:2013+ A1:2015 • EN ISO 12100:2010 JLG Industries, Inc. hereby declares that the above mentioned machine conforms with the requirements of: • 2008 No. 1597 - Supply of Machinery (Safety) Regulations 2008 • 2016 No. 1091 - Electromagnetic Compatibility Regulations 20165 •...
  • Page 125 Inspection, Maintenance and Repair Log Serial Number ___________________________________ Date Comments...
  • Page 126 Inspection, Maintenance and Repair Log...
  • Page 128 Corporate Office JLG Industries, Inc. 1 JLG Drive McConnellsburg, PA 17233-9533 USA (717) 485-5161 (Corporate) (877) 554-5438 (Customer Support) (717) 485-6417 Visit our website for JLG Worldwide Locations. www.jlg.com...

This manual is also suitable for:

Rt3369Ert2669Ert3369

Table of Contents
